YoctoHub-GSM-3G-NA : User's guide

1. Introduction
1.1 Optional accessories
2. Presentation
2.1 The YoctoHub-GSM-3G-NA components
3. First steps
3.1 Manual configuration
3.2 Device state window
3.3 Automated configuration
3.4 Connections
4. Assembly
4.1 Fixing
4.2 Fixing a sub-module
5. Interaction with external services
5.1 Configuration
5.2 Emoncms
5.3 Valarm.net
5.4 Xively (previously Cosm)
5.5 InfluxDB
5.6 PRTG
5.7 MQTT
5.8 Yocto-API callback
5.9 User defined callback
6. Programming
6.1 Accessing connected modules
6.2 Controlling the YoctoHub-GSM-3G-NA
7. Sleep mode
7.1 Manual configuration of the wake ups
7.2 Configuring the wake up system by software
8. High-level API Reference
8.1 Class YHubPort
8.2 Class YCellular
8.3 Class YNetwork
8.4 Class YFiles
8.5 Class YRealTimeClock
8.6 Class YWakeUpMonitor
8.7 Class YWakeUpSchedule
9. Troubleshooting
9.1 Where to start?
9.2 Programming examples don't seem to work
9.3 Linux and USB
9.4 ARM Platforms: HF and EL
9.5 Powered module but invisible for the OS
9.6 Another process named xxx is already using yAPI
9.7 Disconnections, erratic behavior
9.8 Can't contzect sub devices by USB
9.9 Damaged device
10. Characteristics
11. Index

1. Introduction

The YoctoHub-GSM-3G-NA is a 60x58mm electronic module enabling you to drive other Yoctopuce modules through a cellular connection of the 3G GSM type (UMTS and HSPA). The radio module supports the two GSM frequency bands 850MHz and 1900MHz used in North America, the Caribbeans, and Latin America.1


The YoctoHub-GSM-3G-NA

The YoctoHub-GSM-3G-NA is designed to be easily deployed and to not require any specific maintenance. In the opposite to a mini-computer, it does not have a complex operating system. Settings can be modified manually or automatically through USB. Therefore, the YoctoHub-GSM-3G-NA is much more suited to industrialization than a mini-computer. However, you cannot run additional software written by the user on the YoctoHub-GSM-3G-NA.

The YoctoHub-GSM-3G-NA is not a standard USB hub with network access. Although it uses USB cables, its down ports use a proprietary protocol, much simpler than USB. It is therefore not possible to control, or even to power, standard USB devices with a YoctoHub-GSM-3G-NA.

Yoctopuce thanks you for buying this YoctoHub-GSM-3G-NA and sincerely hopes that you will be satisfied with it. The Yoctopuce engineers have put a large amount of effort to ensure that your YoctoHub-GSM-3G-NA is easy to install anywhere and easy to use in any circumstance. If you are nevertheless disappointed with this device, do not hesitate to contact Yoctopuce support2.

1.1. Optional accessories

The accessories below are not strictly necessary, but they might help you to get the better of your YoctoHub-GSM-3G-NA.

Screws and spacers

In order to mount the Yocto-3D module, you can put small screws in the 3mm assembly holes, with a screw head no larger than 8mm. The best way is to use threaded spacers, which you can then mount wherever you want. You can find more details on this topic in the chapter about assembly and connections.

USB MicroB-MicroB cable

The YoctoHub-GSM-3G-NA connectivity is mainly achieved through USB microB connectors. This means you will have to use USB cables with a microB connector on both ends. These cables are not very common, but you can order some from the Yoctopuce online shop3.

1.27mm pitch connector

USB cable are very handy to quickly interconnect Yoctopuce devices. However, these use a lot of space. That's why there is, on the YoctoHub-GSM-3G-NA PCB, a small footprint for 1.27 or 1.25mm pitch connectors near each USB connector. Soldering 1.27 pitch connector on these footprints allows to use a much more compact wiring. These 1.27mm connectors are quite standard and can be ordered from any electronic shop. Yoctopuce sells the 1.27-1.27-11 product, which is a set of connector with a 11cm long cable.

YoctoHub-Shield

The YoctoHub-GSM-3G-NA features three down ports allowing to connect up to three sub-devices. However this capacity can be raised, thanks to the YoctoHub-Shield. Each shield add 4 new ports, and up to 10 shields can be daisy-chained to your YoctoHub-GSM-3G-NA. See the YoctoHub-Shield documentation for more details.


The YoctoHub-Shield adds more ports to your YoctoHub-GSM-3G-NA.

Enclosures

Your YoctoHub-GSM-3G-NA has been designed to be installed as is in your project. Nevertheless, Yoctopuce sells enclosures specifically designed for Yoctopuce devices. More details are available on the Yoctopuce web site. The suggested enclosure model for your YoctoHub-GSM-3G-NA is the YoctoBox-HubWlan-Transp.


Your YoctoHub-GSM-3G-NA can be installed in an enclosure.

2. Presentation


1:Yocto-button 10:Sleep neutralization
2:Control + power USB port 11:Back connection
3:Yocto-Led 12:Down port 1
4:Overload led 13:Down port 1 led
5:Network transfer led 14:Down port 2
6:Wake up button 15:Down port 2 led
7:Sleep button 16:Down port 3
8:SIM card holder (below) 17:Down port 3led
9:Antenna connector

2.1. The YoctoHub-GSM-3G-NA components

Serial number

Each Yocto-module has a unique serial number assigned to it at the factory. For YoctoHub-GSM-3G-NA modules, this number starts with YHUBGSM4. The module can be software driven using this serial number. The serial number cannot be modified.

Logical name

The logical name is similar to the serial number: it is a supposedly unique character string which allows you to reference your module by software. However, in the opposite of the serial number, the logical name can be modified at will. The advantage is to enable you to build several copies of the same project without needing to modify the driving software. You only need to program the same logical name in each copy. Warning: the behavior of a project becomes unpredictable when it contains several modules with the same logical name and when the driving software tries to access one of these modules through its logical name. When leaving the factory, modules do not have an assigned logical name. It is yours to define.

Yocto-button

The Yocto-button has two functionalities. First, it can activate the Yocto-beacon mode (see below under Yocto-led). Second, if you plug in a Yocto-module while keeping this button pressed, you can then reprogram its firmware with a new version. Note that there is a simpler UI-based method to update the firmware, but this one works even if the firmware on the module is incomplete or corrupted.

Yocto-led

Normally, the Yocto-led is used to indicate that the module is working smoothly. The Yocto-led then emits a low blue light which varies slowly, mimicking breathing. The Yocto-led stops breathing when the module is not communicating any more, as for instance when powered by a USB hub which is disconnected from any active computer.

When you press the Yocto-button, the Yocto-led switches to Yocto-beacon mode. It starts flashing faster with a stronger light, in order to facilitate the localization of a module when you have several identical ones. It is indeed possible to trigger off the Yocto-beacon by software, as it is possible to detect by software that a Yocto-beacon is on.

The Yocto-led has a third functionality, which is less pleasant: when the internal software which controls the module encounters a fatal error, the Yocto-led starts emitting an SOS in morse 4. If this happens, unplug and re-plug the module. If it happens again, check that the module contains the latest version of the firmware and, if it is the case, contact Yoctopuce support5.

Power / Control port

This port allows you to power the YoctoHub-GSM-3G-NA and the modules connected to it with a simple USB charger. This port also allows you to control the YoctoHub-GSM-3G-NA by USB, exactly like you can do it with a classic Yoctopuce module. It is particularly useful when you want to configure the YoctoHub-GSM-3G-NA without knowing its IP address.

Down ports

You can connect up to three Yoctopuce modules on these ports. They will then be available as if they were connected to a computer running a VirtualHub. Note that the protocol used between the YoctoHub-GSM-3G-NA and the USB modules is not USB but a lighter proprietary protocol. Therefore, the YoctoHub-GSM-3G-NA cannot manage devices other than Yoctopuce devices. A standard USB hub does not work either6. If you want to connect more than three Yoctopuce modules, just connect one or more YoctoHub-Shield7 to the back ports.

Warning: the USB connectors are simply soldered in surface and can be pulled out if the USB plug acts as a lever. In this case, if the tracks stayed in position, the connector can be soldered back with a good iron and flux to avoid bridges. Alternatively, you can solder a USB cable directly in the 1.27mm-spaced holes near the connector.

The SIM card holder

To connect the YoctoHub-GSM-3G-NA to a GSM cellular network, you must insert in your YoctoHub-GSM-3G-NA a SIM card, combined with a subscription allowing data transfers. The SIM card holder is designed for the most standard mini-SIM format, also called known as 2FF. Adaptors enabling the use Micro-SIM or Nano-SIM cards, can be found in any mobile phone store. The SIM card holder is of the push-push type: push to insert the SIM until it is in position and makes a small click. To remove the SIM card, don't pull it but push it a second time to eject it from the holder.

You must insert the SIM card with the metal contacts against the printed circuit.


Direction of insertion of the SIM card in the YoctoHub-GSM-3G-NA.

Antenna connector

The YoctoHub-GSM-3G-NA includes an ultra miniature coaxial antenna connector (UFL). Take great care of the UFL connector. It is fragile and is not designed to support many connection/deconnection cycles. The YoctoHub-GSM-3G-NA is sold with a small UFL cable to RP-SMA socket8 and a corresponding RP-SMA plug antenna9. You can use another antenna of your choice, as long as it is designed for the frequency range used in your country for GSM and it has the correct connector. Beware also that using a high-gain antenna may drive you to emit a signal stronger than the authorized norm in your country.


Antenna connection

Overload led

The YoctoHub-GSM-3G-NA continuously monitors its power consumption. If it detects a global consumption of more that 2A, following an overload on one of the down ports for example, it automatically disables all the down ports and lights the overload led. To isolate the source of the issue, you can reactivate the ports one by one, monitoring the power consumption increase. Alternatively, if you know the source of the overload issue and know to have solved it, you can restart the YoctoHub-GSM-3G-NA to enable all its ports at once.

Note that the overload led is a protection measure which can prevent overheating, but it is not a protection guarantee against shorts.

Sleep

On average, the YoctoHub-GSM-3G-NA consumes about 0.5 Watt (100mA), to which you must add the connected modules consumption. But it is able to get into sleep to reduce its power consumption to a strict minimum, and to wake up at a precise time or when an outside contact is closed. This feature is very useful to build measuring installations working on a battery. When the YoctoHub-GSM-3G-NA is in sleep mode, most of the electronics of the module as well as the connected Yoctopuce modules are switched off. This reduces the total consumption to 75 µW (15 µA).

Switching to sleep and waking up can be programmed based on a schedule, controlled by software, or controlled manually with two push buttons located on the YoctoHub-GSM-3G-NA circuit. You can find there two pairs of contacts which enable you to shunt these two buttons.


Sleep and wake up button deviation.

The YoctoHub-GSM-3G-NA includes a switch with which you can disable the sleep mode at the hardware level. This functionality is particularly useful when developing and debugging your project, as well as when updating the firmware.

3. First steps

The aim of this chapter is to help you connect and configure your YoctoHub-GSM-3G-NA for the first time.

3.1. Manual configuration

You can configure your YoctoHub-GSM-3G-NA through its USB control port, by using the VirtualHub10.

Run the VirtualHub on your preferred computer and connect it to the power / control port of the YoctoHub-GSM-3G-NA. You need a USB A-MicroB cable.


Configuration: connecting your YoctoHub-GSM-3G-NA by USB to a computer

Launch your preferred browser on the URL of your VirtualHub. It usually is http://127.0.0.1:4444. You obtain the list of Yoctopuce modules connected by USB, among which your YoctoHub-GSM-3G-NA.


List of Yoctopuce modules connected by USB to your computer, among which your YoctoHub-GSM-3G-NA

Click on the configure button corresponding to your YoctoHub-GSM-3G-NA. You obtain the module configuration window. This window contains a Network configuration section.


YoctoHub-GSM-3G-NA module configuration window

Connection to the GSM cellular network

The first thing you must do is to configure your YoctoHub-GSM-3G-NA so that it connects itself to your GSM network. To do so, click on the edit button corresponding to GSM configuration in the Network configuration section and the GSM cellular network configuration window opens:


GSM cellular network configuration window

You can then enter the PIN code corresponding to the SIM card inserted in the YoctoHub-GSM-3G-NA if need be, and select with which provider you want to work.

In most cases, the SIM card "knows" the provider it is designed for and you can simply keep the automatic selection. However, near country borders, the card may wish to use a more powerful but foreign signal, more expensive to use. To prevent this, you can select the provider of your local network manually.

You can also specify in your YoctoHub-GSM-3G-NA the context in which you want to enable the IP connection data transfer. You can either completely disable it if you are only interested in SMS use11, or activate it on the SIM card network only, or even allow data use on other networks (roaming). Take care if you activate this latest option, because it can quickly generate significant costs!

Depending on your SIM card and on your cellular service provider, you may have to configure an APN (Access Point Name), corresponding to the Internet gateway on your cellular network. It is an arbitrary name, assigned by your provider, to which you must sometimes add a user name and a password. It is impossible to list in this user's guide the APN name to be used with each provider. But if you do a search on the Internet with the name of your cellular service provider and the "APN" keyword, you will very easily find the APN name to use as well as the potential user name and password. The apnchanger.org web site contains this information for the main providers in many countries.

Warning: you have only three chances to enter the correct PIN code, if you fail to do so, you will have to resest the SIM card with its PUK code.

When you have entered the network parameters and potentially tested them, click on the Ok button to close this configuration window and come back to the main configuration window.

Difference between a GSM network and a standard network

Important: The GSM cellular network to which your YoctoHub-GSM-3G-NA is connected is not strictly equivalent to a standard Internet connection. Indeed, the IP address assigned to a cellular modem is almost always a non routed IP address. The YoctoHub-GSM-3G-NA sees the whole Internet network, but Internet does not have a public address to contact it. This means that you cannot connect yourself remotely on your YoctoHub-GSM-3G-NA from any computer, by simply typing its IP address in a web browser.

One of the solutions to solve this issue is to obtain from your cellular service provided a SIM card enabling a direct connection through a virtual private network.

Using a virtual private network

Some cellular service providers can conditionally provide a GSM connection with an internet link to a private address range, which is dedicated to you. This type of connection, dedicated to the machine-to-machine services, is generally restricted to businesses. It allows you to connect yourself remotely (through a virtual private network) to your YoctoHub-GSM-3G-NA, which is otherwise impossible because each cellular phone is normally implicitly isolated behind a NAT filter.

If you do have such a connection, you can configure which IP address must be assigned to the YoctoHub-GSM-3G-NA, and which IP address is authorized to contact it (firewall function). To do so, click on the edit opposite to the IP addressing line. It is essential to configure these parameters correctly to be able to contact your module through its IP address. Otherwise, the firewall blocks any incoming connection.

3.2. Device state window

It is possible to check the device general state, such as logical name, Network state, Hub ports states etc. Juste go back to the device list.

Click on the serial number corresponding to your YoctoHub-GSM-3G-NA. This opens your module property window:


The YoctoHub-GSM-3G-NA properties

This window contains a section indicating the state of the YoctoHub-GSM-3G-NA network part. You can find there its MAC address, current IP address, and network name. This section also provides the state of the network connection. Possible states are:

If your YoctoHub-GSM-3G-NA does indeed go into the WWW Ready state, it means that your internet cellular connection works correctly. You can then perform the next steps: Connect the wanted Yoctopuce modules (sensors and/or actuators) and configure the interactions with the outside.

3.3. Automated configuration

You can industrialize the YoctoHub-GSM-3G-NA network configuration. You can find in the following chapters of this documentation the description of the programming functions enabling you to read the Ethernet address (MAC address) of a module, and to configure all of its network parameters.

The network configuration functions are also available as command lines, using the YNetwork utility software available in the command line programming library 12.

After having set some parameters by software, make sure to call the saveToFlash() function to ensure that the new settings are saved permanently in the module flash memory.

3.4. Connections

Power supply

The YoctoHub-GSM-3G-NA must be powered by the USB control socket.

USB

Simply connect a USB charger in the power / control port port, but make sure that the charger provides enough electric power. The YoctoHub-GSM-3G-NA consumes about 100mA, to which you must add the power consumption of each submodule. The YoctoHub-GSM-3G-NA is designed to manage a maximum of 2A. Therefore, we recommend a USB charger able to deliver at least 2A. Moreover, you must make sure that the total power consumption of the set "hub + submodules" does not go above this limit.


The YoctoHub-GSM-3G-NA can be powered by a regular USB charger

Sub-modules

The YoctoHub-GSM-3G-NA is able to drive all the Yoctopuce modules of the Yocto range. These modules can be directly connected to the down ports. They are automatically detected. For this, you need Micro-B Micro-B USB cables. Whether you use OTG cables or not does not matter.


Connecting sub-modules with USB cables

Alternatively, you can connect your modules by directly soldering electric cables between the YoctoHub-GSM-3G-NA and its sub-modules. Indeed, all the Yoctopuce modules have contacts designed for direct cabling. We recommend you to use solid coper ribbon cables, with a 1.27mm pitch. Solid copper ribbon cable is less supple than threaded cable but easier to solder. Pay particular attention to polarity: the YoctoHub-GSM-3G-NA, like all modules in the Yoctopuce range, is not protected against polarity inversion. Such an inversion would likely destroy your devices. Make sure the positions of the square contacts on both sides of the cable correspond.


Sub-module connection with ribbon cable

The YoctoHub-GSM-3G-NA is designed so that you can fix a single width module directly on top of it. To do so, you need screws, spacers13, and a 1.27mm pitch connector14. You can thus transform your USB Yoctopuce module into a network module while keeping a very compact format.


Fixing a module directly on the hub

Beware, the YoctoHub-GSM-3G-NA is designed to drive only Yoctopuce modules. Indeed, the protocol used between the YoctoHub-GSM-3G-NA and the sub-modules is not USB but a much lighter proprietary protocol. If, by chance, you connect a device other than a Yoctopuce module on one of the YoctoHub-GSM-3G-NA down ports, this port is automatically disabled to prevent damages to the device.

4. Assembly

This chapter provides important information regarding the use of the YoctoHub-GSM-3G-NA module in real-world situations. Make sure to read it carefully before going too far into your project if you want to avoid pitfalls.

4.1. Fixing

While developing your project, you can simply let the hub hang at the end of its cable. Check only that it does not come in contact with any conducting material (such as your tools). When your project is almost at an end, you need to find a way for your modules to stop moving around.


Examples of assembly on supports

The YoctoHub-GSM-3G-NA module contains 3mm assembly holes. You can use these holes for screws. The screw head diameter must not be larger than 8mm or the heads will damage the module circuits.

Make sure that the lower surface of the module is not in contact with the support. We recommend using spacers. You can fix the module in any position that suits you: however be aware that the YoctoHub-GSM-3G-NA electronic components, in particular the network part, generate heat. You must not let this heat accumulate.

4.2. Fixing a sub-module

The YoctoHub-GSM-3G-NA is designed so that you can screw a single width module directly on top of it. By single width, we mean modules with a 20mm width. All the single width modules have their 5 assembly holes and the USB socket in the same position. The sub-module can be assembled with screws and spacers. At the back of the YoctoHub-GSM-3G-NA and sub-module USB connectors, there are a set of 4 contacts enabling you to easily perform an electrical connection between the hub and the sub-module. If you do not feel sufficiently at ease with a soldering iron, you can also use a simple Micro-B Micro-B USB cable, OTG or not.


Fixing a module directly on the hub

Make sure to mount your module on the designed side, as illustrated above. The module 5 holes must correspond to the YoctoHub-GSM-3G-NA 5 holes, and the square contact on the module must be connected to the square contact on the YoctoHub-GSM-3G-NA down port. If you assemble a module on the other side or in another way, the connector polarity will be inverted and you risk to permanently damage your equipment.

All the accessories necessary to fix a module on your YoctoHub-GSM-3G-NA are relatively usual. You can find them on the Yoctopuce web site, as on most web sites selling electronic equipment. However, beware: the head of the screws used to assemble the sub-module must have a maximum head diameter of 4.5mm, otherwise they could damage the electronic components.

5. Interaction with external services

The YoctoHub-GSM-3G-NA can publish the state of connected devices on any web server. The values are posted on a regular basis and each time one of them changes significantly. This feature, named HTTP Callback, enables you to interface your Yoctopuce devices with many web services.

5.1. Configuration

To use this feature, just click on the configure button located on the line matching the YoctoHub-GSM-3G-NA on the main user interface. Then look for the Outgoing calbacks section and click on the edit button.


Just click on the "Configure" button on the first line.


Then edit the "Outgoing callbacks" section.

The callback configuration window shows up. This window enables you to define how your YoctoHub-GSM-3G-NA interacts with an external web server. Several interaction types are at your disposal. For each type, a specific wizard will help you enter appropriate parameters

5.2. Emoncms

Emoncms.org is an open-source cloud service where you can register to upload your sensor data. It will let you view your measures in real-time over the Internet, and draw historical graphs, without writing a single line of code. You just have to enter in the configuration window your own API key, as provided by Emoncms, and allocate an arbitrary node number to YoctoHub-GSM-3G-NA.

It is also possible to install Emoncms on your own server, to keep control on your data. You will find more explanations about this on Yoctopuce blog15.

Yoctopuce is not affiliated with Emoncms.org.

5.3. Valarm.net

Valarm is a professional cloud service where you can register to upload your sensor data, with some advanced features like remote configuration of Yoctopuce devices and measure geolocation.

Valarm is a reseller for Yoctopuce products, but Yoctopuce is not otherwise affiliated with Valarm.

5.4. Xively (previously Cosm)

Xively is a commercial cloud service where you might be able to register to upload your sensor data. Note that since end of 2014, Xively is focusing on enterprise and OEM customers, and might therefore not be available to everyone. For more details, see xively.com.

Yoctopuce is not affiliated with Xively.

5.5. InfluxDB

InfluxDB is an open-source database for time series, metrics and events. It is very efficient to retrieve measure series for a given time range, even when averaging on-the-fly. You can easily install it on your own computer to record and graph your sensor data. There is a step-by-step guide on how to configure InfluxDB and Grafana to graph Yoctopuce sensors on the Yoctopuce blog 16.

Yoctopuce is not affiliated to InfluxData nor to Grafana.

5.6. PRTG

PRTG is a commercial system, device and application monitoring solution developped by PAESSLER. You can easily install it on windows to record and graph your sensor data. For more details, see www.paessler.com/prtg. Vous pouvez facilement l'installer sur Windows pour enregistrer les mesures et obtenir des graphiques de vos capteurs. Pour plus de détails, voir fr.paessler.com/prtg. There is a step-by-step guide on how to configure PRTG to graph Yoctopuce sensors on the Yoctopuce blog 17.

Yoctopuce is not affiliated to PAESSLER.

5.7. MQTT

MQTT is an "Internet of Things" protocol to push sensor data to a central repository, named MQTT broker. For more details, see mqtt.org. You can also find several examples of use of MQTT on Yoctopuce blog.

5.8. Yocto-API callback

With some programming environments, the full Yoctopuce API can be used to drive devices in HTTP callback mode. This way, a web server script can take control of Yoctopuce devices installed behind a NAT filter without having to open any port. Typically, this allows you to control Yoctopuce devices running on a LAN behind a private DSL router from a public web site. The YoctoHub-GSM-3G-NA then acts as a gateway. All you have to do is to define the HTTP server script URL and, if applicable, the credentials needed to access it. On the server script, you would initialize the library using the following call:

RegisterHub("http://callback");

There are two possibilities to use the Yoctopuce API in callback mode. The first one, available in PHP, Java and Node.JS is using pure HTTP callbacks. The YoctoHub-GSM-3G-NA posts its complete state to the server, and receives commands in return from the server script. There are however some limitations with this mode: complex interactions, such as retrieving data from the datalogger, are not possible.

The second mode API callback mode is using WebSocket callbacks. It is currently only available in Java and Node.JS. WebSockets are a standard extension of HTTP, providing a full bidirectional exchange channel over an HTTP connection. When a server script is connected by a YoctoHub-GSM-3G-NA over a Websocket callback connection, the full Yoctopuce API can be used, without any limitation.

The GatewayHub webservice, available from Yoctopuce web site, uses this Websocket callback technology to provide remote access to the YoctoHub-GSM-3G-NA, even in the presence of a NAT filter or firewall. For more information, see Yoctopuce blog18.

5.9. User defined callback

The "User defined callback" allow you to fully customize the way the YoctoHub-GSM-3G-NA interacts with an external web site. You need to provide the URL of the web server where you want the hub to post data. Note that only HTTP protocol is supported (no HTTPS).


The callback configuration window.

If you want to secure access to your callback script, you can setup a standard HTTP authentication. The YoctoHub-GSM-3G-NA knows how to handle standard HTTP authentication schemes: simply fill in the user and and password fields needed to access the URL. Both Basic and Digest authentication are supported. However, Digest authentication is highly recommended, since it uses a challenge mechanism that avoids sending the password itself over the Internet, and prevents replays.

The YoctoHub-GSM-3G-NA posts the advertised values19 on a regular basis, and each time one of these values changes significantly. You can change the default delay between posts.

Tests

To help you debug the process, you can visualize with the YoctoHub-GSM-3G-NA the answer to the callback sent by the web server. Click on the test button when all required fields are filled. When the result meets your expectations, close the debug window and then click on the "Ok" button.

Format

Values are posted in one of the following formats:

1. If the function has been assigned a logical name:

FUNCTION_NAME = VALUE

2. If the module has been assigned a logical name, but not the function:

MODULE_NAME#HARDWARE_NAME = VALUE

3. If no logical name has been set:

SERIAL_NUMBER#HARDWARE_NAME = VALUE

Here is a short PHP script allowing you to visualize the data posted by the callback and the result in the debug window:


<?php
  Print(Date('H:i:s')."\r\n");
  foreach ($_POST as $key=>$value) {
      Print("$key=$value\r\n");
  }
?>


Callback test results with a Yocto-PowerRelay and a Yocto-Temperature.

6. Programming

6.1. Accessing connected modules

The YoctoHub-GSM-3G-NA behaves itself exactly like a computer running a VirtualHub. The only difference between a program using the Yoctopuce API with modules in native USB and the same program with Yoctopuce modules connected to a YoctoHub-GSM-3G-NA is located at the level of the registerHub function call. To use USB modules connected natively, the registerHub parameter is usb. To use modules connected to a YoctoHub-GSM-3G-NA, you must simply replace this parameter by the IP address of the YoctoHub-GSM-3G-NA. For instance, in Delphi:


YRegisterHub("usb",errmsg);

becomes


YRegisterHub("192.168.0.10",errmsg); // The hub IP address is 192.168.0.10

6.2. Controlling the YoctoHub-GSM-3G-NA

From the programming API standpoint, the YoctoHub-GSM-3G-NA is a module like the others. You can perfectly manage it from the Yoctopuce API. To do so, you need the following classes:

Module

This class, shared by all Yoctopuce modules, enables you to control the module itself. You can drive the Yocto-led, know the USB power consumption of the YoctoHub-GSM-3G-NA, and so on.

Network

This class enables you to manage the network part of the YoctoHub-GSM-3G-NA. You can control the link state, read the MAC address, change the YoctoHub-GSM-3G-NA IP address, know the power consumption on PoE, and so on.

HubPort

This class enables you to manage the hub part. You can enable or disable the YoctoHub-GSM-3G-NA ports, you can also know which module is connected to which port.

Files

This class enables you to access files stored in the flash memory of the YoctoHub-GSM-3G-NA. The YoctoHub-GSM-3G-NA contains a small file system which allows you to store, for example, a web application controlling the modules connected to the YoctoHub-GSM-3G-NA.

WakeMonitor

This class enables you to monitor the sleep mode of the YoctoHub-GSM-3G-NA.

WakeSchedule

This class enables you to schedule one or several wake ups for the YoctoHub-GSM-3G-NA.

You can find some examples on how to drive the YoctoHub-GSM-3G-NA by software in the Yoctopuce programming libraries, available free of charge on the Yoctopuce web site.

7. Sleep mode

The YoctoHub-GSM-3G-NA includes a real time clock (RTC) powered by a super capacitor. This capacitor charges itself automatically when the module is powered. But it is able to keep time without any power for several days. This RTC is used to drive a sleep and wake up system to save power. You can configure the sleep system manually through an interface or drive it through software.

7.1. Manual configuration of the wake ups

You can manually configure the wake up conditions by connecting yourself on the interface of the YoctoHub-GSM-3G-NA. In the Wake-up scheduler section of the main configuration window, click on the setup button corresponding to one of the "wakeup-schedule". This opens a window enabling you to schedule more or less regular wake ups. Select the boxes corresponding to the wanted occurrences. Empty sections are ignored.


Wake up configuration window: here every 10 minutes between 9h and 17h.

Likewise, you can configure directly in the YoctoHub-GSM-3G-NA interface the maximal wake up duration, after which the module automatically goes back to sleep. If your YoctoHub-GSM-3G-NA is running on batteries, this ensures they do not empty even if no explicit sleep command is received.

7.2. Configuring the wake up system by software

At the programming interface level, the wake up system is implemented with two types of functions: the wakeUpMonitor function and the wakeUpSchedule function.

wakeUpMonitor

The wakeUpMonitor function manages wake ups and sleep periods, proper. It provides all the instant managing functionalities : instant wake up, instant sleep, computing the date of the next wake up, and so on...

The wakeUpMonitor function enables you also to define the maximum duration during which the YoctoHub-GSM-3G-NA stays awake before automatically going back to sleep.

wakeUpSchedule

The wakeUpSchedule function enables you to program a wake up condition followed by a possible sleep. It includes five variables enabling you to define correspondences on minutes, hours, days of the week, days of the month, and months. These variables are integers where each bit defines a correspondence. Schematically, each set of minutes, hours, and days is represented as a set of boxes with each a coefficient which is a power of two, exactly like in the corresponding interface of the YoctoHub-GSM-3G-NA.

For example, bit 0 for the hours corresponds to hour zero, bit 1 corresponds to hour 1, bit 2 to hour 2, and so on.


To each box is assigned a power of two

Thus, to program the YoctoHub-GSM-3G-NA for it to wake up every day at noon, you must set bit 12 to 1, which corresponds to the value 2^12 = 4096.


Example for a wake up at 12h

For the module to wake up at 0 hour, 6 hours, and 12 hours, you must set the 0, 6, and 12 bits to 1, which corresponds to the value 2^0 +2^6 +2^12 = 1 + 64 + 4096 = 4161


Example for wake ups at 0, 6, and 12h

Variables can be combined. For a wake up to happen every day at 6h05, 6h10, 12h05, and 12h10, you must set the hours to 2^6 + 2^12 = 4060, minutes to 2^5 and 2^10 = 1056. Variables remaining at the zero value are ignored.


Example for wake ups at 6H05, 6h10, 12h05, and 12h10

Note that if you want to program a wake up at 6h05 and 12h10, but not at 6h10 and 12h05, you need to use two distinct wakeUpSchedule functions.

This paradigm allows you to schedule complex wake ups. Thus, to program a wake up every first Tuesday of the month, you must set to 1 bit 1 of the days of the week and the first seven bits of the days of the month.


Example for a wake up every first Tuesday of the month

Some programming languages, among which JavaScript, do not support 64 bit integers. This is an issue for encoding minutes. Therefore, minutes are available both through a 64 bit integer minutes and two 32 bit integers minutesA and minutesB. These 32 bit integers are supposed to be available in any current programming language.


Minutes are also available in the shape of two 32 bit integers

The wakeUpSchedule function includes an additional variable to define the duration, in seconds, during which the module stays awake after a wake up. If this variable is set to zero, the modules stays awake.

The YoctoHub-GSM-3G-NA includes two wakeUpSchedule functions, enabling you to program up to two independent wake up types.

8. High-level API Reference

This chapter summarizes the high-level API functions to drive your YoctoHub-GSM-3G-NA. Syntax and exact type names may vary from one language to another, but, unless otherwise stated, all the functions are available in every language. For detailed information regarding the types of arguments and return values for a given language, refer to the definition file for this language (yocto_api.* as well as the other yocto_* files that define the function interfaces).

For languages which support exceptions, all of these functions throw exceptions in case of error by default, rather than returning the documented error value for each function. This is by design, to facilitate debugging. It is however possible to disable the use of exceptions using the yDisableExceptions() function, in case you prefer to work with functions that return error values.

This chapter does not explain Yoctopuce programming concepts, in order to stay as concise as possible. You will find more details in the documentation of the devices you plan to connect to your YoctoHub-GSM-3G-NA.

8.1. Class YHubPort

YoctoHub slave port control interface, available for instance in the YoctoHub-Ethernet, the YoctoHub-GSM-3G-EU, the YoctoHub-Shield or the YoctoHub-Wireless-g

The YHubPort class provides control over the power supply for slave ports on a YoctoHub. It provide information about the device connected to it. The logical name of a YHubPort is always automatically set to the unique serial number of the Yoctopuce device connected to it.

In order to use the functions described here, you should include:

es
in HTML: <script src="../../lib/yocto_hubport.js"></script>
in node.js: require('yoctolib-es2017/yocto_hubport.js');
js
<script type='text/javascript' src='yocto_hubport.js'></script>
cpp
#include "yocto_hubport.h"
m
#import "yocto_hubport.h"
pas
uses yocto_hubport;
vb
yocto_hubport.vb
cs
yocto_hubport.cs
dnp
import YoctoProxyAPI.YHubPortProxy
java
import com.yoctopuce.YoctoAPI.YHubPort;
uwp
import com.yoctopuce.YoctoAPI.YHubPort;
py
from yocto_hubport import *
php
require_once('yocto_hubport.php');
vi
YHubPort.vi
Global functions
YHubPort.FindHubPort(func)

Retrieves a YoctoHub slave port for a given identifier.

YHubPort.FindHubPortInContext(yctx, func)

Retrieves a YoctoHub slave port for a given identifier in a YAPI context.

YHubPort.FirstHubPort()

Starts the enumeration of YoctoHub slave ports currently accessible.

YHubPort.FirstHubPortInContext(yctx)

Starts the enumeration of YoctoHub slave ports currently accessible.

YHubPort.GetSimilarFunctions()

Enumerates all functions of type HubPort available on the devices currently reachable by the library, and returns their unique hardware ID.

YHubPort properties
hubport→AdvertisedValue [read-only]

Short string representing the current state of the function.

hubport→Enabled [writable]

True if the YoctoHub port is powered, false otherwise.

hubport→FriendlyName [read-only]

Global identifier of the function in the format MODULE_NAME.FUNCTION_NAME.

hubport→FunctionId [read-only]

Hardware identifier of the YoctoHub slave port, without reference to the module.

hubport→HardwareId [read-only]

Unique hardware identifier of the function in the form SERIAL.FUNCTIONID.

hubport→IsOnline [read-only]

Checks if the function is currently reachable.

hubport→LogicalName [writable]

Logical name of the function.

hubport→PortState [read-only]

Current state of the YoctoHub port.

hubport→SerialNumber [read-only]

Serial number of the module, as set by the factory.

YHubPort methods
hubport→clearCache()

Invalidates the cache.

hubport→describe()

Returns a short text that describes unambiguously the instance of the YoctoHub slave port in the form TYPE(NAME)=SERIAL.FUNCTIONID.

hubport→get_advertisedValue()

Returns the current value of the YoctoHub slave port (no more than 6 characters).

hubport→get_baudRate()

Returns the current baud rate used by this YoctoHub port, in kbps.

hubport→get_enabled()

Returns true if the YoctoHub port is powered, false otherwise.

hubport→get_errorMessage()

Returns the error message of the latest error with the YoctoHub slave port.

hubport→get_errorType()

Returns the numerical error code of the latest error with the YoctoHub slave port.

hubport→get_friendlyName()

Returns a global identifier of the YoctoHub slave port in the format MODULE_NAME.FUNCTION_NAME.

hubport→get_functionDescriptor()

Returns a unique identifier of type YFUN_DESCR corresponding to the function.

hubport→get_functionId()

Returns the hardware identifier of the YoctoHub slave port, without reference to the module.

hubport→get_hardwareId()

Returns the unique hardware identifier of the YoctoHub slave port in the form SERIAL.FUNCTIONID.

hubport→get_logicalName()

Returns the logical name of the YoctoHub slave port.

hubport→get_module()

Gets the YModule object for the device on which the function is located.

hubport→get_module_async(callback, context)

Gets the YModule object for the device on which the function is located (asynchronous version).

hubport→get_portState()

Returns the current state of the YoctoHub port.

hubport→get_serialNumber()

Returns the serial number of the module, as set by the factory.

hubport→get_userData()

Returns the value of the userData attribute, as previously stored using method set_userData.

hubport→isOnline()

Checks if the YoctoHub slave port is currently reachable, without raising any error.

hubport→isOnline_async(callback, context)

Checks if the YoctoHub slave port is currently reachable, without raising any error (asynchronous version).

hubport→isReadOnly()

Test if the function is readOnly.

hubport→load(msValidity)

Preloads the YoctoHub slave port cache with a specified validity duration.

hubport→loadAttribute(attrName)

Returns the current value of a single function attribute, as a text string, as quickly as possible but without using the cached value.

hubport→load_async(msValidity, callback, context)

Preloads the YoctoHub slave port cache with a specified validity duration (asynchronous version).

hubport→muteValueCallbacks()

Disables the propagation of every new advertised value to the parent hub.

hubport→nextHubPort()

Continues the enumeration of YoctoHub slave ports started using yFirstHubPort().

hubport→registerValueCallback(callback)

Registers the callback function that is invoked on every change of advertised value.

hubport→set_enabled(newval)

Changes the activation of the YoctoHub port.

hubport→set_logicalName(newval)

Changes the logical name of the YoctoHub slave port.

hubport→set_userData(data)

Stores a user context provided as argument in the userData attribute of the function.

hubport→unmuteValueCallbacks()

Re-enables the propagation of every new advertised value to the parent hub.

hubport→wait_async(callback, context)

Waits for all pending asynchronous commands on the module to complete, and invoke the user-provided callback function.

YHubPort.FindHubPort()
YHubPort.FindHubPort()
yFindHubPort()yFindHubPort()[YHubPort FindHubPort: ]yFindHubPort()yFindHubPort()YHubPort.FindHubPort()YHubPort.FindHubPort()YHubPort.FindHubPort()YHubPort.FindHubPort()YHubPort.FindHubPort()yFindHubPort()YHubPort.FindHubPort()

Retrieves a YoctoHub slave port for a given identifier.

js
function yFindHubPort(func)
cpp
YHubPort* yFindHubPort(string func)
m
+(YHubPort*) FindHubPort: (NSString*) func
pas
TYHubPort yFindHubPort(func: string): TYHubPort
vb
function yFindHubPort(ByVal func As String) As YHubPort
cs
static YHubPort FindHubPort(string func)
dnp
static YHubPortProxy FindHubPort(string func)
java
static YHubPort FindHubPort(String func)
uwp
static YHubPort FindHubPort(string func)
py
FindHubPort(func)
php
function yFindHubPort($func)
es
static FindHubPort(func)

The identifier can be specified using several formats:

This function does not require that the YoctoHub slave port is online at the time it is invoked. The returned object is nevertheless valid. Use the method YHubPort.isOnline() to test if the YoctoHub slave port is indeed online at a given time. In case of ambiguity when looking for a YoctoHub slave port by logical name, no error is notified: the first instance found is returned. The search is performed first by hardware name, then by logical name.

If a call to this object's is_online() method returns FALSE although you are certain that the matching device is plugged, make sure that you did call registerHub() at application initialization time.

Parameters :

funca string that uniquely characterizes the YoctoHub slave port, for instance YHUBETH1.hubPort1.

Returns :

a YHubPort object allowing you to drive the YoctoHub slave port.

YHubPort.FindHubPortInContext()
YHubPort.FindHubPortInContext()
YHubPort.FindHubPortInContext()YHubPort.FindHubPortInContext()YHubPort.FindHubPortInContext()

Retrieves a YoctoHub slave port for a given identifier in a YAPI context.

java
static YHubPort FindHubPortInContext(YAPIContext yctx, String func)
uwp
static YHubPort FindHubPortInContext(YAPIContext yctx, string func)
es
static FindHubPortInContext(yctx, func)

The identifier can be specified using several formats:

This function does not require that the YoctoHub slave port is online at the time it is invoked. The returned object is nevertheless valid. Use the method YHubPort.isOnline() to test if the YoctoHub slave port is indeed online at a given time. In case of ambiguity when looking for a YoctoHub slave port by logical name, no error is notified: the first instance found is returned. The search is performed first by hardware name, then by logical name.

Parameters :

yctxa YAPI context
funca string that uniquely characterizes the YoctoHub slave port, for instance YHUBETH1.hubPort1.

Returns :

a YHubPort object allowing you to drive the YoctoHub slave port.

YHubPort.FirstHubPort()
YHubPort.FirstHubPort()
yFirstHubPort()yFirstHubPort()[YHubPort FirstHubPort]yFirstHubPort()yFirstHubPort()YHubPort.FirstHubPort()YHubPort.FirstHubPort()YHubPort.FirstHubPort()YHubPort.FirstHubPort()yFirstHubPort()YHubPort.FirstHubPort()

Starts the enumeration of YoctoHub slave ports currently accessible.

js
function yFirstHubPort()
cpp
YHubPort * yFirstHubPort()
m
+(YHubPort*) FirstHubPort
pas
TYHubPort yFirstHubPort(): TYHubPort
vb
function yFirstHubPort() As YHubPort
cs
static YHubPort FirstHubPort()
java
static YHubPort FirstHubPort()
uwp
static YHubPort FirstHubPort()
py
FirstHubPort()
php
function yFirstHubPort()
es
static FirstHubPort()

Use the method YHubPort.nextHubPort() to iterate on next YoctoHub slave ports.

Returns :

a pointer to a YHubPort object, corresponding to the first YoctoHub slave port currently online, or a null pointer if there are none.

YHubPort.FirstHubPortInContext()
YHubPort.FirstHubPortInContext()
YHubPort.FirstHubPortInContext()YHubPort.FirstHubPortInContext()YHubPort.FirstHubPortInContext()

Starts the enumeration of YoctoHub slave ports currently accessible.

java
static YHubPort FirstHubPortInContext(YAPIContext yctx)
uwp
static YHubPort FirstHubPortInContext(YAPIContext yctx)
es
static FirstHubPortInContext(yctx)

Use the method YHubPort.nextHubPort() to iterate on next YoctoHub slave ports.

Parameters :

yctxa YAPI context.

Returns :

a pointer to a YHubPort object, corresponding to the first YoctoHub slave port currently online, or a null pointer if there are none.

YHubPort.GetSimilarFunctions()
YHubPort.GetSimilarFunctions()
YHubPort.GetSimilarFunctions()

Enumerates all functions of type HubPort available on the devices currently reachable by the library, and returns their unique hardware ID.

dnp
static new string[] GetSimilarFunctions()

Each of these IDs can be provided as argument to the method YHubPort.FindHubPort to obtain an object that can control the corresponding device.

Returns :

an array of strings, each string containing the unique hardwareId of a device function currently connected.

hubport→AdvertisedValuehubport.AdvertisedValue

Short string representing the current state of the function.

dnp
string AdvertisedValue

hubport→Enabledhubport.Enabled

True if the YoctoHub port is powered, false otherwise.

dnp
int Enabled

Possible values:

Y_ENABLED_INVALID = 0
Y_ENABLED_FALSE = 1
Y_ENABLED_TRUE = 2

Writable. Changes the activation of the YoctoHub port. If the port is enabled, the connected module is powered. Otherwise, port power is shut down.

hubport→FriendlyNamehubport.FriendlyName

Global identifier of the function in the format MODULE_NAME.FUNCTION_NAME.

dnp
string FriendlyName

The returned string uses the logical names of the module and of the function if they are defined, otherwise the serial number of the module and the hardware identifier of the function (for example: MyCustomName.relay1)

hubport→FunctionIdhubport.FunctionId

Hardware identifier of the YoctoHub slave port, without reference to the module.

dnp
string FunctionId

For example relay1

hubport→HardwareIdhubport.HardwareId

Unique hardware identifier of the function in the form SERIAL.FUNCTIONID.

dnp
string HardwareId

The unique hardware identifier is composed of the device serial number and of the hardware identifier of the function (for example RELAYLO1-123456.relay1).

hubport→IsOnlinehubport.IsOnline

Checks if the function is currently reachable.

dnp
bool IsOnline

If there is a cached value for the function in cache, that has not yet expired, the device is considered reachable. No exception is raised if there is an error while trying to contact the device hosting the function.

hubport→LogicalNamehubport.LogicalName

Logical name of the function.

dnp
string LogicalName

Writable. You can use yCheckLogicalName() prior to this call to make sure that your parameter is valid. Remember to call the saveToFlash() method of the module if the modification must be kept.

hubport→PortStatehubport.PortState

Current state of the YoctoHub port.

dnp
int PortState

Possible values:

Y_PORTSTATE_INVALID = 0
Y_PORTSTATE_OFF = 1
Y_PORTSTATE_OVRLD = 2
Y_PORTSTATE_ON = 3
Y_PORTSTATE_RUN = 4
Y_PORTSTATE_PROG = 5

hubport→SerialNumberhubport.SerialNumber

Serial number of the module, as set by the factory.

dnp
string SerialNumber

hubport→clearCache()hubport.clearCache()hubport→clearCache()[hubport clearCache]hubport.clearCache()hubport.clearCache()hubport.clearCache()hubport.clearCache()hubport.clearCache()hubport→clearCache()hubport.clearCache()

Invalidates the cache.

js
function clearCache()
cpp
void clearCache()
m
-(void) clearCache
pas
clearCache()
vb
procedure clearCache()
cs
void clearCache()
java
void clearCache()
py
clearCache()
php
function clearCache()
es
async clearCache()

Invalidates the cache of the YoctoHub slave port attributes. Forces the next call to get_xxx() or loadxxx() to use values that come from the device.

hubport→describe()hubport.describe()hubport→describe()[hubport describe]hubport.describe()hubport.describe()hubport.describe()hubport.describe()hubport.describe()hubport→describe()hubport.describe()

Returns a short text that describes unambiguously the instance of the YoctoHub slave port in the form TYPE(NAME)=SERIAL.FUNCTIONID.

js
function describe()
cpp
string describe()
m
-(NSString*) describe
pas
string describe(): string
vb
function describe() As String
cs
string describe()
java
String describe()
py
describe()
php
function describe()
es
async describe()

More precisely, TYPE is the type of the function, NAME it the name used for the first access to the function, SERIAL is the serial number of the module if the module is connected or "unresolved", and FUNCTIONID is the hardware identifier of the function if the module is connected. For example, this method returns Relay(MyCustomName.relay1)=RELAYLO1-123456.relay1 if the module is already connected or Relay(BadCustomeName.relay1)=unresolved if the module has not yet been connected. This method does not trigger any USB or TCP transaction and can therefore be used in a debugger.

Returns :

a string that describes the YoctoHub slave port (ex: Relay(MyCustomName.relay1)=RELAYLO1-123456.relay1)

hubport→get_advertisedValue()
hubport→advertisedValue()
hubport.get_advertisedValue()hubport→get_advertisedValue()[hubport advertisedValue]hubport.get_advertisedValue()hubport.get_advertisedValue()hubport.get_advertisedValue()hubport.get_advertisedValue()hubport.get_advertisedValue()hubport.get_advertisedValue()hubport.get_advertisedValue()hubport→get_advertisedValue()hubport.get_advertisedValue()YHubPort get_advertisedValue

Returns the current value of the YoctoHub slave port (no more than 6 characters).

js
function get_advertisedValue()
cpp
string get_advertisedValue()
m
-(NSString*) advertisedValue
pas
string get_advertisedValue(): string
vb
function get_advertisedValue() As String
cs
string get_advertisedValue()
dnp
string get_advertisedValue()
java
String get_advertisedValue()
uwp
async Task<string> get_advertisedValue()
py
get_advertisedValue()
php
function get_advertisedValue()
es
async get_advertisedValue()
cmd
YHubPort target get_advertisedValue

Returns :

a string corresponding to the current value of the YoctoHub slave port (no more than 6 characters).

On failure, throws an exception or returns Y_ADVERTISEDVALUE_INVALID.

hubport→get_baudRate()
hubport→baudRate()
hubport.get_baudRate()hubport→get_baudRate()[hubport baudRate]hubport.get_baudRate()hubport.get_baudRate()hubport.get_baudRate()hubport.get_baudRate()hubport.get_baudRate()hubport.get_baudRate()hubport.get_baudRate()hubport→get_baudRate()hubport.get_baudRate()YHubPort get_baudRate

Returns the current baud rate used by this YoctoHub port, in kbps.

js
function get_baudRate()
cpp
int get_baudRate()
m
-(int) baudRate
pas
LongInt get_baudRate(): LongInt
vb
function get_baudRate() As Integer
cs
int get_baudRate()
dnp
int get_baudRate()
java
int get_baudRate()
uwp
async Task<int> get_baudRate()
py
get_baudRate()
php
function get_baudRate()
es
async get_baudRate()
cmd
YHubPort target get_baudRate

The default value is 1000 kbps, but a slower rate may be used if communication problems are encountered.

Returns :

an integer corresponding to the current baud rate used by this YoctoHub port, in kbps

On failure, throws an exception or returns Y_BAUDRATE_INVALID.

hubport→get_enabled()
hubport→enabled()
hubport.get_enabled()hubport→get_enabled()[hubport enabled]hubport.get_enabled()hubport.get_enabled()hubport.get_enabled()hubport.get_enabled()hubport.get_enabled()hubport.get_enabled()hubport.get_enabled()hubport→get_enabled()hubport.get_enabled()YHubPort get_enabled

Returns true if the YoctoHub port is powered, false otherwise.

js
function get_enabled()
cpp
Y_ENABLED_enum get_enabled()
m
-(Y_ENABLED_enum) enabled
pas
Integer get_enabled(): Integer
vb
function get_enabled() As Integer
cs
int get_enabled()
dnp
int get_enabled()
java
int get_enabled()
uwp
async Task<int> get_enabled()
py
get_enabled()
php
function get_enabled()
es
async get_enabled()
cmd
YHubPort target get_enabled

Returns :

either Y_ENABLED_FALSE or Y_ENABLED_TRUE, according to true if the YoctoHub port is powered, false otherwise

On failure, throws an exception or returns Y_ENABLED_INVALID.

hubport→get_errorMessage()
hubport→errorMessage()
hubport.get_errorMessage()hubport→get_errorMessage()[hubport errorMessage]hubport.get_errorMessage()hubport.get_errorMessage()hubport.get_errorMessage()hubport.get_errorMessage()hubport.get_errorMessage()hubport→get_errorMessage()hubport.get_errorMessage()

Returns the error message of the latest error with the YoctoHub slave port.

js
function get_errorMessage()
cpp
string get_errorMessage()
m
-(NSString*) errorMessage
pas
string get_errorMessage(): string
vb
function get_errorMessage() As String
cs
string get_errorMessage()
java
String get_errorMessage()
py
get_errorMessage()
php
function get_errorMessage()
es
get_errorMessage()

This method is mostly useful when using the Yoctopuce library with exceptions disabled.

Returns :

a string corresponding to the latest error message that occured while using the YoctoHub slave port object

hubport→get_errorType()
hubport→errorType()
hubport.get_errorType()hubport→get_errorType()[hubport errorType]hubport.get_errorType()hubport.get_errorType()hubport.get_errorType()hubport.get_errorType()hubport.get_errorType()hubport→get_errorType()hubport.get_errorType()

Returns the numerical error code of the latest error with the YoctoHub slave port.

js
function get_errorType()
cpp
YRETCODE get_errorType()
m
-(YRETCODE) errorType
pas
YRETCODE get_errorType(): YRETCODE
vb
function get_errorType() As YRETCODE
cs
YRETCODE get_errorType()
java
int get_errorType()
py
get_errorType()
php
function get_errorType()
es
get_errorType()

This method is mostly useful when using the Yoctopuce library with exceptions disabled.

Returns :

a number corresponding to the code of the latest error that occurred while using the YoctoHub slave port object

hubport→get_friendlyName()
hubport→friendlyName()
hubport.get_friendlyName()hubport→get_friendlyName()[hubport friendlyName]hubport.get_friendlyName()hubport.get_friendlyName()hubport.get_friendlyName()hubport.get_friendlyName()hubport→get_friendlyName()hubport.get_friendlyName()

Returns a global identifier of the YoctoHub slave port in the format MODULE_NAME.FUNCTION_NAME.

js
function get_friendlyName()
cpp
string get_friendlyName()
m
-(NSString*) friendlyName
cs
string get_friendlyName()
dnp
string get_friendlyName()
java
String get_friendlyName()
py
get_friendlyName()
php
function get_friendlyName()
es
async get_friendlyName()

The returned string uses the logical names of the module and of the YoctoHub slave port if they are defined, otherwise the serial number of the module and the hardware identifier of the YoctoHub slave port (for example: MyCustomName.relay1)

Returns :

a string that uniquely identifies the YoctoHub slave port using logical names (ex: MyCustomName.relay1)

On failure, throws an exception or returns Y_FRIENDLYNAME_INVALID.

hubport→get_functionDescriptor()
hubport→functionDescriptor()
hubport.get_functionDescriptor()hubport→get_functionDescriptor()[hubport functionDescriptor]hubport.get_functionDescriptor()hubport.get_functionDescriptor()hubport.get_functionDescriptor()hubport.get_functionDescriptor()hubport.get_functionDescriptor()hubport→get_functionDescriptor()hubport.get_functionDescriptor()

Returns a unique identifier of type YFUN_DESCR corresponding to the function.

js
function get_functionDescriptor()
cpp
YFUN_DESCR get_functionDescriptor()
m
-(YFUN_DESCR) functionDescriptor
pas
YFUN_DESCR get_functionDescriptor(): YFUN_DESCR
vb
function get_functionDescriptor() As YFUN_DESCR
cs
YFUN_DESCR get_functionDescriptor()
java
String get_functionDescriptor()
py
get_functionDescriptor()
php
function get_functionDescriptor()
es
async get_functionDescriptor()

This identifier can be used to test if two instances of YFunction reference the same physical function on the same physical device.

Returns :

an identifier of type YFUN_DESCR.

If the function has never been contacted, the returned value is Y_FUNCTIONDESCRIPTOR_INVALID.

hubport→get_functionId()
hubport→functionId()
hubport.get_functionId()hubport→get_functionId()[hubport functionId]hubport.get_functionId()hubport.get_functionId()hubport.get_functionId()hubport.get_functionId()hubport.get_functionId()hubport→get_functionId()hubport.get_functionId()

Returns the hardware identifier of the YoctoHub slave port, without reference to the module.

js
function get_functionId()
cpp
string get_functionId()
m
-(NSString*) functionId
vb
function get_functionId() As String
cs
string get_functionId()
dnp
string get_functionId()
java
String get_functionId()
py
get_functionId()
php
function get_functionId()
es
async get_functionId()

For example relay1

Returns :

a string that identifies the YoctoHub slave port (ex: relay1)

On failure, throws an exception or returns Y_FUNCTIONID_INVALID.

hubport→get_hardwareId()
hubport→hardwareId()
hubport.get_hardwareId()hubport→get_hardwareId()[hubport hardwareId]hubport.get_hardwareId()hubport.get_hardwareId()hubport.get_hardwareId()hubport.get_hardwareId()hubport.get_hardwareId()hubport→get_hardwareId()hubport.get_hardwareId()

Returns the unique hardware identifier of the YoctoHub slave port in the form SERIAL.FUNCTIONID.

js
function get_hardwareId()
cpp
string get_hardwareId()
m
-(NSString*) hardwareId
vb
function get_hardwareId() As String
cs
string get_hardwareId()
dnp
string get_hardwareId()
java
String get_hardwareId()
py
get_hardwareId()
php
function get_hardwareId()
es
async get_hardwareId()

The unique hardware identifier is composed of the device serial number and of the hardware identifier of the YoctoHub slave port (for example RELAYLO1-123456.relay1).

Returns :

a string that uniquely identifies the YoctoHub slave port (ex: RELAYLO1-123456.relay1)

On failure, throws an exception or returns Y_HARDWAREID_INVALID.

hubport→get_logicalName()
hubport→logicalName()
hubport.get_logicalName()hubport→get_logicalName()[hubport logicalName]hubport.get_logicalName()hubport.get_logicalName()hubport.get_logicalName()hubport.get_logicalName()hubport.get_logicalName()hubport.get_logicalName()hubport.get_logicalName()hubport→get_logicalName()hubport.get_logicalName()YHubPort get_logicalName

Returns the logical name of the YoctoHub slave port.

js
function get_logicalName()
cpp
string get_logicalName()
m
-(NSString*) logicalName
pas
string get_logicalName(): string
vb
function get_logicalName() As String
cs
string get_logicalName()
dnp
string get_logicalName()
java
String get_logicalName()
uwp
async Task<string> get_logicalName()
py
get_logicalName()
php
function get_logicalName()
es
async get_logicalName()
cmd
YHubPort target get_logicalName

Returns :

a string corresponding to the logical name of the YoctoHub slave port.

On failure, throws an exception or returns Y_LOGICALNAME_INVALID.

hubport→get_module()
hubport→module()
hubport.get_module()hubport→get_module()[hubport module]hubport.get_module()hubport.get_module()hubport.get_module()hubport.get_module()hubport.get_module()hubport.get_module()hubport→get_module()hubport.get_module()

Gets the YModule object for the device on which the function is located.

js
function get_module()
cpp
YModule * get_module()
m
-(YModule*) module
pas
TYModule get_module(): TYModule
vb
function get_module() As YModule
cs
YModule get_module()
dnp
YModuleProxy get_module()
java
YModule get_module()
py
get_module()
php
function get_module()
es
async get_module()

If the function cannot be located on any module, the returned instance of YModule is not shown as on-line.

Returns :

an instance of YModule

hubport→get_module_async()
hubport→module_async()
hubport.get_module_async()

Gets the YModule object for the device on which the function is located (asynchronous version).

js
function get_module_async(callback, context)

If the function cannot be located on any module, the returned YModule object does not show as on-line.

This asynchronous version exists only in JavaScript. It uses a callback instead of a return value in order to avoid blocking Firefox JavaScript VM that does not implement context switching during blocking I/O calls. See the documentation section on asynchronous JavasSript calls for more details.

Parameters :

callbackcallback function that is invoked when the result is known. The callback function receives three arguments: the caller-specific context object, the receiving function object and the requested YModule object
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing : the result is provided to the callback.

hubport→get_portState()
hubport→portState()
hubport.get_portState()hubport→get_portState()[hubport portState]hubport.get_portState()hubport.get_portState()hubport.get_portState()hubport.get_portState()hubport.get_portState()hubport.get_portState()hubport.get_portState()hubport→get_portState()hubport.get_portState()YHubPort get_portState

Returns the current state of the YoctoHub port.

js
function get_portState()
cpp
Y_PORTSTATE_enum get_portState()
m
-(Y_PORTSTATE_enum) portState
pas
Integer get_portState(): Integer
vb
function get_portState() As Integer
cs
int get_portState()
dnp
int get_portState()
java
int get_portState()
uwp
async Task<int> get_portState()
py
get_portState()
php
function get_portState()
es
async get_portState()
cmd
YHubPort target get_portState

Returns :

a value among Y_PORTSTATE_OFF, Y_PORTSTATE_OVRLD, Y_PORTSTATE_ON, Y_PORTSTATE_RUN and Y_PORTSTATE_PROG corresponding to the current state of the YoctoHub port

On failure, throws an exception or returns Y_PORTSTATE_INVALID.

hubport→get_serialNumber()
hubport→serialNumber()
hubport.get_serialNumber()hubport→get_serialNumber()[hubport serialNumber]hubport.get_serialNumber()hubport.get_serialNumber()hubport.get_serialNumber()hubport.get_serialNumber()hubport.get_serialNumber()hubport.get_serialNumber()hubport.get_serialNumber()hubport→get_serialNumber()hubport.get_serialNumber()YHubPort get_serialNumber

Returns the serial number of the module, as set by the factory.

js
function get_serialNumber()
cpp
string get_serialNumber()
m
-(NSString*) serialNumber
pas
string get_serialNumber(): string
vb
function get_serialNumber() As String
cs
string get_serialNumber()
dnp
string get_serialNumber()
java
String get_serialNumber()
uwp
async Task<string> get_serialNumber()
py
get_serialNumber()
php
function get_serialNumber()
es
async get_serialNumber()
cmd
YHubPort target get_serialNumber

Returns :

a string corresponding to the serial number of the module, as set by the factory.

On failure, throws an exception or returns YModule.SERIALNUMBER_INVALID.

hubport→get_userData()
hubport→userData()
hubport.get_userData()hubport→get_userData()[hubport userData]hubport.get_userData()hubport.get_userData()hubport.get_userData()hubport.get_userData()hubport.get_userData()hubport→get_userData()hubport.get_userData()

Returns the value of the userData attribute, as previously stored using method set_userData.

js
function get_userData()
cpp
void * get_userData()
m
-(id) userData
pas
Tobject get_userData(): Tobject
vb
function get_userData() As Object
cs
object get_userData()
java
Object get_userData()
py
get_userData()
php
function get_userData()
es
async get_userData()

This attribute is never touched directly by the API, and is at disposal of the caller to store a context.

Returns :

the object stored previously by the caller.

hubport→isOnline()hubport.isOnline()hubport→isOnline()[hubport isOnline]hubport.isOnline()hubport.isOnline()hubport.isOnline()hubport.isOnline()hubport.isOnline()hubport.isOnline()hubport→isOnline()hubport.isOnline()

Checks if the YoctoHub slave port is currently reachable, without raising any error.

js
function isOnline()
cpp
bool isOnline()
m
-(BOOL) isOnline
pas
boolean isOnline(): boolean
vb
function isOnline() As Boolean
cs
bool isOnline()
dnp
bool isOnline()
java
boolean isOnline()
py
isOnline()
php
function isOnline()
es
async isOnline()

If there is a cached value for the YoctoHub slave port in cache, that has not yet expired, the device is considered reachable. No exception is raised if there is an error while trying to contact the device hosting the YoctoHub slave port.

Returns :

true if the YoctoHub slave port can be reached, and false otherwise

hubport→isOnline_async()hubport.isOnline_async()

Checks if the YoctoHub slave port is currently reachable, without raising any error (asynchronous version).

js
function isOnline_async(callback, context)

If there is a cached value for the YoctoHub slave port in cache, that has not yet expired, the device is considered reachable. No exception is raised if there is an error while trying to contact the device hosting the requested function.

This asynchronous version exists only in Javascript. It uses a callback instead of a return value in order to avoid blocking the Javascript virtual machine.

Parameters :

callbackcallback function that is invoked when the result is known. The callback function receives three arguments: the caller-specific context object, the receiving function object and the boolean result
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing : the result is provided to the callback.

hubport→isReadOnly()hubport→isReadOnly()[hubport isReadOnly]hubport.isReadOnly()hubport.isReadOnly()hubport.isReadOnly()hubport.isReadOnly()hubport.isReadOnly()hubport.isReadOnly()hubport.isReadOnly()hubport→isReadOnly()hubport.isReadOnly()YHubPort isReadOnly

Test if the function is readOnly.

cpp
bool isReadOnly()
m
-(bool) isReadOnly
pas
boolean isReadOnly(): boolean
vb
function isReadOnly() As Boolean
cs
bool isReadOnly()
dnp
bool isReadOnly()
java
boolean isReadOnly()
uwp
async Task<bool> isReadOnly()
py
isReadOnly()
php
function isReadOnly()
es
async isReadOnly()
cmd
YHubPort target isReadOnly

Return true if the function is write protected or that the function is not available.

Returns :

true if the function is readOnly or not online.

hubport→load()hubport.load()hubport→load()[hubport load: ]hubport.load()hubport.load()hubport.load()hubport.load()hubport.load()hubport→load()hubport.load()

Preloads the YoctoHub slave port cache with a specified validity duration.

js
function load(msValidity)
cpp
YRETCODE load(int msValidity)
m
-(YRETCODE) load: (u64) msValidity
pas
YRETCODE load(msValidity: u64): YRETCODE
vb
function load(ByVal msValidity As Long) As YRETCODE
cs
YRETCODE load(ulong msValidity)
java
int load(long msValidity)
py
load(msValidity)
php
function load($msValidity)
es
async load(msValidity)

By default, whenever accessing a device, all function attributes are kept in cache for the standard duration (5 ms). This method can be used to temporarily mark the cache as valid for a longer period, in order to reduce network traffic for instance.

Parameters :

msValidityan integer corresponding to the validity attributed to the loaded function parameters, in milliseconds

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

hubport→loadAttribute()hubport.loadAttribute()hubport→loadAttribute()[hubport loadAttribute: ]hubport.loadAttribute()hubport.loadAttribute()hubport.loadAttribute()hubport.loadAttribute()hubport.loadAttribute()hubport.loadAttribute()hubport.loadAttribute()hubport→loadAttribute()hubport.loadAttribute()

Returns the current value of a single function attribute, as a text string, as quickly as possible but without using the cached value.

js
function loadAttribute(attrName)
cpp
string loadAttribute(string attrName)
m
-(NSString*) loadAttribute: (NSString*) attrName
pas
string loadAttribute(attrName: string): string
vb
function loadAttribute() As String
cs
string loadAttribute(string attrName)
dnp
string loadAttribute(string attrName)
java
String loadAttribute(String attrName)
uwp
async Task<string> loadAttribute(string attrName)
py
loadAttribute(attrName)
php
function loadAttribute($attrName)
es
async loadAttribute(attrName)

Parameters :

attrNamethe name of the requested attribute

Returns :

a string with the value of the the attribute

On failure, throws an exception or returns an empty string.

hubport→load_async()hubport.load_async()

Preloads the YoctoHub slave port cache with a specified validity duration (asynchronous version).

js
function load_async(msValidity, callback, context)

By default, whenever accessing a device, all function attributes are kept in cache for the standard duration (5 ms). This method can be used to temporarily mark the cache as valid for a longer period, in order to reduce network traffic for instance.

This asynchronous version exists only in JavaScript. It uses a callback instead of a return value in order to avoid blocking the JavaScript virtual machine.

Parameters :

msValidityan integer corresponding to the validity of the loaded function parameters, in milliseconds
callbackcallback function that is invoked when the result is known. The callback function receives three arguments: the caller-specific context object, the receiving function object and the error code (or YAPI_SUCCESS)
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing : the result is provided to the callback.

hubport→muteValueCallbacks()hubport.muteValueCallbacks()hubport→muteValueCallbacks()[hubport muteValueCallbacks]hubport.muteValueCallbacks()hubport.muteValueCallbacks()hubport.muteValueCallbacks()hubport.muteValueCallbacks()hubport.muteValueCallbacks()hubport.muteValueCallbacks()hubport.muteValueCallbacks()hubport→muteValueCallbacks()hubport.muteValueCallbacks()YHubPort muteValueCallbacks

Disables the propagation of every new advertised value to the parent hub.

js
function muteValueCallbacks()
cpp
int muteValueCallbacks()
m
-(int) muteValueCallbacks
pas
LongInt muteValueCallbacks(): LongInt
vb
function muteValueCallbacks() As Integer
cs
int muteValueCallbacks()
dnp
int muteValueCallbacks()
java
int muteValueCallbacks()
uwp
async Task<int> muteValueCallbacks()
py
muteValueCallbacks()
php
function muteValueCallbacks()
es
async muteValueCallbacks()
cmd
YHubPort target muteValueCallbacks

You can use this function to save bandwidth and CPU on computers with limited resources, or to prevent unwanted invocations of the HTTP callback. Remember to call the saveToFlash() method of the module if the modification must be kept.

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

hubport→nextHubPort()hubport.nextHubPort()hubport→nextHubPort()[hubport nextHubPort]hubport.nextHubPort()hubport.nextHubPort()hubport.nextHubPort()hubport.nextHubPort()hubport.nextHubPort()hubport.nextHubPort()hubport→nextHubPort()hubport.nextHubPort()

Continues the enumeration of YoctoHub slave ports started using yFirstHubPort().

js
function nextHubPort()
cpp
YHubPort * nextHubPort()
m
-(YHubPort*) nextHubPort
pas
TYHubPort nextHubPort(): TYHubPort
vb
function nextHubPort() As YHubPort
cs
YHubPort nextHubPort()
java
YHubPort nextHubPort()
uwp
YHubPort nextHubPort()
py
nextHubPort()
php
function nextHubPort()
es
nextHubPort()

Caution: You can't make any assumption about the returned YoctoHub slave ports order. If you want to find a specific a YoctoHub slave port, use HubPort.findHubPort() and a hardwareID or a logical name.

Returns :

a pointer to a YHubPort object, corresponding to a YoctoHub slave port currently online, or a null pointer if there are no more YoctoHub slave ports to enumerate.

hubport→registerValueCallback()hubport.registerValueCallback()hubport→registerValueCallback()[hubport registerValueCallback: ]hubport.registerValueCallback()hubport.registerValueCallback()hubport.registerValueCallback()hubport.registerValueCallback()hubport.registerValueCallback()hubport.registerValueCallback()hubport→registerValueCallback()hubport.registerValueCallback()

Registers the callback function that is invoked on every change of advertised value.

js
function registerValueCallback(callback)
cpp
int registerValueCallback(YHubPortValueCallback callback)
m
-(int) registerValueCallback: (YHubPortValueCallback) callback
pas
LongInt registerValueCallback(callback: TYHubPortValueCallback): LongInt
vb
function registerValueCallback() As Integer
cs
int registerValueCallback(ValueCallback callback)
java
int registerValueCallback(UpdateCallback callback)
uwp
async Task<int> registerValueCallback(ValueCallback callback)
py
registerValueCallback(callback)
php
function registerValueCallback($callback)
es
async registerValueCallback(callback)

The callback is invoked only during the execution of ySleep or yHandleEvents. This provides control over the time when the callback is triggered. For good responsiveness, remember to call one of these two functions periodically. To unregister a callback, pass a null pointer as argument.

Parameters :

callbackthe callback function to call, or a null pointer. The callback function should take two arguments: the function object of which the value has changed, and the character string describing the new advertised value.

hubport→set_enabled()
hubport→setEnabled()
hubport.set_enabled()hubport→set_enabled()[hubport setEnabled: ]hubport.set_enabled()hubport.set_enabled()hubport.set_enabled()hubport.set_enabled()hubport.set_enabled()hubport.set_enabled()hubport.set_enabled()hubport→set_enabled()hubport.set_enabled()YHubPort set_enabled

Changes the activation of the YoctoHub port.

js
function set_enabled(newval)
cpp
int set_enabled(Y_ENABLED_enum newval)
m
-(int) setEnabled: (Y_ENABLED_enum) newval
pas
integer set_enabled(newval: Integer): integer
vb
function set_enabled(ByVal newval As Integer) As Integer
cs
int set_enabled(int newval)
dnp
int set_enabled(int newval)
java
int set_enabled(int newval)
uwp
async Task<int> set_enabled(int newval)
py
set_enabled(newval)
php
function set_enabled($newval)
es
async set_enabled(newval)
cmd
YHubPort target set_enabled newval

If the port is enabled, the connected module is powered. Otherwise, port power is shut down.

Parameters :

newvaleither Y_ENABLED_FALSE or Y_ENABLED_TRUE, according to the activation of the YoctoHub port

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

hubport→set_logicalName()
hubport→setLogicalName()
hubport.set_logicalName()hubport→set_logicalName()[hubport setLogicalName: ]hubport.set_logicalName()hubport.set_logicalName()hubport.set_logicalName()hubport.set_logicalName()hubport.set_logicalName()hubport.set_logicalName()hubport.set_logicalName()hubport→set_logicalName()hubport.set_logicalName()YHubPort set_logicalName

Changes the logical name of the YoctoHub slave port.

js
function set_logicalName(newval)
cpp
int set_logicalName(string newval)
m
-(int) setLogicalName: (NSString*) newval
pas
integer set_logicalName(newval: string): integer
vb
function set_logicalName(ByVal newval As String) As Integer
cs
int set_logicalName(string newval)
dnp
int set_logicalName(string newval)
java
int set_logicalName(String newval)
uwp
async Task<int> set_logicalName(string newval)
py
set_logicalName(newval)
php
function set_logicalName($newval)
es
async set_logicalName(newval)
cmd
YHubPort target set_logicalName newval

You can use yCheckLogicalName() prior to this call to make sure that your parameter is valid. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string corresponding to the logical name of the YoctoHub slave port.

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

hubport→set_userData()
hubport→setUserData()
hubport.set_userData()hubport→set_userData()[hubport setUserData: ]hubport.set_userData()hubport.set_userData()hubport.set_userData()hubport.set_userData()hubport.set_userData()hubport→set_userData()hubport.set_userData()

Stores a user context provided as argument in the userData attribute of the function.

js
function set_userData(data)
cpp
void set_userData(void * data)
m
-(void) setUserData: (id) data
pas
set_userData(data: Tobject)
vb
procedure set_userData(ByVal data As Object)
cs
void set_userData(object data)
java
void set_userData(Object data)
py
set_userData(data)
php
function set_userData($data)
es
async set_userData(data)

This attribute is never touched by the API, and is at disposal of the caller to store a context.

Parameters :

dataany kind of object to be stored

hubport→unmuteValueCallbacks()hubport.unmuteValueCallbacks()hubport→unmuteValueCallbacks()[hubport unmuteValueCallbacks]hubport.unmuteValueCallbacks()hubport.unmuteValueCallbacks()hubport.unmuteValueCallbacks()hubport.unmuteValueCallbacks()hubport.unmuteValueCallbacks()hubport.unmuteValueCallbacks()hubport.unmuteValueCallbacks()hubport→unmuteValueCallbacks()hubport.unmuteValueCallbacks()YHubPort unmuteValueCallbacks

Re-enables the propagation of every new advertised value to the parent hub.

js
function unmuteValueCallbacks()
cpp
int unmuteValueCallbacks()
m
-(int) unmuteValueCallbacks
pas
LongInt unmuteValueCallbacks(): LongInt
vb
function unmuteValueCallbacks() As Integer
cs
int unmuteValueCallbacks()
dnp
int unmuteValueCallbacks()
java
int unmuteValueCallbacks()
uwp
async Task<int> unmuteValueCallbacks()
py
unmuteValueCallbacks()
php
function unmuteValueCallbacks()
es
async unmuteValueCallbacks()
cmd
YHubPort target unmuteValueCallbacks

This function reverts the effect of a previous call to muteValueCallbacks(). Remember to call the saveToFlash() method of the module if the modification must be kept.

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

hubport→wait_async()hubport.wait_async()hubport.wait_async()

Waits for all pending asynchronous commands on the module to complete, and invoke the user-provided callback function.

js
function wait_async(callback, context)
es
wait_async(callback, context)

The callback function can therefore freely issue synchronous or asynchronous commands, without risking to block the JavaScript VM.

Parameters :

callbackcallback function that is invoked when all pending commands on the module are completed. The callback function receives two arguments: the caller-specific context object and the receiving function object.
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing.

8.2. Class YCellular

Cellular interface control interface, available for instance in the YoctoHub-GSM-2G, the YoctoHub-GSM-3G-EU or the YoctoHub-GSM-3G-NA

The YCellular class provides control over cellular network parameters and status for devices that are GSM-enabled. Note that TCP/IP parameters are configured separately, using class YNetwork.

In order to use the functions described here, you should include:

js
<script type='text/javascript' src='yocto_cellular.js'></script>
cpp
#include "yocto_cellular.h"
m
#import "yocto_cellular.h"
pas
uses yocto_cellular;
vb
yocto_cellular.vb
cs
yocto_cellular.cs
dnp
import YoctoProxyAPI.YCellularProxy
java
import com.yoctopuce.YoctoAPI.YCellular;
uwp
import com.yoctopuce.YoctoAPI.YCellular;
py
from yocto_cellular import *
php
require_once('yocto_cellular.php');
es
in HTML: <script src="../../lib/yocto_cellular.js"></script>
in node.js: require('yoctolib-es2017/yocto_cellular.js');
vi
YCellular.vi
Global functions
YCellular.FindCellular(func)

Retrieves a cellular interface for a given identifier.

YCellular.FindCellularInContext(yctx, func)

Retrieves a cellular interface for a given identifier in a YAPI context.

YCellular.FirstCellular()

Starts the enumeration of cellular interfaces currently accessible.

YCellular.FirstCellularInContext(yctx)

Starts the enumeration of cellular interfaces currently accessible.

YCellular.GetSimilarFunctions()

Enumerates all functions of type Cellular available on the devices currently reachable by the library, and returns their unique hardware ID.

YCellular properties
cellular→AdvertisedValue [read-only]

Short string representing the current state of the function.

cellular→Apn [writable]

Access Point Name (APN) to be used, if needed.

cellular→EnableData [writable]

Condition for enabling IP data services (GPRS).

cellular→FriendlyName [read-only]

Global identifier of the function in the format MODULE_NAME.FUNCTION_NAME.

cellular→FunctionId [read-only]

Hardware identifier of the cellular interface, without reference to the module.

cellular→HardwareId [read-only]

Unique hardware identifier of the function in the form SERIAL.FUNCTIONID.

cellular→IsOnline [read-only]

Checks if the function is currently reachable.

cellular→LockedOperator [writable]

Name of the only cell operator to use if automatic choice is disabled, or an empty string if the SIM card will automatically choose among available cell operators.

cellular→LogicalName [writable]

Logical name of the function.

cellular→Pin [writable]

N opaque string if a PIN code has been configured in the device to access the SIM card, or an empty string if none has been configured or if the code provided was rejected by the SIM card.

cellular→PingInterval [writable]

Automated connectivity check interval, in seconds.

cellular→SerialNumber [read-only]

Serial number of the module, as set by the factory.

YCellular methods
cellular→_AT(cmd)

Sends an AT command to the GSM module and returns the command output.

cellular→clearCache()

Invalidates the cache.

cellular→clearDataCounters()

Clear the transmitted data counters.

cellular→describe()

Returns a short text that describes unambiguously the instance of the cellular interface in the form TYPE(NAME)=SERIAL.FUNCTIONID.

cellular→get_advertisedValue()

Returns the current value of the cellular interface (no more than 6 characters).

cellular→get_airplaneMode()

Returns true if the airplane mode is active (radio turned off).

cellular→get_apn()

Returns the Access Point Name (APN) to be used, if needed.

cellular→get_apnSecret()

Returns an opaque string if APN authentication parameters have been configured in the device, or an empty string otherwise.

cellular→get_availableOperators()

Returns the list detected cell operators in the neighborhood.

cellular→get_cellIdentifier()

Returns the unique identifier of the cellular antenna in use: MCC, MNC, LAC and Cell ID.

cellular→get_cellOperator()

Returns the name of the cell operator currently in use.

cellular→get_cellType()

Active cellular connection type.

cellular→get_dataReceived()

Returns the number of bytes received so far.

cellular→get_dataSent()

Returns the number of bytes sent so far.

cellular→get_enableData()

Returns the condition for enabling IP data services (GPRS).

cellular→get_errorMessage()

Returns the error message of the latest error with the cellular interface.

cellular→get_errorType()

Returns the numerical error code of the latest error with the cellular interface.

cellular→get_friendlyName()

Returns a global identifier of the cellular interface in the format MODULE_NAME.FUNCTION_NAME.

cellular→get_functionDescriptor()

Returns a unique identifier of type YFUN_DESCR corresponding to the function.

cellular→get_functionId()

Returns the hardware identifier of the cellular interface, without reference to the module.

cellular→get_hardwareId()

Returns the unique hardware identifier of the cellular interface in the form SERIAL.FUNCTIONID.

cellular→get_imsi()

Returns an opaque string if a PIN code has been configured in the device to access the SIM card, or an empty string if none has been configured or if the code provided was rejected by the SIM card.

cellular→get_linkQuality()

Returns the link quality, expressed in percent.

cellular→get_lockedOperator()

Returns the name of the only cell operator to use if automatic choice is disabled, or an empty string if the SIM card will automatically choose among available cell operators.

cellular→get_logicalName()

Returns the logical name of the cellular interface.

cellular→get_message()

Returns the latest status message from the wireless interface.

cellular→get_module()

Gets the YModule object for the device on which the function is located.

cellular→get_module_async(callback, context)

Gets the YModule object for the device on which the function is located (asynchronous version).

cellular→get_pin()

Returns an opaque string if a PIN code has been configured in the device to access the SIM card, or an empty string if none has been configured or if the code provided was rejected by the SIM card.

cellular→get_pingInterval()

Returns the automated connectivity check interval, in seconds.

cellular→get_serialNumber()

Returns the serial number of the module, as set by the factory.

cellular→get_userData()

Returns the value of the userData attribute, as previously stored using method set_userData.

cellular→isOnline()

Checks if the cellular interface is currently reachable, without raising any error.

cellular→isOnline_async(callback, context)

Checks if the cellular interface is currently reachable, without raising any error (asynchronous version).

cellular→isReadOnly()

Test if the function is readOnly.

cellular→load(msValidity)

Preloads the cellular interface cache with a specified validity duration.

cellular→loadAttribute(attrName)

Returns the current value of a single function attribute, as a text string, as quickly as possible but without using the cached value.

cellular→load_async(msValidity, callback, context)

Preloads the cellular interface cache with a specified validity duration (asynchronous version).

cellular→muteValueCallbacks()

Disables the propagation of every new advertised value to the parent hub.

cellular→nextCellular()

Continues the enumeration of cellular interfaces started using yFirstCellular().

cellular→quickCellSurvey()

Returns a list of nearby cellular antennas, as required for quick geolocation of the device.

cellular→registerValueCallback(callback)

Registers the callback function that is invoked on every change of advertised value.

cellular→sendPUK(puk, newPin)

Sends a PUK code to unlock the SIM card after three failed PIN code attempts, and setup a new PIN into the SIM card.

cellular→set_airplaneMode(newval)

Changes the activation state of airplane mode (radio turned off).

cellular→set_apn(newval)

Returns the Access Point Name (APN) to be used, if needed.

cellular→set_apnAuth(username, password)

Configure authentication parameters to connect to the APN.

cellular→set_dataReceived(newval)

Changes the value of the incoming data counter.

cellular→set_dataSent(newval)

Changes the value of the outgoing data counter.

cellular→set_enableData(newval)

Changes the condition for enabling IP data services (GPRS).

cellular→set_lockedOperator(newval)

Changes the name of the cell operator to be used.

cellular→set_logicalName(newval)

Changes the logical name of the cellular interface.

cellular→set_pin(newval)

Changes the PIN code used by the module to access the SIM card.

cellular→set_pingInterval(newval)

Changes the automated connectivity check interval, in seconds.

cellular→set_userData(data)

Stores a user context provided as argument in the userData attribute of the function.

cellular→unmuteValueCallbacks()

Re-enables the propagation of every new advertised value to the parent hub.

cellular→wait_async(callback, context)

Waits for all pending asynchronous commands on the module to complete, and invoke the user-provided callback function.

YCellular.FindCellular()
YCellular.FindCellular()
yFindCellular()yFindCellular()[YCellular FindCellular: ]yFindCellular()yFindCellular()YCellular.FindCellular()YCellular.FindCellular()YCellular.FindCellular()YCellular.FindCellular()YCellular.FindCellular()yFindCellular()YCellular.FindCellular()

Retrieves a cellular interface for a given identifier.

js
function yFindCellular(func)
cpp
YCellular* yFindCellular(string func)
m
+(YCellular*) FindCellular: (NSString*) func
pas
TYCellular yFindCellular(func: string): TYCellular
vb
function yFindCellular(ByVal func As String) As YCellular
cs
static YCellular FindCellular(string func)
dnp
static YCellularProxy FindCellular(string func)
java
static YCellular FindCellular(String func)
uwp
static YCellular FindCellular(string func)
py
FindCellular(func)
php
function yFindCellular($func)
es
static FindCellular(func)

The identifier can be specified using several formats:

This function does not require that the cellular interface is online at the time it is invoked. The returned object is nevertheless valid. Use the method YCellular.isOnline() to test if the cellular interface is indeed online at a given time. In case of ambiguity when looking for a cellular interface by logical name, no error is notified: the first instance found is returned. The search is performed first by hardware name, then by logical name.

If a call to this object's is_online() method returns FALSE although you are certain that the matching device is plugged, make sure that you did call registerHub() at application initialization time.

Parameters :

funca string that uniquely characterizes the cellular interface, for instance YHUBGSM1.cellular.

Returns :

a YCellular object allowing you to drive the cellular interface.

YCellular.FindCellularInContext()
YCellular.FindCellularInContext()
YCellular.FindCellularInContext()YCellular.FindCellularInContext()YCellular.FindCellularInContext()

Retrieves a cellular interface for a given identifier in a YAPI context.

java
static YCellular FindCellularInContext(YAPIContext yctx, String func)
uwp
static YCellular FindCellularInContext(YAPIContext yctx, string func)
es
static FindCellularInContext(yctx, func)

The identifier can be specified using several formats:

This function does not require that the cellular interface is online at the time it is invoked. The returned object is nevertheless valid. Use the method YCellular.isOnline() to test if the cellular interface is indeed online at a given time. In case of ambiguity when looking for a cellular interface by logical name, no error is notified: the first instance found is returned. The search is performed first by hardware name, then by logical name.

Parameters :

yctxa YAPI context
funca string that uniquely characterizes the cellular interface, for instance YHUBGSM1.cellular.

Returns :

a YCellular object allowing you to drive the cellular interface.

YCellular.FirstCellular()
YCellular.FirstCellular()
yFirstCellular()yFirstCellular()[YCellular FirstCellular]yFirstCellular()yFirstCellular()YCellular.FirstCellular()YCellular.FirstCellular()YCellular.FirstCellular()YCellular.FirstCellular()yFirstCellular()YCellular.FirstCellular()

Starts the enumeration of cellular interfaces currently accessible.

js
function yFirstCellular()
cpp
YCellular * yFirstCellular()
m
+(YCellular*) FirstCellular
pas
TYCellular yFirstCellular(): TYCellular
vb
function yFirstCellular() As YCellular
cs
static YCellular FirstCellular()
java
static YCellular FirstCellular()
uwp
static YCellular FirstCellular()
py
FirstCellular()
php
function yFirstCellular()
es
static FirstCellular()

Use the method YCellular.nextCellular() to iterate on next cellular interfaces.

Returns :

a pointer to a YCellular object, corresponding to the first cellular interface currently online, or a null pointer if there are none.

YCellular.FirstCellularInContext()
YCellular.FirstCellularInContext()
YCellular.FirstCellularInContext()YCellular.FirstCellularInContext()YCellular.FirstCellularInContext()

Starts the enumeration of cellular interfaces currently accessible.

java
static YCellular FirstCellularInContext(YAPIContext yctx)
uwp
static YCellular FirstCellularInContext(YAPIContext yctx)
es
static FirstCellularInContext(yctx)

Use the method YCellular.nextCellular() to iterate on next cellular interfaces.

Parameters :

yctxa YAPI context.

Returns :

a pointer to a YCellular object, corresponding to the first cellular interface currently online, or a null pointer if there are none.

YCellular.GetSimilarFunctions()
YCellular.GetSimilarFunctions()
YCellular.GetSimilarFunctions()

Enumerates all functions of type Cellular available on the devices currently reachable by the library, and returns their unique hardware ID.

dnp
static new string[] GetSimilarFunctions()

Each of these IDs can be provided as argument to the method YCellular.FindCellular to obtain an object that can control the corresponding device.

Returns :

an array of strings, each string containing the unique hardwareId of a device function currently connected.

cellular→AdvertisedValuecellular.AdvertisedValue

Short string representing the current state of the function.

dnp
string AdvertisedValue

cellular→Apncellular.Apn

Access Point Name (APN) to be used, if needed.

dnp
string Apn

When left blank, the APN suggested by the cell operator will be used.

Writable. Returns the Access Point Name (APN) to be used, if needed. When left blank, the APN suggested by the cell operator will be used. Remember to call the saveToFlash() method of the module if the modification must be kept.

cellular→EnableDatacellular.EnableData

Condition for enabling IP data services (GPRS).

dnp
int EnableData

When data services are disabled, SMS are the only mean of communication.

Possible values:

Y_ENABLEDATA_INVALID = 0
Y_ENABLEDATA_HOMENETWORK = 1
Y_ENABLEDATA_ROAMING = 2
Y_ENABLEDATA_NEVER = 3
Y_ENABLEDATA_NEUTRALITY = 4

Writable. The service can be either fully deactivated, or limited to the SIM home network, or enabled for all partner networks (roaming). Caution: enabling data services on roaming networks may cause prohibitive communication costs !

When data services are disabled, SMS are the only mean of communication. Remember to call the saveToFlash() method of the module if the modification must be kept.

cellular→FriendlyNamecellular.FriendlyName

Global identifier of the function in the format MODULE_NAME.FUNCTION_NAME.

dnp
string FriendlyName

The returned string uses the logical names of the module and of the function if they are defined, otherwise the serial number of the module and the hardware identifier of the function (for example: MyCustomName.relay1)

cellular→FunctionIdcellular.FunctionId

Hardware identifier of the cellular interface, without reference to the module.

dnp
string FunctionId

For example relay1

cellular→HardwareIdcellular.HardwareId

Unique hardware identifier of the function in the form SERIAL.FUNCTIONID.

dnp
string HardwareId

The unique hardware identifier is composed of the device serial number and of the hardware identifier of the function (for example RELAYLO1-123456.relay1).

cellular→IsOnlinecellular.IsOnline

Checks if the function is currently reachable.

dnp
bool IsOnline

If there is a cached value for the function in cache, that has not yet expired, the device is considered reachable. No exception is raised if there is an error while trying to contact the device hosting the function.

cellular→LockedOperatorcellular.LockedOperator

Name of the only cell operator to use if automatic choice is disabled, or an empty string if the SIM card will automatically choose among available cell operators.

dnp
string LockedOperator

Writable. Changes the name of the cell operator to be used. If the name is an empty string, the choice will be made automatically based on the SIM card. Otherwise, the selected operator is the only one that will be used. Remember to call the saveToFlash() method of the module if the modification must be kept.

cellular→LogicalNamecellular.LogicalName

Logical name of the function.

dnp
string LogicalName

Writable. You can use yCheckLogicalName() prior to this call to make sure that your parameter is valid. Remember to call the saveToFlash() method of the module if the modification must be kept.

cellular→Pincellular.Pin

N opaque string if a PIN code has been configured in the device to access the SIM card, or an empty string if none has been configured or if the code provided was rejected by the SIM card.

dnp
string Pin

Writable. Changes the PIN code used by the module to access the SIM card. This function does not change the code on the SIM card itself, but only changes the parameter used by the device to try to get access to it. If the SIM code does not work immediately on first try, it will be automatically forgotten and the message will be set to "Enter SIM PIN". The method should then be invoked again with right correct PIN code. After three failed attempts in a row, the message is changed to "Enter SIM PUK" and the SIM card PUK code must be provided using method sendPUK.

Remember to call the saveToFlash() method of the module to save the new value in the device flash.

cellular→PingIntervalcellular.PingInterval

Automated connectivity check interval, in seconds.

dnp
int PingInterval

Writable. Remember to call the saveToFlash() method of the module if the modification must be kept.

cellular→SerialNumbercellular.SerialNumber

Serial number of the module, as set by the factory.

dnp
string SerialNumber

cellular→_AT()cellular→_AT()[cellular _AT: ]cellular._AT()cellular._AT()cellular._AT()cellular._AT()cellular._AT()cellular._AT()cellular._AT()cellular→_AT()cellular._AT()YCellular _AT

Sends an AT command to the GSM module and returns the command output.

cpp
string _AT(string cmd)
m
-(NSString*) _AT: (NSString*) cmd
pas
string _AT(cmd: string): string
vb
function _AT() As String
cs
string _AT(string cmd)
dnp
string _AT(string cmd)
java
String _AT(String cmd)
uwp
async Task<string> _AT(string cmd)
py
_AT(cmd)
php
function _AT($cmd)
es
async _AT(cmd)
cmd
YCellular target _AT cmd

The command will only execute when the GSM module is in standard command state, and should leave it in the exact same state. Use this function with great care !

Parameters :

cmdthe AT command to execute, like for instance: "+CCLK?".

Returns :

a string with the result of the commands. Empty lines are automatically removed from the output.

cellular→clearCache()cellular.clearCache()cellular→clearCache()[cellular clearCache]cellular.clearCache()cellular.clearCache()cellular.clearCache()cellular.clearCache()cellular.clearCache()cellular→clearCache()cellular.clearCache()

Invalidates the cache.

js
function clearCache()
cpp
void clearCache()
m
-(void) clearCache
pas
clearCache()
vb
procedure clearCache()
cs
void clearCache()
java
void clearCache()
py
clearCache()
php
function clearCache()
es
async clearCache()

Invalidates the cache of the cellular interface attributes. Forces the next call to get_xxx() or loadxxx() to use values that come from the device.

cellular→clearDataCounters()cellular.clearDataCounters()cellular→clearDataCounters()[cellular clearDataCounters]cellular.clearDataCounters()cellular.clearDataCounters()cellular.clearDataCounters()cellular.clearDataCounters()cellular.clearDataCounters()cellular.clearDataCounters()cellular.clearDataCounters()cellular→clearDataCounters()cellular.clearDataCounters()YCellular clearDataCounters

Clear the transmitted data counters.

js
function clearDataCounters()
cpp
int clearDataCounters()
m
-(int) clearDataCounters
pas
LongInt clearDataCounters(): LongInt
vb
function clearDataCounters() As Integer
cs
int clearDataCounters()
dnp
int clearDataCounters()
java
int clearDataCounters()
uwp
async Task<int> clearDataCounters()
py
clearDataCounters()
php
function clearDataCounters()
es
async clearDataCounters()
cmd
YCellular target clearDataCounters

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→describe()cellular.describe()cellular→describe()[cellular describe]cellular.describe()cellular.describe()cellular.describe()cellular.describe()cellular.describe()cellular→describe()cellular.describe()

Returns a short text that describes unambiguously the instance of the cellular interface in the form TYPE(NAME)=SERIAL.FUNCTIONID.

js
function describe()
cpp
string describe()
m
-(NSString*) describe
pas
string describe(): string
vb
function describe() As String
cs
string describe()
java
String describe()
py
describe()
php
function describe()
es
async describe()

More precisely, TYPE is the type of the function, NAME it the name used for the first access to the function, SERIAL is the serial number of the module if the module is connected or "unresolved", and FUNCTIONID is the hardware identifier of the function if the module is connected. For example, this method returns Relay(MyCustomName.relay1)=RELAYLO1-123456.relay1 if the module is already connected or Relay(BadCustomeName.relay1)=unresolved if the module has not yet been connected. This method does not trigger any USB or TCP transaction and can therefore be used in a debugger.

Returns :

a string that describes the cellular interface (ex: Relay(MyCustomName.relay1)=RELAYLO1-123456.relay1)

cellular→get_advertisedValue()
cellular→advertisedValue()
cellular.get_advertisedValue()cellular→get_advertisedValue()[cellular advertisedValue]cellular.get_advertisedValue()cellular.get_advertisedValue()cellular.get_advertisedValue()cellular.get_advertisedValue()cellular.get_advertisedValue()cellular.get_advertisedValue()cellular.get_advertisedValue()cellular→get_advertisedValue()cellular.get_advertisedValue()YCellular get_advertisedValue

Returns the current value of the cellular interface (no more than 6 characters).

js
function get_advertisedValue()
cpp
string get_advertisedValue()
m
-(NSString*) advertisedValue
pas
string get_advertisedValue(): string
vb
function get_advertisedValue() As String
cs
string get_advertisedValue()
dnp
string get_advertisedValue()
java
String get_advertisedValue()
uwp
async Task<string> get_advertisedValue()
py
get_advertisedValue()
php
function get_advertisedValue()
es
async get_advertisedValue()
cmd
YCellular target get_advertisedValue

Returns :

a string corresponding to the current value of the cellular interface (no more than 6 characters).

On failure, throws an exception or returns Y_ADVERTISEDVALUE_INVALID.

cellular→get_airplaneMode()
cellular→airplaneMode()
cellular.get_airplaneMode()cellular→get_airplaneMode()[cellular airplaneMode]cellular.get_airplaneMode()cellular.get_airplaneMode()cellular.get_airplaneMode()cellular.get_airplaneMode()cellular.get_airplaneMode()cellular.get_airplaneMode()cellular.get_airplaneMode()cellular→get_airplaneMode()cellular.get_airplaneMode()YCellular get_airplaneMode

Returns true if the airplane mode is active (radio turned off).

js
function get_airplaneMode()
cpp
Y_AIRPLANEMODE_enum get_airplaneMode()
m
-(Y_AIRPLANEMODE_enum) airplaneMode
pas
Integer get_airplaneMode(): Integer
vb
function get_airplaneMode() As Integer
cs
int get_airplaneMode()
dnp
int get_airplaneMode()
java
int get_airplaneMode()
uwp
async Task<int> get_airplaneMode()
py
get_airplaneMode()
php
function get_airplaneMode()
es
async get_airplaneMode()
cmd
YCellular target get_airplaneMode

Returns :

either Y_AIRPLANEMODE_OFF or Y_AIRPLANEMODE_ON, according to true if the airplane mode is active (radio turned off)

On failure, throws an exception or returns Y_AIRPLANEMODE_INVALID.

cellular→get_apn()
cellular→apn()
cellular.get_apn()cellular→get_apn()[cellular apn]cellular.get_apn()cellular.get_apn()cellular.get_apn()cellular.get_apn()cellular.get_apn()cellular.get_apn()cellular.get_apn()cellular→get_apn()cellular.get_apn()YCellular get_apn

Returns the Access Point Name (APN) to be used, if needed.

js
function get_apn()
cpp
string get_apn()
m
-(NSString*) apn
pas
string get_apn(): string
vb
function get_apn() As String
cs
string get_apn()
dnp
string get_apn()
java
String get_apn()
uwp
async Task<string> get_apn()
py
get_apn()
php
function get_apn()
es
async get_apn()
cmd
YCellular target get_apn

When left blank, the APN suggested by the cell operator will be used.

Returns :

a string corresponding to the Access Point Name (APN) to be used, if needed

On failure, throws an exception or returns Y_APN_INVALID.

cellular→get_apnSecret()
cellular→apnSecret()
cellular.get_apnSecret()cellular→get_apnSecret()[cellular apnSecret]cellular.get_apnSecret()cellular.get_apnSecret()cellular.get_apnSecret()cellular.get_apnSecret()cellular.get_apnSecret()cellular.get_apnSecret()cellular.get_apnSecret()cellular→get_apnSecret()cellular.get_apnSecret()YCellular get_apnSecret

Returns an opaque string if APN authentication parameters have been configured in the device, or an empty string otherwise.

js
function get_apnSecret()
cpp
string get_apnSecret()
m
-(NSString*) apnSecret
pas
string get_apnSecret(): string
vb
function get_apnSecret() As String
cs
string get_apnSecret()
dnp
string get_apnSecret()
java
String get_apnSecret()
uwp
async Task<string> get_apnSecret()
py
get_apnSecret()
php
function get_apnSecret()
es
async get_apnSecret()
cmd
YCellular target get_apnSecret

To configure these parameters, use set_apnAuth().

Returns :

a string corresponding to an opaque string if APN authentication parameters have been configured in the device, or an empty string otherwise

On failure, throws an exception or returns Y_APNSECRET_INVALID.

cellular→get_availableOperators()
cellular→availableOperators()
cellular.get_availableOperators()cellular→get_availableOperators()[cellular availableOperators]cellular.get_availableOperators()cellular.get_availableOperators()cellular.get_availableOperators()cellular.get_availableOperators()cellular.get_availableOperators()cellular.get_availableOperators()cellular.get_availableOperators()cellular→get_availableOperators()cellular.get_availableOperators()YCellular get_availableOperators

Returns the list detected cell operators in the neighborhood.

js
function get_availableOperators()
cpp
vector<string> get_availableOperators()
m
-(NSMutableArray*) availableOperators
pas
TStringArray get_availableOperators(): TStringArray
vb
function get_availableOperators() As List
cs
List<string> get_availableOperators()
dnp
string[] get_availableOperators()
java
ArrayList<String> get_availableOperators()
uwp
async Task<List<string>> get_availableOperators()
py
get_availableOperators()
php
function get_availableOperators()
es
async get_availableOperators()
cmd
YCellular target get_availableOperators

This function will typically take between 30 seconds to 1 minute to return. Note that any SIM card can usually only connect to specific operators. All networks returned by this function might therefore not be available for connection.

Returns :

a list of string (cell operator names).

cellular→get_cellIdentifier()
cellular→cellIdentifier()
cellular.get_cellIdentifier()cellular→get_cellIdentifier()[cellular cellIdentifier]cellular.get_cellIdentifier()cellular.get_cellIdentifier()cellular.get_cellIdentifier()cellular.get_cellIdentifier()cellular.get_cellIdentifier()cellular.get_cellIdentifier()cellular.get_cellIdentifier()cellular→get_cellIdentifier()cellular.get_cellIdentifier()YCellular get_cellIdentifier

Returns the unique identifier of the cellular antenna in use: MCC, MNC, LAC and Cell ID.

js
function get_cellIdentifier()
cpp
string get_cellIdentifier()
m
-(NSString*) cellIdentifier
pas
string get_cellIdentifier(): string
vb
function get_cellIdentifier() As String
cs
string get_cellIdentifier()
dnp
string get_cellIdentifier()
java
String get_cellIdentifier()
uwp
async Task<string> get_cellIdentifier()
py
get_cellIdentifier()
php
function get_cellIdentifier()
es
async get_cellIdentifier()
cmd
YCellular target get_cellIdentifier

Returns :

a string corresponding to the unique identifier of the cellular antenna in use: MCC, MNC, LAC and Cell ID

On failure, throws an exception or returns Y_CELLIDENTIFIER_INVALID.

cellular→get_cellOperator()
cellular→cellOperator()
cellular.get_cellOperator()cellular→get_cellOperator()[cellular cellOperator]cellular.get_cellOperator()cellular.get_cellOperator()cellular.get_cellOperator()cellular.get_cellOperator()cellular.get_cellOperator()cellular.get_cellOperator()cellular.get_cellOperator()cellular→get_cellOperator()cellular.get_cellOperator()YCellular get_cellOperator

Returns the name of the cell operator currently in use.

js
function get_cellOperator()
cpp
string get_cellOperator()
m
-(NSString*) cellOperator
pas
string get_cellOperator(): string
vb
function get_cellOperator() As String
cs
string get_cellOperator()
dnp
string get_cellOperator()
java
String get_cellOperator()
uwp
async Task<string> get_cellOperator()
py
get_cellOperator()
php
function get_cellOperator()
es
async get_cellOperator()
cmd
YCellular target get_cellOperator

Returns :

a string corresponding to the name of the cell operator currently in use

On failure, throws an exception or returns Y_CELLOPERATOR_INVALID.

cellular→get_cellType()
cellular→cellType()
cellular.get_cellType()cellular→get_cellType()[cellular cellType]cellular.get_cellType()cellular.get_cellType()cellular.get_cellType()cellular.get_cellType()cellular.get_cellType()cellular.get_cellType()cellular.get_cellType()cellular→get_cellType()cellular.get_cellType()YCellular get_cellType

Active cellular connection type.

js
function get_cellType()
cpp
Y_CELLTYPE_enum get_cellType()
m
-(Y_CELLTYPE_enum) cellType
pas
Integer get_cellType(): Integer
vb
function get_cellType() As Integer
cs
int get_cellType()
dnp
int get_cellType()
java
int get_cellType()
uwp
async Task<int> get_cellType()
py
get_cellType()
php
function get_cellType()
es
async get_cellType()
cmd
YCellular target get_cellType

Returns :

a value among Y_CELLTYPE_GPRS, Y_CELLTYPE_EGPRS, Y_CELLTYPE_WCDMA, Y_CELLTYPE_HSDPA, Y_CELLTYPE_NONE and Y_CELLTYPE_CDMA

On failure, throws an exception or returns Y_CELLTYPE_INVALID.

cellular→get_dataReceived()
cellular→dataReceived()
cellular.get_dataReceived()cellular→get_dataReceived()[cellular dataReceived]cellular.get_dataReceived()cellular.get_dataReceived()cellular.get_dataReceived()cellular.get_dataReceived()cellular.get_dataReceived()cellular.get_dataReceived()cellular.get_dataReceived()cellular→get_dataReceived()cellular.get_dataReceived()YCellular get_dataReceived

Returns the number of bytes received so far.

js
function get_dataReceived()
cpp
int get_dataReceived()
m
-(int) dataReceived
pas
LongInt get_dataReceived(): LongInt
vb
function get_dataReceived() As Integer
cs
int get_dataReceived()
dnp
int get_dataReceived()
java
int get_dataReceived()
uwp
async Task<int> get_dataReceived()
py
get_dataReceived()
php
function get_dataReceived()
es
async get_dataReceived()
cmd
YCellular target get_dataReceived

Returns :

an integer corresponding to the number of bytes received so far

On failure, throws an exception or returns Y_DATARECEIVED_INVALID.

cellular→get_dataSent()
cellular→dataSent()
cellular.get_dataSent()cellular→get_dataSent()[cellular dataSent]cellular.get_dataSent()cellular.get_dataSent()cellular.get_dataSent()cellular.get_dataSent()cellular.get_dataSent()cellular.get_dataSent()cellular.get_dataSent()cellular→get_dataSent()cellular.get_dataSent()YCellular get_dataSent

Returns the number of bytes sent so far.

js
function get_dataSent()
cpp
int get_dataSent()
m
-(int) dataSent
pas
LongInt get_dataSent(): LongInt
vb
function get_dataSent() As Integer
cs
int get_dataSent()
dnp
int get_dataSent()
java
int get_dataSent()
uwp
async Task<int> get_dataSent()
py
get_dataSent()
php
function get_dataSent()
es
async get_dataSent()
cmd
YCellular target get_dataSent

Returns :

an integer corresponding to the number of bytes sent so far

On failure, throws an exception or returns Y_DATASENT_INVALID.

cellular→get_enableData()
cellular→enableData()
cellular.get_enableData()cellular→get_enableData()[cellular enableData]cellular.get_enableData()cellular.get_enableData()cellular.get_enableData()cellular.get_enableData()cellular.get_enableData()cellular.get_enableData()cellular.get_enableData()cellular→get_enableData()cellular.get_enableData()YCellular get_enableData

Returns the condition for enabling IP data services (GPRS).

js
function get_enableData()
cpp
Y_ENABLEDATA_enum get_enableData()
m
-(Y_ENABLEDATA_enum) enableData
pas
Integer get_enableData(): Integer
vb
function get_enableData() As Integer
cs
int get_enableData()
dnp
int get_enableData()
java
int get_enableData()
uwp
async Task<int> get_enableData()
py
get_enableData()
php
function get_enableData()
es
async get_enableData()
cmd
YCellular target get_enableData

When data services are disabled, SMS are the only mean of communication.

Returns :

a value among Y_ENABLEDATA_HOMENETWORK, Y_ENABLEDATA_ROAMING, Y_ENABLEDATA_NEVER and Y_ENABLEDATA_NEUTRALITY corresponding to the condition for enabling IP data services (GPRS)

On failure, throws an exception or returns Y_ENABLEDATA_INVALID.

cellular→get_errorMessage()
cellular→errorMessage()
cellular.get_errorMessage()cellular→get_errorMessage()[cellular errorMessage]cellular.get_errorMessage()cellular.get_errorMessage()cellular.get_errorMessage()cellular.get_errorMessage()cellular.get_errorMessage()cellular→get_errorMessage()cellular.get_errorMessage()

Returns the error message of the latest error with the cellular interface.

js
function get_errorMessage()
cpp
string get_errorMessage()
m
-(NSString*) errorMessage
pas
string get_errorMessage(): string
vb
function get_errorMessage() As String
cs
string get_errorMessage()
java
String get_errorMessage()
py
get_errorMessage()
php
function get_errorMessage()
es
get_errorMessage()

This method is mostly useful when using the Yoctopuce library with exceptions disabled.

Returns :

a string corresponding to the latest error message that occured while using the cellular interface object

cellular→get_errorType()
cellular→errorType()
cellular.get_errorType()cellular→get_errorType()[cellular errorType]cellular.get_errorType()cellular.get_errorType()cellular.get_errorType()cellular.get_errorType()cellular.get_errorType()cellular→get_errorType()cellular.get_errorType()

Returns the numerical error code of the latest error with the cellular interface.

js
function get_errorType()
cpp
YRETCODE get_errorType()
m
-(YRETCODE) errorType
pas
YRETCODE get_errorType(): YRETCODE
vb
function get_errorType() As YRETCODE
cs
YRETCODE get_errorType()
java
int get_errorType()
py
get_errorType()
php
function get_errorType()
es
get_errorType()

This method is mostly useful when using the Yoctopuce library with exceptions disabled.

Returns :

a number corresponding to the code of the latest error that occurred while using the cellular interface object

cellular→get_friendlyName()
cellular→friendlyName()
cellular.get_friendlyName()cellular→get_friendlyName()[cellular friendlyName]cellular.get_friendlyName()cellular.get_friendlyName()cellular.get_friendlyName()cellular.get_friendlyName()cellular→get_friendlyName()cellular.get_friendlyName()

Returns a global identifier of the cellular interface in the format MODULE_NAME.FUNCTION_NAME.

js
function get_friendlyName()
cpp
string get_friendlyName()
m
-(NSString*) friendlyName
cs
string get_friendlyName()
dnp
string get_friendlyName()
java
String get_friendlyName()
py
get_friendlyName()
php
function get_friendlyName()
es
async get_friendlyName()

The returned string uses the logical names of the module and of the cellular interface if they are defined, otherwise the serial number of the module and the hardware identifier of the cellular interface (for example: MyCustomName.relay1)

Returns :

a string that uniquely identifies the cellular interface using logical names (ex: MyCustomName.relay1)

On failure, throws an exception or returns Y_FRIENDLYNAME_INVALID.

cellular→get_functionDescriptor()
cellular→functionDescriptor()
cellular.get_functionDescriptor()cellular→get_functionDescriptor()[cellular functionDescriptor]cellular.get_functionDescriptor()cellular.get_functionDescriptor()cellular.get_functionDescriptor()cellular.get_functionDescriptor()cellular.get_functionDescriptor()cellular→get_functionDescriptor()cellular.get_functionDescriptor()

Returns a unique identifier of type YFUN_DESCR corresponding to the function.

js
function get_functionDescriptor()
cpp
YFUN_DESCR get_functionDescriptor()
m
-(YFUN_DESCR) functionDescriptor
pas
YFUN_DESCR get_functionDescriptor(): YFUN_DESCR
vb
function get_functionDescriptor() As YFUN_DESCR
cs
YFUN_DESCR get_functionDescriptor()
java
String get_functionDescriptor()
py
get_functionDescriptor()
php
function get_functionDescriptor()
es
async get_functionDescriptor()

This identifier can be used to test if two instances of YFunction reference the same physical function on the same physical device.

Returns :

an identifier of type YFUN_DESCR.

If the function has never been contacted, the returned value is Y_FUNCTIONDESCRIPTOR_INVALID.

cellular→get_functionId()
cellular→functionId()
cellular.get_functionId()cellular→get_functionId()[cellular functionId]cellular.get_functionId()cellular.get_functionId()cellular.get_functionId()cellular.get_functionId()cellular.get_functionId()cellular→get_functionId()cellular.get_functionId()

Returns the hardware identifier of the cellular interface, without reference to the module.

js
function get_functionId()
cpp
string get_functionId()
m
-(NSString*) functionId
vb
function get_functionId() As String
cs
string get_functionId()
dnp
string get_functionId()
java
String get_functionId()
py
get_functionId()
php
function get_functionId()
es
async get_functionId()

For example relay1

Returns :

a string that identifies the cellular interface (ex: relay1)

On failure, throws an exception or returns Y_FUNCTIONID_INVALID.

cellular→get_hardwareId()
cellular→hardwareId()
cellular.get_hardwareId()cellular→get_hardwareId()[cellular hardwareId]cellular.get_hardwareId()cellular.get_hardwareId()cellular.get_hardwareId()cellular.get_hardwareId()cellular.get_hardwareId()cellular→get_hardwareId()cellular.get_hardwareId()

Returns the unique hardware identifier of the cellular interface in the form SERIAL.FUNCTIONID.

js
function get_hardwareId()
cpp
string get_hardwareId()
m
-(NSString*) hardwareId
vb
function get_hardwareId() As String
cs
string get_hardwareId()
dnp
string get_hardwareId()
java
String get_hardwareId()
py
get_hardwareId()
php
function get_hardwareId()
es
async get_hardwareId()

The unique hardware identifier is composed of the device serial number and of the hardware identifier of the cellular interface (for example RELAYLO1-123456.relay1).

Returns :

a string that uniquely identifies the cellular interface (ex: RELAYLO1-123456.relay1)

On failure, throws an exception or returns Y_HARDWAREID_INVALID.

cellular→get_imsi()
cellular→imsi()
cellular.get_imsi()cellular→get_imsi()[cellular imsi]cellular.get_imsi()cellular.get_imsi()cellular.get_imsi()cellular.get_imsi()cellular.get_imsi()cellular.get_imsi()cellular.get_imsi()cellular→get_imsi()cellular.get_imsi()YCellular get_imsi

Returns an opaque string if a PIN code has been configured in the device to access the SIM card, or an empty string if none has been configured or if the code provided was rejected by the SIM card.

js
function get_imsi()
cpp
string get_imsi()
m
-(NSString*) imsi
pas
string get_imsi(): string
vb
function get_imsi() As String
cs
string get_imsi()
dnp
string get_imsi()
java
String get_imsi()
uwp
async Task<string> get_imsi()
py
get_imsi()
php
function get_imsi()
es
async get_imsi()
cmd
YCellular target get_imsi

Returns :

a string corresponding to an opaque string if a PIN code has been configured in the device to access the SIM card, or an empty string if none has been configured or if the code provided was rejected by the SIM card

On failure, throws an exception or returns Y_IMSI_INVALID.

cellular→get_linkQuality()
cellular→linkQuality()
cellular.get_linkQuality()cellular→get_linkQuality()[cellular linkQuality]cellular.get_linkQuality()cellular.get_linkQuality()cellular.get_linkQuality()cellular.get_linkQuality()cellular.get_linkQuality()cellular.get_linkQuality()cellular.get_linkQuality()cellular→get_linkQuality()cellular.get_linkQuality()YCellular get_linkQuality

Returns the link quality, expressed in percent.

js
function get_linkQuality()
cpp
int get_linkQuality()
m
-(int) linkQuality
pas
LongInt get_linkQuality(): LongInt
vb
function get_linkQuality() As Integer
cs
int get_linkQuality()
dnp
int get_linkQuality()
java
int get_linkQuality()
uwp
async Task<int> get_linkQuality()
py
get_linkQuality()
php
function get_linkQuality()
es
async get_linkQuality()
cmd
YCellular target get_linkQuality

Returns :

an integer corresponding to the link quality, expressed in percent

On failure, throws an exception or returns Y_LINKQUALITY_INVALID.

cellular→get_lockedOperator()
cellular→lockedOperator()
cellular.get_lockedOperator()cellular→get_lockedOperator()[cellular lockedOperator]cellular.get_lockedOperator()cellular.get_lockedOperator()cellular.get_lockedOperator()cellular.get_lockedOperator()cellular.get_lockedOperator()cellular.get_lockedOperator()cellular.get_lockedOperator()cellular→get_lockedOperator()cellular.get_lockedOperator()YCellular get_lockedOperator

Returns the name of the only cell operator to use if automatic choice is disabled, or an empty string if the SIM card will automatically choose among available cell operators.

js
function get_lockedOperator()
cpp
string get_lockedOperator()
m
-(NSString*) lockedOperator
pas
string get_lockedOperator(): string
vb
function get_lockedOperator() As String
cs
string get_lockedOperator()
dnp
string get_lockedOperator()
java
String get_lockedOperator()
uwp
async Task<string> get_lockedOperator()
py
get_lockedOperator()
php
function get_lockedOperator()
es
async get_lockedOperator()
cmd
YCellular target get_lockedOperator

Returns :

a string corresponding to the name of the only cell operator to use if automatic choice is disabled, or an empty string if the SIM card will automatically choose among available cell operators

On failure, throws an exception or returns Y_LOCKEDOPERATOR_INVALID.

cellular→get_logicalName()
cellular→logicalName()
cellular.get_logicalName()cellular→get_logicalName()[cellular logicalName]cellular.get_logicalName()cellular.get_logicalName()cellular.get_logicalName()cellular.get_logicalName()cellular.get_logicalName()cellular.get_logicalName()cellular.get_logicalName()cellular→get_logicalName()cellular.get_logicalName()YCellular get_logicalName

Returns the logical name of the cellular interface.

js
function get_logicalName()
cpp
string get_logicalName()
m
-(NSString*) logicalName
pas
string get_logicalName(): string
vb
function get_logicalName() As String
cs
string get_logicalName()
dnp
string get_logicalName()
java
String get_logicalName()
uwp
async Task<string> get_logicalName()
py
get_logicalName()
php
function get_logicalName()
es
async get_logicalName()
cmd
YCellular target get_logicalName

Returns :

a string corresponding to the logical name of the cellular interface.

On failure, throws an exception or returns Y_LOGICALNAME_INVALID.

cellular→get_message()
cellular→message()
cellular.get_message()cellular→get_message()[cellular message]cellular.get_message()cellular.get_message()cellular.get_message()cellular.get_message()cellular.get_message()cellular.get_message()cellular.get_message()cellular→get_message()cellular.get_message()YCellular get_message

Returns the latest status message from the wireless interface.

js
function get_message()
cpp
string get_message()
m
-(NSString*) message
pas
string get_message(): string
vb
function get_message() As String
cs
string get_message()
dnp
string get_message()
java
String get_message()
uwp
async Task<string> get_message()
py
get_message()
php
function get_message()
es
async get_message()
cmd
YCellular target get_message

Returns :

a string corresponding to the latest status message from the wireless interface

On failure, throws an exception or returns Y_MESSAGE_INVALID.

cellular→get_module()
cellular→module()
cellular.get_module()cellular→get_module()[cellular module]cellular.get_module()cellular.get_module()cellular.get_module()cellular.get_module()cellular.get_module()cellular.get_module()cellular→get_module()cellular.get_module()

Gets the YModule object for the device on which the function is located.

js
function get_module()
cpp
YModule * get_module()
m
-(YModule*) module
pas
TYModule get_module(): TYModule
vb
function get_module() As YModule
cs
YModule get_module()
dnp
YModuleProxy get_module()
java
YModule get_module()
py
get_module()
php
function get_module()
es
async get_module()

If the function cannot be located on any module, the returned instance of YModule is not shown as on-line.

Returns :

an instance of YModule

cellular→get_module_async()
cellular→module_async()
cellular.get_module_async()

Gets the YModule object for the device on which the function is located (asynchronous version).

js
function get_module_async(callback, context)

If the function cannot be located on any module, the returned YModule object does not show as on-line.

This asynchronous version exists only in JavaScript. It uses a callback instead of a return value in order to avoid blocking Firefox JavaScript VM that does not implement context switching during blocking I/O calls. See the documentation section on asynchronous JavasSript calls for more details.

Parameters :

callbackcallback function that is invoked when the result is known. The callback function receives three arguments: the caller-specific context object, the receiving function object and the requested YModule object
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing : the result is provided to the callback.

cellular→get_pin()
cellular→pin()
cellular.get_pin()cellular→get_pin()[cellular pin]cellular.get_pin()cellular.get_pin()cellular.get_pin()cellular.get_pin()cellular.get_pin()cellular.get_pin()cellular.get_pin()cellular→get_pin()cellular.get_pin()YCellular get_pin

Returns an opaque string if a PIN code has been configured in the device to access the SIM card, or an empty string if none has been configured or if the code provided was rejected by the SIM card.

js
function get_pin()
cpp
string get_pin()
m
-(NSString*) pin
pas
string get_pin(): string
vb
function get_pin() As String
cs
string get_pin()
dnp
string get_pin()
java
String get_pin()
uwp
async Task<string> get_pin()
py
get_pin()
php
function get_pin()
es
async get_pin()
cmd
YCellular target get_pin

Returns :

a string corresponding to an opaque string if a PIN code has been configured in the device to access the SIM card, or an empty string if none has been configured or if the code provided was rejected by the SIM card

On failure, throws an exception or returns Y_PIN_INVALID.

cellular→get_pingInterval()
cellular→pingInterval()
cellular.get_pingInterval()cellular→get_pingInterval()[cellular pingInterval]cellular.get_pingInterval()cellular.get_pingInterval()cellular.get_pingInterval()cellular.get_pingInterval()cellular.get_pingInterval()cellular.get_pingInterval()cellular.get_pingInterval()cellular→get_pingInterval()cellular.get_pingInterval()YCellular get_pingInterval

Returns the automated connectivity check interval, in seconds.

js
function get_pingInterval()
cpp
int get_pingInterval()
m
-(int) pingInterval
pas
LongInt get_pingInterval(): LongInt
vb
function get_pingInterval() As Integer
cs
int get_pingInterval()
dnp
int get_pingInterval()
java
int get_pingInterval()
uwp
async Task<int> get_pingInterval()
py
get_pingInterval()
php
function get_pingInterval()
es
async get_pingInterval()
cmd
YCellular target get_pingInterval

Returns :

an integer corresponding to the automated connectivity check interval, in seconds

On failure, throws an exception or returns Y_PINGINTERVAL_INVALID.

cellular→get_serialNumber()
cellular→serialNumber()
cellular.get_serialNumber()cellular→get_serialNumber()[cellular serialNumber]cellular.get_serialNumber()cellular.get_serialNumber()cellular.get_serialNumber()cellular.get_serialNumber()cellular.get_serialNumber()cellular.get_serialNumber()cellular.get_serialNumber()cellular→get_serialNumber()cellular.get_serialNumber()YCellular get_serialNumber

Returns the serial number of the module, as set by the factory.

js
function get_serialNumber()
cpp
string get_serialNumber()
m
-(NSString*) serialNumber
pas
string get_serialNumber(): string
vb
function get_serialNumber() As String
cs
string get_serialNumber()
dnp
string get_serialNumber()
java
String get_serialNumber()
uwp
async Task<string> get_serialNumber()
py
get_serialNumber()
php
function get_serialNumber()
es
async get_serialNumber()
cmd
YCellular target get_serialNumber

Returns :

a string corresponding to the serial number of the module, as set by the factory.

On failure, throws an exception or returns YModule.SERIALNUMBER_INVALID.

cellular→get_userData()
cellular→userData()
cellular.get_userData()cellular→get_userData()[cellular userData]cellular.get_userData()cellular.get_userData()cellular.get_userData()cellular.get_userData()cellular.get_userData()cellular→get_userData()cellular.get_userData()

Returns the value of the userData attribute, as previously stored using method set_userData.

js
function get_userData()
cpp
void * get_userData()
m
-(id) userData
pas
Tobject get_userData(): Tobject
vb
function get_userData() As Object
cs
object get_userData()
java
Object get_userData()
py
get_userData()
php
function get_userData()
es
async get_userData()

This attribute is never touched directly by the API, and is at disposal of the caller to store a context.

Returns :

the object stored previously by the caller.

cellular→isOnline()cellular.isOnline()cellular→isOnline()[cellular isOnline]cellular.isOnline()cellular.isOnline()cellular.isOnline()cellular.isOnline()cellular.isOnline()cellular.isOnline()cellular→isOnline()cellular.isOnline()

Checks if the cellular interface is currently reachable, without raising any error.

js
function isOnline()
cpp
bool isOnline()
m
-(BOOL) isOnline
pas
boolean isOnline(): boolean
vb
function isOnline() As Boolean
cs
bool isOnline()
dnp
bool isOnline()
java
boolean isOnline()
py
isOnline()
php
function isOnline()
es
async isOnline()

If there is a cached value for the cellular interface in cache, that has not yet expired, the device is considered reachable. No exception is raised if there is an error while trying to contact the device hosting the cellular interface.

Returns :

true if the cellular interface can be reached, and false otherwise

cellular→isOnline_async()cellular.isOnline_async()

Checks if the cellular interface is currently reachable, without raising any error (asynchronous version).

js
function isOnline_async(callback, context)

If there is a cached value for the cellular interface in cache, that has not yet expired, the device is considered reachable. No exception is raised if there is an error while trying to contact the device hosting the requested function.

This asynchronous version exists only in Javascript. It uses a callback instead of a return value in order to avoid blocking the Javascript virtual machine.

Parameters :

callbackcallback function that is invoked when the result is known. The callback function receives three arguments: the caller-specific context object, the receiving function object and the boolean result
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing : the result is provided to the callback.

cellular→isReadOnly()cellular→isReadOnly()[cellular isReadOnly]cellular.isReadOnly()cellular.isReadOnly()cellular.isReadOnly()cellular.isReadOnly()cellular.isReadOnly()cellular.isReadOnly()cellular.isReadOnly()cellular→isReadOnly()cellular.isReadOnly()YCellular isReadOnly

Test if the function is readOnly.

cpp
bool isReadOnly()
m
-(bool) isReadOnly
pas
boolean isReadOnly(): boolean
vb
function isReadOnly() As Boolean
cs
bool isReadOnly()
dnp
bool isReadOnly()
java
boolean isReadOnly()
uwp
async Task<bool> isReadOnly()
py
isReadOnly()
php
function isReadOnly()
es
async isReadOnly()
cmd
YCellular target isReadOnly

Return true if the function is write protected or that the function is not available.

Returns :

true if the function is readOnly or not online.

cellular→load()cellular.load()cellular→load()[cellular load: ]cellular.load()cellular.load()cellular.load()cellular.load()cellular.load()cellular→load()cellular.load()

Preloads the cellular interface cache with a specified validity duration.

js
function load(msValidity)
cpp
YRETCODE load(int msValidity)
m
-(YRETCODE) load: (u64) msValidity
pas
YRETCODE load(msValidity: u64): YRETCODE
vb
function load(ByVal msValidity As Long) As YRETCODE
cs
YRETCODE load(ulong msValidity)
java
int load(long msValidity)
py
load(msValidity)
php
function load($msValidity)
es
async load(msValidity)

By default, whenever accessing a device, all function attributes are kept in cache for the standard duration (5 ms). This method can be used to temporarily mark the cache as valid for a longer period, in order to reduce network traffic for instance.

Parameters :

msValidityan integer corresponding to the validity attributed to the loaded function parameters, in milliseconds

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→loadAttribute()cellular.loadAttribute()cellular→loadAttribute()[cellular loadAttribute: ]cellular.loadAttribute()cellular.loadAttribute()cellular.loadAttribute()cellular.loadAttribute()cellular.loadAttribute()cellular.loadAttribute()cellular.loadAttribute()cellular→loadAttribute()cellular.loadAttribute()

Returns the current value of a single function attribute, as a text string, as quickly as possible but without using the cached value.

js
function loadAttribute(attrName)
cpp
string loadAttribute(string attrName)
m
-(NSString*) loadAttribute: (NSString*) attrName
pas
string loadAttribute(attrName: string): string
vb
function loadAttribute() As String
cs
string loadAttribute(string attrName)
dnp
string loadAttribute(string attrName)
java
String loadAttribute(String attrName)
uwp
async Task<string> loadAttribute(string attrName)
py
loadAttribute(attrName)
php
function loadAttribute($attrName)
es
async loadAttribute(attrName)

Parameters :

attrNamethe name of the requested attribute

Returns :

a string with the value of the the attribute

On failure, throws an exception or returns an empty string.

cellular→load_async()cellular.load_async()

Preloads the cellular interface cache with a specified validity duration (asynchronous version).

js
function load_async(msValidity, callback, context)

By default, whenever accessing a device, all function attributes are kept in cache for the standard duration (5 ms). This method can be used to temporarily mark the cache as valid for a longer period, in order to reduce network traffic for instance.

This asynchronous version exists only in JavaScript. It uses a callback instead of a return value in order to avoid blocking the JavaScript virtual machine.

Parameters :

msValidityan integer corresponding to the validity of the loaded function parameters, in milliseconds
callbackcallback function that is invoked when the result is known. The callback function receives three arguments: the caller-specific context object, the receiving function object and the error code (or YAPI_SUCCESS)
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing : the result is provided to the callback.

cellular→muteValueCallbacks()cellular.muteValueCallbacks()cellular→muteValueCallbacks()[cellular muteValueCallbacks]cellular.muteValueCallbacks()cellular.muteValueCallbacks()cellular.muteValueCallbacks()cellular.muteValueCallbacks()cellular.muteValueCallbacks()cellular.muteValueCallbacks()cellular.muteValueCallbacks()cellular→muteValueCallbacks()cellular.muteValueCallbacks()YCellular muteValueCallbacks

Disables the propagation of every new advertised value to the parent hub.

js
function muteValueCallbacks()
cpp
int muteValueCallbacks()
m
-(int) muteValueCallbacks
pas
LongInt muteValueCallbacks(): LongInt
vb
function muteValueCallbacks() As Integer
cs
int muteValueCallbacks()
dnp
int muteValueCallbacks()
java
int muteValueCallbacks()
uwp
async Task<int> muteValueCallbacks()
py
muteValueCallbacks()
php
function muteValueCallbacks()
es
async muteValueCallbacks()
cmd
YCellular target muteValueCallbacks

You can use this function to save bandwidth and CPU on computers with limited resources, or to prevent unwanted invocations of the HTTP callback. Remember to call the saveToFlash() method of the module if the modification must be kept.

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→nextCellular()cellular.nextCellular()cellular→nextCellular()[cellular nextCellular]cellular.nextCellular()cellular.nextCellular()cellular.nextCellular()cellular.nextCellular()cellular.nextCellular()cellular.nextCellular()cellular→nextCellular()cellular.nextCellular()

Continues the enumeration of cellular interfaces started using yFirstCellular().

js
function nextCellular()
cpp
YCellular * nextCellular()
m
-(YCellular*) nextCellular
pas
TYCellular nextCellular(): TYCellular
vb
function nextCellular() As YCellular
cs
YCellular nextCellular()
java
YCellular nextCellular()
uwp
YCellular nextCellular()
py
nextCellular()
php
function nextCellular()
es
nextCellular()

Caution: You can't make any assumption about the returned cellular interfaces order. If you want to find a specific a cellular interface, use Cellular.findCellular() and a hardwareID or a logical name.

Returns :

a pointer to a YCellular object, corresponding to a cellular interface currently online, or a null pointer if there are no more cellular interfaces to enumerate.

cellular→quickCellSurvey()cellular.quickCellSurvey()cellular→quickCellSurvey()[cellular quickCellSurvey]cellular.quickCellSurvey()cellular.quickCellSurvey()cellular.quickCellSurvey()cellular.quickCellSurvey()cellular.quickCellSurvey()cellular.quickCellSurvey()cellular.quickCellSurvey()cellular→quickCellSurvey()cellular.quickCellSurvey()YCellular quickCellSurvey

Returns a list of nearby cellular antennas, as required for quick geolocation of the device.

js
function quickCellSurvey()
cpp
vector<YCellRecord> quickCellSurvey()
m
-(NSMutableArray*) quickCellSurvey
pas
TYCellRecordArray quickCellSurvey(): TYCellRecordArray
vb
function quickCellSurvey() As List
cs
List<YCellRecord> quickCellSurvey()
dnp
YCellRecordProxy[] quickCellSurvey()
java
ArrayList<YCellRecord> quickCellSurvey()
uwp
async Task<List<YCellRecord>> quickCellSurvey()
py
quickCellSurvey()
php
function quickCellSurvey()
es
async quickCellSurvey()
cmd
YCellular target quickCellSurvey

The first cell listed is the serving cell, and the next ones are the neighbor cells reported by the serving cell.

Returns :

a list of YCellRecords.

cellular→registerValueCallback()cellular.registerValueCallback()cellular→registerValueCallback()[cellular registerValueCallback: ]cellular.registerValueCallback()cellular.registerValueCallback()cellular.registerValueCallback()cellular.registerValueCallback()cellular.registerValueCallback()cellular.registerValueCallback()cellular→registerValueCallback()cellular.registerValueCallback()

Registers the callback function that is invoked on every change of advertised value.

js
function registerValueCallback(callback)
cpp
int registerValueCallback(YCellularValueCallback callback)
m
-(int) registerValueCallback: (YCellularValueCallback) callback
pas
LongInt registerValueCallback(callback: TYCellularValueCallback): LongInt
vb
function registerValueCallback() As Integer
cs
int registerValueCallback(ValueCallback callback)
java
int registerValueCallback(UpdateCallback callback)
uwp
async Task<int> registerValueCallback(ValueCallback callback)
py
registerValueCallback(callback)
php
function registerValueCallback($callback)
es
async registerValueCallback(callback)

The callback is invoked only during the execution of ySleep or yHandleEvents. This provides control over the time when the callback is triggered. For good responsiveness, remember to call one of these two functions periodically. To unregister a callback, pass a null pointer as argument.

Parameters :

callbackthe callback function to call, or a null pointer. The callback function should take two arguments: the function object of which the value has changed, and the character string describing the new advertised value.

cellular→sendPUK()cellular.sendPUK()cellular→sendPUK()[cellular sendPUK: ]cellular.sendPUK()cellular.sendPUK()cellular.sendPUK()cellular.sendPUK()cellular.sendPUK()cellular.sendPUK()cellular.sendPUK()cellular→sendPUK()cellular.sendPUK()YCellular sendPUK

Sends a PUK code to unlock the SIM card after three failed PIN code attempts, and setup a new PIN into the SIM card.

js
function sendPUK(puk, newPin)
cpp
int sendPUK(string puk, string newPin)
m
-(int) sendPUK: (NSString*) puk : (NSString*) newPin
pas
LongInt sendPUK(puk: string, newPin: string): LongInt
vb
function sendPUK() As Integer
cs
int sendPUK(string puk, string newPin)
dnp
int sendPUK(string puk, string newPin)
java
int sendPUK(String puk, String newPin)
uwp
async Task<int> sendPUK(string puk, string newPin)
py
sendPUK(puk, newPin)
php
function sendPUK($puk, $newPin)
es
async sendPUK(puk, newPin)
cmd
YCellular target sendPUK puk newPin

Only ten consecutive tentatives are permitted: after that, the SIM card will be blocked permanently without any mean of recovery to use it again. Note that after calling this method, you have usually to invoke method set_pin() to tell the YoctoHub which PIN to use in the future.

Parameters :

pukthe SIM PUK code
newPinnew PIN code to configure into the SIM card

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_airplaneMode()
cellular→setAirplaneMode()
cellular.set_airplaneMode()cellular→set_airplaneMode()[cellular setAirplaneMode: ]cellular.set_airplaneMode()cellular.set_airplaneMode()cellular.set_airplaneMode()cellular.set_airplaneMode()cellular.set_airplaneMode()cellular.set_airplaneMode()cellular.set_airplaneMode()cellular→set_airplaneMode()cellular.set_airplaneMode()YCellular set_airplaneMode

Changes the activation state of airplane mode (radio turned off).

js
function set_airplaneMode(newval)
cpp
int set_airplaneMode(Y_AIRPLANEMODE_enum newval)
m
-(int) setAirplaneMode: (Y_AIRPLANEMODE_enum) newval
pas
integer set_airplaneMode(newval: Integer): integer
vb
function set_airplaneMode(ByVal newval As Integer) As Integer
cs
int set_airplaneMode(int newval)
dnp
int set_airplaneMode(int newval)
java
int set_airplaneMode(int newval)
uwp
async Task<int> set_airplaneMode(int newval)
py
set_airplaneMode(newval)
php
function set_airplaneMode($newval)
es
async set_airplaneMode(newval)
cmd
YCellular target set_airplaneMode newval

Parameters :

newvaleither Y_AIRPLANEMODE_OFF or Y_AIRPLANEMODE_ON, according to the activation state of airplane mode (radio turned off)

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_apn()
cellular→setApn()
cellular.set_apn()cellular→set_apn()[cellular setApn: ]cellular.set_apn()cellular.set_apn()cellular.set_apn()cellular.set_apn()cellular.set_apn()cellular.set_apn()cellular.set_apn()cellular→set_apn()cellular.set_apn()YCellular set_apn

Returns the Access Point Name (APN) to be used, if needed.

js
function set_apn(newval)
cpp
int set_apn(string newval)
m
-(int) setApn: (NSString*) newval
pas
integer set_apn(newval: string): integer
vb
function set_apn(ByVal newval As String) As Integer
cs
int set_apn(string newval)
dnp
int set_apn(string newval)
java
int set_apn(String newval)
uwp
async Task<int> set_apn(string newval)
py
set_apn(newval)
php
function set_apn($newval)
es
async set_apn(newval)
cmd
YCellular target set_apn newval

When left blank, the APN suggested by the cell operator will be used. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_apnAuth()
cellular→setApnAuth()
cellular.set_apnAuth()cellular→set_apnAuth()[cellular setApnAuth: ]cellular.set_apnAuth()cellular.set_apnAuth()cellular.set_apnAuth()cellular.set_apnAuth()cellular.set_apnAuth()cellular.set_apnAuth()cellular.set_apnAuth()cellular→set_apnAuth()cellular.set_apnAuth()YCellular set_apnAuth

Configure authentication parameters to connect to the APN.

js
function set_apnAuth(username, password)
cpp
int set_apnAuth(string username, string password)
m
-(int) setApnAuth: (NSString*) username
  : (NSString*) password
pas
LongInt set_apnAuth(username: string, password: string): LongInt
vb
function set_apnAuth() As Integer
cs
int set_apnAuth(string username, string password)
dnp
int set_apnAuth(string username, string password)
java
int set_apnAuth(String username, String password)
uwp
async Task<int> set_apnAuth(string username, string password)
py
set_apnAuth(username, password)
php
function set_apnAuth($username, $password)
es
async set_apnAuth(username, password)
cmd
YCellular target set_apnAuth username password

Both PAP and CHAP authentication are supported.

Parameters :

usernameAPN username
passwordAPN password

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_dataReceived()
cellular→setDataReceived()
cellular.set_dataReceived()cellular→set_dataReceived()[cellular setDataReceived: ]cellular.set_dataReceived()cellular.set_dataReceived()cellular.set_dataReceived()cellular.set_dataReceived()cellular.set_dataReceived()cellular.set_dataReceived()cellular.set_dataReceived()cellular→set_dataReceived()cellular.set_dataReceived()YCellular set_dataReceived

Changes the value of the incoming data counter.

js
function set_dataReceived(newval)
cpp
int set_dataReceived(int newval)
m
-(int) setDataReceived: (int) newval
pas
integer set_dataReceived(newval: LongInt): integer
vb
function set_dataReceived(ByVal newval As Integer) As Integer
cs
int set_dataReceived(int newval)
dnp
int set_dataReceived(int newval)
java
int set_dataReceived(int newval)
uwp
async Task<int> set_dataReceived(int newval)
py
set_dataReceived(newval)
php
function set_dataReceived($newval)
es
async set_dataReceived(newval)
cmd
YCellular target set_dataReceived newval

Parameters :

newvalan integer corresponding to the value of the incoming data counter

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_dataSent()
cellular→setDataSent()
cellular.set_dataSent()cellular→set_dataSent()[cellular setDataSent: ]cellular.set_dataSent()cellular.set_dataSent()cellular.set_dataSent()cellular.set_dataSent()cellular.set_dataSent()cellular.set_dataSent()cellular.set_dataSent()cellular→set_dataSent()cellular.set_dataSent()YCellular set_dataSent

Changes the value of the outgoing data counter.

js
function set_dataSent(newval)
cpp
int set_dataSent(int newval)
m
-(int) setDataSent: (int) newval
pas
integer set_dataSent(newval: LongInt): integer
vb
function set_dataSent(ByVal newval As Integer) As Integer
cs
int set_dataSent(int newval)
dnp
int set_dataSent(int newval)
java
int set_dataSent(int newval)
uwp
async Task<int> set_dataSent(int newval)
py
set_dataSent(newval)
php
function set_dataSent($newval)
es
async set_dataSent(newval)
cmd
YCellular target set_dataSent newval

Parameters :

newvalan integer corresponding to the value of the outgoing data counter

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_enableData()
cellular→setEnableData()
cellular.set_enableData()cellular→set_enableData()[cellular setEnableData: ]cellular.set_enableData()cellular.set_enableData()cellular.set_enableData()cellular.set_enableData()cellular.set_enableData()cellular.set_enableData()cellular.set_enableData()cellular→set_enableData()cellular.set_enableData()YCellular set_enableData

Changes the condition for enabling IP data services (GPRS).

js
function set_enableData(newval)
cpp
int set_enableData(Y_ENABLEDATA_enum newval)
m
-(int) setEnableData: (Y_ENABLEDATA_enum) newval
pas
integer set_enableData(newval: Integer): integer
vb
function set_enableData(ByVal newval As Integer) As Integer
cs
int set_enableData(int newval)
dnp
int set_enableData(int newval)
java
int set_enableData(int newval)
uwp
async Task<int> set_enableData(int newval)
py
set_enableData(newval)
php
function set_enableData($newval)
es
async set_enableData(newval)
cmd
YCellular target set_enableData newval

The service can be either fully deactivated, or limited to the SIM home network, or enabled for all partner networks (roaming). Caution: enabling data services on roaming networks may cause prohibitive communication costs !

When data services are disabled, SMS are the only mean of communication. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala value among Y_ENABLEDATA_HOMENETWORK, Y_ENABLEDATA_ROAMING, Y_ENABLEDATA_NEVER and Y_ENABLEDATA_NEUTRALITY corresponding to the condition for enabling IP data services (GPRS)

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_lockedOperator()
cellular→setLockedOperator()
cellular.set_lockedOperator()cellular→set_lockedOperator()[cellular setLockedOperator: ]cellular.set_lockedOperator()cellular.set_lockedOperator()cellular.set_lockedOperator()cellular.set_lockedOperator()cellular.set_lockedOperator()cellular.set_lockedOperator()cellular.set_lockedOperator()cellular→set_lockedOperator()cellular.set_lockedOperator()YCellular set_lockedOperator

Changes the name of the cell operator to be used.

js
function set_lockedOperator(newval)
cpp
int set_lockedOperator(string newval)
m
-(int) setLockedOperator: (NSString*) newval
pas
integer set_lockedOperator(newval: string): integer
vb
function set_lockedOperator(ByVal newval As String) As Integer
cs
int set_lockedOperator(string newval)
dnp
int set_lockedOperator(string newval)
java
int set_lockedOperator(String newval)
uwp
async Task<int> set_lockedOperator(string newval)
py
set_lockedOperator(newval)
php
function set_lockedOperator($newval)
es
async set_lockedOperator(newval)
cmd
YCellular target set_lockedOperator newval

If the name is an empty string, the choice will be made automatically based on the SIM card. Otherwise, the selected operator is the only one that will be used. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string corresponding to the name of the cell operator to be used

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_logicalName()
cellular→setLogicalName()
cellular.set_logicalName()cellular→set_logicalName()[cellular setLogicalName: ]cellular.set_logicalName()cellular.set_logicalName()cellular.set_logicalName()cellular.set_logicalName()cellular.set_logicalName()cellular.set_logicalName()cellular.set_logicalName()cellular→set_logicalName()cellular.set_logicalName()YCellular set_logicalName

Changes the logical name of the cellular interface.

js
function set_logicalName(newval)
cpp
int set_logicalName(string newval)
m
-(int) setLogicalName: (NSString*) newval
pas
integer set_logicalName(newval: string): integer
vb
function set_logicalName(ByVal newval As String) As Integer
cs
int set_logicalName(string newval)
dnp
int set_logicalName(string newval)
java
int set_logicalName(String newval)
uwp
async Task<int> set_logicalName(string newval)
py
set_logicalName(newval)
php
function set_logicalName($newval)
es
async set_logicalName(newval)
cmd
YCellular target set_logicalName newval

You can use yCheckLogicalName() prior to this call to make sure that your parameter is valid. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string corresponding to the logical name of the cellular interface.

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_pin()
cellular→setPin()
cellular.set_pin()cellular→set_pin()[cellular setPin: ]cellular.set_pin()cellular.set_pin()cellular.set_pin()cellular.set_pin()cellular.set_pin()cellular.set_pin()cellular.set_pin()cellular→set_pin()cellular.set_pin()YCellular set_pin

Changes the PIN code used by the module to access the SIM card.

js
function set_pin(newval)
cpp
int set_pin(string newval)
m
-(int) setPin: (NSString*) newval
pas
integer set_pin(newval: string): integer
vb
function set_pin(ByVal newval As String) As Integer
cs
int set_pin(string newval)
dnp
int set_pin(string newval)
java
int set_pin(String newval)
uwp
async Task<int> set_pin(string newval)
py
set_pin(newval)
php
function set_pin($newval)
es
async set_pin(newval)
cmd
YCellular target set_pin newval

This function does not change the code on the SIM card itself, but only changes the parameter used by the device to try to get access to it. If the SIM code does not work immediately on first try, it will be automatically forgotten and the message will be set to "Enter SIM PIN". The method should then be invoked again with right correct PIN code. After three failed attempts in a row, the message is changed to "Enter SIM PUK" and the SIM card PUK code must be provided using method sendPUK.

Remember to call the saveToFlash() method of the module to save the new value in the device flash.

Parameters :

newvala string corresponding to the PIN code used by the module to access the SIM card

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_pingInterval()
cellular→setPingInterval()
cellular.set_pingInterval()cellular→set_pingInterval()[cellular setPingInterval: ]cellular.set_pingInterval()cellular.set_pingInterval()cellular.set_pingInterval()cellular.set_pingInterval()cellular.set_pingInterval()cellular.set_pingInterval()cellular.set_pingInterval()cellular→set_pingInterval()cellular.set_pingInterval()YCellular set_pingInterval

Changes the automated connectivity check interval, in seconds.

js
function set_pingInterval(newval)
cpp
int set_pingInterval(int newval)
m
-(int) setPingInterval: (int) newval
pas
integer set_pingInterval(newval: LongInt): integer
vb
function set_pingInterval(ByVal newval As Integer) As Integer
cs
int set_pingInterval(int newval)
dnp
int set_pingInterval(int newval)
java
int set_pingInterval(int newval)
uwp
async Task<int> set_pingInterval(int newval)
py
set_pingInterval(newval)
php
function set_pingInterval($newval)
es
async set_pingInterval(newval)
cmd
YCellular target set_pingInterval newval

Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvalan integer corresponding to the automated connectivity check interval, in seconds

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→set_userData()
cellular→setUserData()
cellular.set_userData()cellular→set_userData()[cellular setUserData: ]cellular.set_userData()cellular.set_userData()cellular.set_userData()cellular.set_userData()cellular.set_userData()cellular→set_userData()cellular.set_userData()

Stores a user context provided as argument in the userData attribute of the function.

js
function set_userData(data)
cpp
void set_userData(void * data)
m
-(void) setUserData: (id) data
pas
set_userData(data: Tobject)
vb
procedure set_userData(ByVal data As Object)
cs
void set_userData(object data)
java
void set_userData(Object data)
py
set_userData(data)
php
function set_userData($data)
es
async set_userData(data)

This attribute is never touched by the API, and is at disposal of the caller to store a context.

Parameters :

dataany kind of object to be stored

cellular→unmuteValueCallbacks()cellular.unmuteValueCallbacks()cellular→unmuteValueCallbacks()[cellular unmuteValueCallbacks]cellular.unmuteValueCallbacks()cellular.unmuteValueCallbacks()cellular.unmuteValueCallbacks()cellular.unmuteValueCallbacks()cellular.unmuteValueCallbacks()cellular.unmuteValueCallbacks()cellular.unmuteValueCallbacks()cellular→unmuteValueCallbacks()cellular.unmuteValueCallbacks()YCellular unmuteValueCallbacks

Re-enables the propagation of every new advertised value to the parent hub.

js
function unmuteValueCallbacks()
cpp
int unmuteValueCallbacks()
m
-(int) unmuteValueCallbacks
pas
LongInt unmuteValueCallbacks(): LongInt
vb
function unmuteValueCallbacks() As Integer
cs
int unmuteValueCallbacks()
dnp
int unmuteValueCallbacks()
java
int unmuteValueCallbacks()
uwp
async Task<int> unmuteValueCallbacks()
py
unmuteValueCallbacks()
php
function unmuteValueCallbacks()
es
async unmuteValueCallbacks()
cmd
YCellular target unmuteValueCallbacks

This function reverts the effect of a previous call to muteValueCallbacks(). Remember to call the saveToFlash() method of the module if the modification must be kept.

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

cellular→wait_async()cellular.wait_async()cellular.wait_async()

Waits for all pending asynchronous commands on the module to complete, and invoke the user-provided callback function.

js
function wait_async(callback, context)
es
wait_async(callback, context)

The callback function can therefore freely issue synchronous or asynchronous commands, without risking to block the JavaScript VM.

Parameters :

callbackcallback function that is invoked when all pending commands on the module are completed. The callback function receives two arguments: the caller-specific context object and the receiving function object.
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing.

8.3. Class YNetwork

Network interface control interface, available for instance in the YoctoHub-Ethernet, the YoctoHub-GSM-3G-EU, the YoctoHub-GSM-3G-NA or the YoctoHub-Wireless-g

YNetwork objects provide access to TCP/IP parameters of Yoctopuce devices that include a built-in network interface.

In order to use the functions described here, you should include:

es
in HTML: <script src="../../lib/yocto_network.js"></script>
in node.js: require('yoctolib-es2017/yocto_network.js');
js
<script type='text/javascript' src='yocto_network.js'></script>
cpp
#include "yocto_network.h"
m
#import "yocto_network.h"
pas
uses yocto_network;
vb
yocto_network.vb
cs
yocto_network.cs
dnp
import YoctoProxyAPI.YNetworkProxy
java
import com.yoctopuce.YoctoAPI.YNetwork;
uwp
import com.yoctopuce.YoctoAPI.YNetwork;
py
from yocto_network import *
php
require_once('yocto_network.php');
vi
YNetwork.vi
Global functions
YNetwork.FindNetwork(func)

Retrieves a network interface for a given identifier.

YNetwork.FindNetworkInContext(yctx, func)

Retrieves a network interface for a given identifier in a YAPI context.

YNetwork.FirstNetwork()

Starts the enumeration of network interfaces currently accessible.

YNetwork.FirstNetworkInContext(yctx)

Starts the enumeration of network interfaces currently accessible.

YNetwork.GetSimilarFunctions()

Enumerates all functions of type Network available on the devices currently reachable by the library, and returns their unique hardware ID.

YNetwork properties
network→AdminPassword [writable]

Hash string if a password has been set for user "admin", or an empty string otherwise.

network→AdvertisedValue [read-only]

Short string representing the current state of the function.

network→CallbackCredentials [writable]

Hashed version of the notification callback credentials if set, or an empty string otherwise.

network→CallbackEncoding [writable]

Encoding standard to use for representing notification values.

network→CallbackInitialDelay [writable]

Initial waiting time before first callback notifications, in seconds.

network→CallbackMaxDelay [writable]

Waiting time between two HTTP callbacks when there is nothing new.

network→CallbackMethod [writable]

HTTP method used to notify callbacks for significant state changes.

network→CallbackMinDelay [writable]

Minimum waiting time between two HTTP callbacks, in seconds.

network→CallbackSchedule [writable]

HTTP callback schedule strategy, as a text string.

network→CallbackUrl [writable]

Callback URL to notify of significant state changes.

network→DefaultPage [writable]

HTML page to serve for the URL "/"" of the hub.

network→Discoverable [writable]

Activation state of the multicast announce protocols to allow easy discovery of the module in the network neighborhood (uPnP/Bonjour protocol).

network→FriendlyName [read-only]

Global identifier of the function in the format MODULE_NAME.FUNCTION_NAME.

network→FunctionId [read-only]

Hardware identifier of the network interface, without reference to the module.

network→HardwareId [read-only]

Unique hardware identifier of the function in the form SERIAL.FUNCTIONID.

network→HttpPort [writable]

TCP port used to serve the hub web UI.

network→IpAddress [read-only]

IP address currently in use by the device.

network→IsOnline [read-only]

Checks if the function is currently reachable.

network→LogicalName [writable]

Logical name of the function.

network→MacAddress [read-only]

MAC address of the network interface.

network→NtpServer [writable]

IP address of the NTP server to be used by the device.

network→PrimaryDNS [writable]

IP address of the primary name server to be used by the module.

network→Readiness [read-only]

Current established working mode of the network interface.

network→SecondaryDNS [writable]

IP address of the secondary name server to be used by the module.

network→SerialNumber [read-only]

Serial number of the module, as set by the factory.

network→UserPassword [writable]

Hash string if a password has been set for "user" user, or an empty string otherwise.

network→WwwWatchdogDelay [writable]

Allowed downtime of the WWW link (in seconds) before triggering an automated reboot to try to recover Internet connectivity.

YNetwork methods
network→callbackLogin(username, password)

Connects to the notification callback and saves the credentials required to log into it.

network→clearCache()

Invalidates the cache.

network→describe()

Returns a short text that describes unambiguously the instance of the network interface in the form TYPE(NAME)=SERIAL.FUNCTIONID.

network→get_adminPassword()

Returns a hash string if a password has been set for user "admin", or an empty string otherwise.

network→get_advertisedValue()

Returns the current value of the network interface (no more than 6 characters).

network→get_callbackCredentials()

Returns a hashed version of the notification callback credentials if set, or an empty string otherwise.

network→get_callbackEncoding()

Returns the encoding standard to use for representing notification values.

network→get_callbackInitialDelay()

Returns the initial waiting time before first callback notifications, in seconds.

network→get_callbackMaxDelay()

Returns the waiting time between two HTTP callbacks when there is nothing new.

network→get_callbackMethod()

Returns the HTTP method used to notify callbacks for significant state changes.

network→get_callbackMinDelay()

Returns the minimum waiting time between two HTTP callbacks, in seconds.

network→get_callbackSchedule()

Returns the HTTP callback schedule strategy, as a text string.

network→get_callbackUrl()

Returns the callback URL to notify of significant state changes.

network→get_defaultPage()

Returns the HTML page to serve for the URL "/"" of the hub.

network→get_discoverable()

Returns the activation state of the multicast announce protocols to allow easy discovery of the module in the network neighborhood (uPnP/Bonjour protocol).

network→get_errorMessage()

Returns the error message of the latest error with the network interface.

network→get_errorType()

Returns the numerical error code of the latest error with the network interface.

network→get_friendlyName()

Returns a global identifier of the network interface in the format MODULE_NAME.FUNCTION_NAME.

network→get_functionDescriptor()

Returns a unique identifier of type YFUN_DESCR corresponding to the function.

network→get_functionId()

Returns the hardware identifier of the network interface, without reference to the module.

network→get_hardwareId()

Returns the unique hardware identifier of the network interface in the form SERIAL.FUNCTIONID.

network→get_httpPort()

Returns the TCP port used to serve the hub web UI.

network→get_ipAddress()

Returns the IP address currently in use by the device.

network→get_ipConfig()

Returns the IP configuration of the network interface.

network→get_logicalName()

Returns the logical name of the network interface.

network→get_macAddress()

Returns the MAC address of the network interface.

network→get_module()

Gets the YModule object for the device on which the function is located.

network→get_module_async(callback, context)

Gets the YModule object for the device on which the function is located (asynchronous version).

network→get_ntpServer()

Returns the IP address of the NTP server to be used by the device.

network→get_poeCurrent()

Returns the current consumed by the module from Power-over-Ethernet (PoE), in milliamps.

network→get_primaryDNS()

Returns the IP address of the primary name server to be used by the module.

network→get_readiness()

Returns the current established working mode of the network interface.

network→get_router()

Returns the IP address of the router on the device subnet (default gateway).

network→get_secondaryDNS()

Returns the IP address of the secondary name server to be used by the module.

network→get_serialNumber()

Returns the serial number of the module, as set by the factory.

network→get_subnetMask()

Returns the subnet mask currently used by the device.

network→get_userData()

Returns the value of the userData attribute, as previously stored using method set_userData.

network→get_userPassword()

Returns a hash string if a password has been set for "user" user, or an empty string otherwise.

network→get_wwwWatchdogDelay()

Returns the allowed downtime of the WWW link (in seconds) before triggering an automated reboot to try to recover Internet connectivity.

network→isOnline()

Checks if the network interface is currently reachable, without raising any error.

network→isOnline_async(callback, context)

Checks if the network interface is currently reachable, without raising any error (asynchronous version).

network→isReadOnly()

Test if the function is readOnly.

network→load(msValidity)

Preloads the network interface cache with a specified validity duration.

network→loadAttribute(attrName)

Returns the current value of a single function attribute, as a text string, as quickly as possible but without using the cached value.

network→load_async(msValidity, callback, context)

Preloads the network interface cache with a specified validity duration (asynchronous version).

network→muteValueCallbacks()

Disables the propagation of every new advertised value to the parent hub.

network→nextNetwork()

Continues the enumeration of network interfaces started using yFirstNetwork().

network→ping(host)

Pings host to test the network connectivity.

network→registerValueCallback(callback)

Registers the callback function that is invoked on every change of advertised value.

network→set_adminPassword(newval)

Changes the password for the "admin" user.

network→set_callbackCredentials(newval)

Changes the credentials required to connect to the callback address.

network→set_callbackEncoding(newval)

Changes the encoding standard to use for representing notification values.

network→set_callbackInitialDelay(newval)

Changes the initial waiting time before first callback notifications, in seconds.

network→set_callbackMaxDelay(newval)

Changes the waiting time between two HTTP callbacks when there is nothing new.

network→set_callbackMethod(newval)

Changes the HTTP method used to notify callbacks for significant state changes.

network→set_callbackMinDelay(newval)

Changes the minimum waiting time between two HTTP callbacks, in seconds.

network→set_callbackSchedule(newval)

Changes the HTTP callback schedule strategy, as a text string.

network→set_callbackUrl(newval)

Changes the callback URL to notify significant state changes.

network→set_defaultPage(newval)

Changes the default HTML page returned by the hub.

network→set_discoverable(newval)

Changes the activation state of the multicast announce protocols to allow easy discovery of the module in the network neighborhood (uPnP/Bonjour protocol).

network→set_httpPort(newval)

Changes the the TCP port used to serve the hub web UI.

network→set_logicalName(newval)

Changes the logical name of the network interface.

network→set_ntpServer(newval)

Changes the IP address of the NTP server to be used by the module.

network→set_periodicCallbackSchedule(interval, offset)

Setup periodic HTTP callbacks (simplified function).

network→set_primaryDNS(newval)

Changes the IP address of the primary name server to be used by the module.

network→set_secondaryDNS(newval)

Changes the IP address of the secondary name server to be used by the module.

network→set_userData(data)

Stores a user context provided as argument in the userData attribute of the function.

network→set_userPassword(newval)

Changes the password for the "user" user.

network→set_wwwWatchdogDelay(newval)

Changes the allowed downtime of the WWW link (in seconds) before triggering an automated reboot to try to recover Internet connectivity.

network→triggerCallback()

Trigger an HTTP callback quickly.

network→unmuteValueCallbacks()

Re-enables the propagation of every new advertised value to the parent hub.

network→useDHCP(fallbackIpAddr, fallbackSubnetMaskLen, fallbackRouter)

Changes the configuration of the network interface to enable the use of an IP address received from a DHCP server.

network→useDHCPauto()

Changes the configuration of the network interface to enable the use of an IP address received from a DHCP server.

network→useStaticIP(ipAddress, subnetMaskLen, router)

Changes the configuration of the network interface to use a static IP address.

network→wait_async(callback, context)

Waits for all pending asynchronous commands on the module to complete, and invoke the user-provided callback function.

YNetwork.FindNetwork()
YNetwork.FindNetwork()
yFindNetwork()yFindNetwork()[YNetwork FindNetwork: ]yFindNetwork()yFindNetwork()YNetwork.FindNetwork()YNetwork.FindNetwork()YNetwork.FindNetwork()YNetwork.FindNetwork()YNetwork.FindNetwork()yFindNetwork()YNetwork.FindNetwork()

Retrieves a network interface for a given identifier.

js
function yFindNetwork(func)
cpp
YNetwork* yFindNetwork(string func)
m
+(YNetwork*) FindNetwork: (NSString*) func
pas
TYNetwork yFindNetwork(func: string): TYNetwork
vb
function yFindNetwork(ByVal func As String) As YNetwork
cs
static YNetwork FindNetwork(string func)
dnp
static YNetworkProxy FindNetwork(string func)
java
static YNetwork FindNetwork(String func)
uwp
static YNetwork FindNetwork(string func)
py
FindNetwork(func)
php
function yFindNetwork($func)
es
static FindNetwork(func)

The identifier can be specified using several formats:

This function does not require that the network interface is online at the time it is invoked. The returned object is nevertheless valid. Use the method YNetwork.isOnline() to test if the network interface is indeed online at a given time. In case of ambiguity when looking for a network interface by logical name, no error is notified: the first instance found is returned. The search is performed first by hardware name, then by logical name.

If a call to this object's is_online() method returns FALSE although you are certain that the matching device is plugged, make sure that you did call registerHub() at application initialization time.

Parameters :

funca string that uniquely characterizes the network interface, for instance YHUBETH1.network.

Returns :

a YNetwork object allowing you to drive the network interface.

YNetwork.FindNetworkInContext()
YNetwork.FindNetworkInContext()
YNetwork.FindNetworkInContext()YNetwork.FindNetworkInContext()YNetwork.FindNetworkInContext()

Retrieves a network interface for a given identifier in a YAPI context.

java
static YNetwork FindNetworkInContext(YAPIContext yctx, String func)
uwp
static YNetwork FindNetworkInContext(YAPIContext yctx, string func)
es
static FindNetworkInContext(yctx, func)

The identifier can be specified using several formats:

This function does not require that the network interface is online at the time it is invoked. The returned object is nevertheless valid. Use the method YNetwork.isOnline() to test if the network interface is indeed online at a given time. In case of ambiguity when looking for a network interface by logical name, no error is notified: the first instance found is returned. The search is performed first by hardware name, then by logical name.

Parameters :

yctxa YAPI context
funca string that uniquely characterizes the network interface, for instance YHUBETH1.network.

Returns :

a YNetwork object allowing you to drive the network interface.

YNetwork.FirstNetwork()
YNetwork.FirstNetwork()
yFirstNetwork()yFirstNetwork()[YNetwork FirstNetwork]yFirstNetwork()yFirstNetwork()YNetwork.FirstNetwork()YNetwork.FirstNetwork()YNetwork.FirstNetwork()YNetwork.FirstNetwork()yFirstNetwork()YNetwork.FirstNetwork()

Starts the enumeration of network interfaces currently accessible.

js
function yFirstNetwork()
cpp
YNetwork * yFirstNetwork()
m
+(YNetwork*) FirstNetwork
pas
TYNetwork yFirstNetwork(): TYNetwork
vb
function yFirstNetwork() As YNetwork
cs
static YNetwork FirstNetwork()
java
static YNetwork FirstNetwork()
uwp
static YNetwork FirstNetwork()
py
FirstNetwork()
php
function yFirstNetwork()
es
static FirstNetwork()

Use the method YNetwork.nextNetwork() to iterate on next network interfaces.

Returns :

a pointer to a YNetwork object, corresponding to the first network interface currently online, or a null pointer if there are none.

YNetwork.FirstNetworkInContext()
YNetwork.FirstNetworkInContext()
YNetwork.FirstNetworkInContext()YNetwork.FirstNetworkInContext()YNetwork.FirstNetworkInContext()

Starts the enumeration of network interfaces currently accessible.

java
static YNetwork FirstNetworkInContext(YAPIContext yctx)
uwp
static YNetwork FirstNetworkInContext(YAPIContext yctx)
es
static FirstNetworkInContext(yctx)

Use the method YNetwork.nextNetwork() to iterate on next network interfaces.

Parameters :

yctxa YAPI context.

Returns :

a pointer to a YNetwork object, corresponding to the first network interface currently online, or a null pointer if there are none.

YNetwork.GetSimilarFunctions()
YNetwork.GetSimilarFunctions()
YNetwork.GetSimilarFunctions()

Enumerates all functions of type Network available on the devices currently reachable by the library, and returns their unique hardware ID.

dnp
static new string[] GetSimilarFunctions()

Each of these IDs can be provided as argument to the method YNetwork.FindNetwork to obtain an object that can control the corresponding device.

Returns :

an array of strings, each string containing the unique hardwareId of a device function currently connected.

network→AdminPasswordnetwork.AdminPassword

Hash string if a password has been set for user "admin", or an empty string otherwise.

dnp
string AdminPassword

Writable. Changes the password for the "admin" user. This password becomes instantly required to perform any change of the module state. If the specified value is an empty string, a password is not required anymore. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→AdvertisedValuenetwork.AdvertisedValue

Short string representing the current state of the function.

dnp
string AdvertisedValue

network→CallbackCredentialsnetwork.CallbackCredentials

Hashed version of the notification callback credentials if set, or an empty string otherwise.

dnp
string CallbackCredentials

Writable. Changes the credentials required to connect to the callback address. The credentials must be provided as returned by function get_callbackCredentials, in the form username:hash. The method used to compute the hash varies according to the the authentication scheme implemented by the callback, For Basic authentication, the hash is the MD5 of the string username:password. For Digest authentication, the hash is the MD5 of the string username:realm:password. For a simpler way to configure callback credentials, use function callbackLogin instead. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→CallbackEncodingnetwork.CallbackEncoding

Encoding standard to use for representing notification values.

dnp
int CallbackEncoding

Possible values:

Y_CALLBACKENCODING_INVALID = 0
Y_CALLBACKENCODING_FORM = 1
Y_CALLBACKENCODING_JSON = 2
Y_CALLBACKENCODING_JSON_ARRAY = 3
Y_CALLBACKENCODING_CSV = 4
Y_CALLBACKENCODING_YOCTO_API = 5
Y_CALLBACKENCODING_JSON_NUM = 6
Y_CALLBACKENCODING_EMONCMS = 7
Y_CALLBACKENCODING_AZURE = 8
Y_CALLBACKENCODING_INFLUXDB = 9
Y_CALLBACKENCODING_MQTT = 10
Y_CALLBACKENCODING_YOCTO_API_JZON = 11
Y_CALLBACKENCODING_PRTG = 12

Writable. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→CallbackInitialDelaynetwork.CallbackInitialDelay

Initial waiting time before first callback notifications, in seconds.

dnp
int CallbackInitialDelay

Writable. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→CallbackMaxDelaynetwork.CallbackMaxDelay

Waiting time between two HTTP callbacks when there is nothing new.

dnp
int CallbackMaxDelay

Writable. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→CallbackMethodnetwork.CallbackMethod

HTTP method used to notify callbacks for significant state changes.

dnp
int CallbackMethod

Possible values:

Y_CALLBACKMETHOD_INVALID = 0
Y_CALLBACKMETHOD_POST = 1
Y_CALLBACKMETHOD_GET = 2
Y_CALLBACKMETHOD_PUT = 3

Writable. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→CallbackMinDelaynetwork.CallbackMinDelay

Minimum waiting time between two HTTP callbacks, in seconds.

dnp
int CallbackMinDelay

Writable. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→CallbackSchedulenetwork.CallbackSchedule

HTTP callback schedule strategy, as a text string.

dnp
string CallbackSchedule

Writable. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→CallbackUrlnetwork.CallbackUrl

Callback URL to notify of significant state changes.

dnp
string CallbackUrl

Writable. Changes the callback URL to notify significant state changes. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→DefaultPagenetwork.DefaultPage

HTML page to serve for the URL "/"" of the hub.

dnp
string DefaultPage

Writable. Changes the default HTML page returned by the hub. If not value are set the hub return "index.html" which is the web interface of the hub. It is possible to change this page for file that has been uploaded on the hub. The maximum filename size is 15 characters. When you change this parameter, remember to call the saveToFlash() method of the module if the modification must be kept.

network→Discoverablenetwork.Discoverable

Activation state of the multicast announce protocols to allow easy discovery of the module in the network neighborhood (uPnP/Bonjour protocol).

dnp
int Discoverable

Possible values:

Y_DISCOVERABLE_INVALID = 0
Y_DISCOVERABLE_FALSE = 1
Y_DISCOVERABLE_TRUE = 2

Writable. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→FriendlyNamenetwork.FriendlyName

Global identifier of the function in the format MODULE_NAME.FUNCTION_NAME.

dnp
string FriendlyName

The returned string uses the logical names of the module and of the function if they are defined, otherwise the serial number of the module and the hardware identifier of the function (for example: MyCustomName.relay1)

network→FunctionIdnetwork.FunctionId

Hardware identifier of the network interface, without reference to the module.

dnp
string FunctionId

For example relay1

network→HardwareIdnetwork.HardwareId

Unique hardware identifier of the function in the form SERIAL.FUNCTIONID.

dnp
string HardwareId

The unique hardware identifier is composed of the device serial number and of the hardware identifier of the function (for example RELAYLO1-123456.relay1).

network→HttpPortnetwork.HttpPort

TCP port used to serve the hub web UI.

dnp
int HttpPort

Writable. Changes the the TCP port used to serve the hub web UI. The default value is port 80, which is the default for all Web servers. Regardless of the value set here, the hub will always reply on port 4444, which is used by default by Yoctopuce API library. When you change this parameter, remember to call the saveToFlash() method of the module if the modification must be kept.

network→IpAddressnetwork.IpAddress

IP address currently in use by the device.

dnp
string IpAddress

The address may have been configured statically, or provided by a DHCP server.

network→IsOnlinenetwork.IsOnline

Checks if the function is currently reachable.

dnp
bool IsOnline

If there is a cached value for the function in cache, that has not yet expired, the device is considered reachable. No exception is raised if there is an error while trying to contact the device hosting the function.

network→LogicalNamenetwork.LogicalName

Logical name of the function.

dnp
string LogicalName

Writable. You can use yCheckLogicalName() prior to this call to make sure that your parameter is valid. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→MacAddressnetwork.MacAddress

MAC address of the network interface.

dnp
string MacAddress

The MAC address is also available on a sticker on the module, in both numeric and barcode forms.

network→NtpServernetwork.NtpServer

IP address of the NTP server to be used by the device.

dnp
string NtpServer

Writable. Changes the IP address of the NTP server to be used by the module. Use an empty string to restore the factory set address. Remember to call the saveToFlash() method and then to reboot the module to apply this setting.

network→PrimaryDNSnetwork.PrimaryDNS

IP address of the primary name server to be used by the module.

dnp
string PrimaryDNS

Writable. When using DHCP, if a value is specified, it overrides the value received from the DHCP server. Remember to call the saveToFlash() method and then to reboot the module to apply this setting.

network→Readinessnetwork.Readiness

Current established working mode of the network interface.

dnp
int Readiness

Level zero (DOWN_0) means that no hardware link has been detected. Either there is no signal on the network cable, or the selected wireless access point cannot be detected. Level 1 (LIVE_1) is reached when the network is detected, but is not yet connected. For a wireless network, this shows that the requested SSID is present. Level 2 (LINK_2) is reached when the hardware connection is established. For a wired network connection, level 2 means that the cable is attached at both ends. For a connection to a wireless access point, it shows that the security parameters are properly configured. For an ad-hoc wireless connection, it means that there is at least one other device connected on the ad-hoc network. Level 3 (DHCP_3) is reached when an IP address has been obtained using DHCP. Level 4 (DNS_4) is reached when the DNS server is reachable on the network. Level 5 (WWW_5) is reached when global connectivity is demonstrated by properly loading the current time from an NTP server.

Possible values:

Y_READINESS_INVALID = 0
Y_READINESS_DOWN = 1
Y_READINESS_EXISTS = 2
Y_READINESS_LINKED = 3
Y_READINESS_LAN_OK = 4
Y_READINESS_WWW_OK = 5

network→SecondaryDNSnetwork.SecondaryDNS

IP address of the secondary name server to be used by the module.

dnp
string SecondaryDNS

Writable. When using DHCP, if a value is specified, it overrides the value received from the DHCP server. Remember to call the saveToFlash() method and then to reboot the module to apply this setting.

network→SerialNumbernetwork.SerialNumber

Serial number of the module, as set by the factory.

dnp
string SerialNumber

network→UserPasswordnetwork.UserPassword

Hash string if a password has been set for "user" user, or an empty string otherwise.

dnp
string UserPassword

Writable. Changes the password for the "user" user. This password becomes instantly required to perform any use of the module. If the specified value is an empty string, a password is not required anymore. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→WwwWatchdogDelaynetwork.WwwWatchdogDelay

Allowed downtime of the WWW link (in seconds) before triggering an automated reboot to try to recover Internet connectivity.

dnp
int WwwWatchdogDelay

A zero value disables automated reboot in case of Internet connectivity loss.

Writable. A zero value disables automated reboot in case of Internet connectivity loss. The smallest valid non-zero timeout is 90 seconds. Remember to call the saveToFlash() method of the module if the modification must be kept.

network→callbackLogin()network.callbackLogin()network→callbackLogin()[network callbackLogin: ]network.callbackLogin()network.callbackLogin()network.callbackLogin()network.callbackLogin()network.callbackLogin()network.callbackLogin()network→callbackLogin()network.callbackLogin()YNetwork callbackLogin

Connects to the notification callback and saves the credentials required to log into it.

js
function callbackLogin(username, password)
cpp
int callbackLogin(string username, string password)
m
-(int) callbackLogin: (NSString*) username
  : (NSString*) password
pas
integer callbackLogin(username: string, password: string): integer
vb
function callbackLogin(ByVal username As String,
  ByVal password As String) As Integer
cs
int callbackLogin(string username, string password)
dnp
int callbackLogin(string username, string password)
java
int callbackLogin(String username, String password)
py
callbackLogin(username, password)
php
function callbackLogin($username, $password)
es
async callbackLogin(username, password)
cmd
YNetwork target callbackLogin username password

The password is not stored into the module, only a hashed copy of the credentials are saved. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

usernameusername required to log to the callback
passwordpassword required to log to the callback

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→clearCache()network.clearCache()network→clearCache()[network clearCache]network.clearCache()network.clearCache()network.clearCache()network.clearCache()network.clearCache()network→clearCache()network.clearCache()

Invalidates the cache.

js
function clearCache()
cpp
void clearCache()
m
-(void) clearCache
pas
clearCache()
vb
procedure clearCache()
cs
void clearCache()
java
void clearCache()
py
clearCache()
php
function clearCache()
es
async clearCache()

Invalidates the cache of the network interface attributes. Forces the next call to get_xxx() or loadxxx() to use values that come from the device.

network→describe()network.describe()network→describe()[network describe]network.describe()network.describe()network.describe()network.describe()network.describe()network→describe()network.describe()

Returns a short text that describes unambiguously the instance of the network interface in the form TYPE(NAME)=SERIAL.FUNCTIONID.

js
function describe()
cpp
string describe()
m
-(NSString*) describe
pas
string describe(): string
vb
function describe() As String
cs
string describe()
java
String describe()
py
describe()
php
function describe()
es
async describe()

More precisely, TYPE is the type of the function, NAME it the name used for the first access to the function, SERIAL is the serial number of the module if the module is connected or "unresolved", and FUNCTIONID is the hardware identifier of the function if the module is connected. For example, this method returns Relay(MyCustomName.relay1)=RELAYLO1-123456.relay1 if the module is already connected or Relay(BadCustomeName.relay1)=unresolved if the module has not yet been connected. This method does not trigger any USB or TCP transaction and can therefore be used in a debugger.

Returns :

a string that describes the network interface (ex: Relay(MyCustomName.relay1)=RELAYLO1-123456.relay1)

network→get_adminPassword()
network→adminPassword()
network.get_adminPassword()network→get_adminPassword()[network adminPassword]network.get_adminPassword()network.get_adminPassword()network.get_adminPassword()network.get_adminPassword()network.get_adminPassword()network.get_adminPassword()network.get_adminPassword()network→get_adminPassword()network.get_adminPassword()YNetwork get_adminPassword

Returns a hash string if a password has been set for user "admin", or an empty string otherwise.

js
function get_adminPassword()
cpp
string get_adminPassword()
m
-(NSString*) adminPassword
pas
string get_adminPassword(): string
vb
function get_adminPassword() As String
cs
string get_adminPassword()
dnp
string get_adminPassword()
java
String get_adminPassword()
uwp
async Task<string> get_adminPassword()
py
get_adminPassword()
php
function get_adminPassword()
es
async get_adminPassword()
cmd
YNetwork target get_adminPassword

Returns :

a string corresponding to a hash string if a password has been set for user "admin", or an empty string otherwise

On failure, throws an exception or returns Y_ADMINPASSWORD_INVALID.

network→get_advertisedValue()
network→advertisedValue()
network.get_advertisedValue()network→get_advertisedValue()[network advertisedValue]network.get_advertisedValue()network.get_advertisedValue()network.get_advertisedValue()network.get_advertisedValue()network.get_advertisedValue()network.get_advertisedValue()network.get_advertisedValue()network→get_advertisedValue()network.get_advertisedValue()YNetwork get_advertisedValue

Returns the current value of the network interface (no more than 6 characters).

js
function get_advertisedValue()
cpp
string get_advertisedValue()
m
-(NSString*) advertisedValue
pas
string get_advertisedValue(): string
vb
function get_advertisedValue() As String
cs
string get_advertisedValue()
dnp
string get_advertisedValue()
java
String get_advertisedValue()
uwp
async Task<string> get_advertisedValue()
py
get_advertisedValue()
php
function get_advertisedValue()
es
async get_advertisedValue()
cmd
YNetwork target get_advertisedValue

Returns :

a string corresponding to the current value of the network interface (no more than 6 characters).

On failure, throws an exception or returns Y_ADVERTISEDVALUE_INVALID.

network→get_callbackCredentials()
network→callbackCredentials()
network.get_callbackCredentials()network→get_callbackCredentials()[network callbackCredentials]network.get_callbackCredentials()network.get_callbackCredentials()network.get_callbackCredentials()network.get_callbackCredentials()network.get_callbackCredentials()network.get_callbackCredentials()network.get_callbackCredentials()network→get_callbackCredentials()network.get_callbackCredentials()YNetwork get_callbackCredentials

Returns a hashed version of the notification callback credentials if set, or an empty string otherwise.

js
function get_callbackCredentials()
cpp
string get_callbackCredentials()
m
-(NSString*) callbackCredentials
pas
string get_callbackCredentials(): string
vb
function get_callbackCredentials() As String
cs
string get_callbackCredentials()
dnp
string get_callbackCredentials()
java
String get_callbackCredentials()
uwp
async Task<string> get_callbackCredentials()
py
get_callbackCredentials()
php
function get_callbackCredentials()
es
async get_callbackCredentials()
cmd
YNetwork target get_callbackCredentials

Returns :

a string corresponding to a hashed version of the notification callback credentials if set, or an empty string otherwise

On failure, throws an exception or returns Y_CALLBACKCREDENTIALS_INVALID.

network→get_callbackEncoding()
network→callbackEncoding()
network.get_callbackEncoding()network→get_callbackEncoding()[network callbackEncoding]network.get_callbackEncoding()network.get_callbackEncoding()network.get_callbackEncoding()network.get_callbackEncoding()network.get_callbackEncoding()network.get_callbackEncoding()network.get_callbackEncoding()network→get_callbackEncoding()network.get_callbackEncoding()YNetwork get_callbackEncoding

Returns the encoding standard to use for representing notification values.

js
function get_callbackEncoding()
cpp
Y_CALLBACKENCODING_enum get_callbackEncoding()
m
-(Y_CALLBACKENCODING_enum) callbackEncoding
pas
Integer get_callbackEncoding(): Integer
vb
function get_callbackEncoding() As Integer
cs
int get_callbackEncoding()
dnp
int get_callbackEncoding()
java
int get_callbackEncoding()
uwp
async Task<int> get_callbackEncoding()
py
get_callbackEncoding()
php
function get_callbackEncoding()
es
async get_callbackEncoding()
cmd
YNetwork target get_callbackEncoding

Returns :

a value among Y_CALLBACKENCODING_FORM, Y_CALLBACKENCODING_JSON, Y_CALLBACKENCODING_JSON_ARRAY, Y_CALLBACKENCODING_CSV, Y_CALLBACKENCODING_YOCTO_API, Y_CALLBACKENCODING_JSON_NUM, Y_CALLBACKENCODING_EMONCMS, Y_CALLBACKENCODING_AZURE, Y_CALLBACKENCODING_INFLUXDB, Y_CALLBACKENCODING_MQTT, Y_CALLBACKENCODING_YOCTO_API_JZON and Y_CALLBACKENCODING_PRTG corresponding to the encoding standard to use for representing notification values

On failure, throws an exception or returns Y_CALLBACKENCODING_INVALID.

network→get_callbackInitialDelay()
network→callbackInitialDelay()
network.get_callbackInitialDelay()network→get_callbackInitialDelay()[network callbackInitialDelay]network.get_callbackInitialDelay()network.get_callbackInitialDelay()network.get_callbackInitialDelay()network.get_callbackInitialDelay()network.get_callbackInitialDelay()network.get_callbackInitialDelay()network.get_callbackInitialDelay()network→get_callbackInitialDelay()network.get_callbackInitialDelay()YNetwork get_callbackInitialDelay

Returns the initial waiting time before first callback notifications, in seconds.

js
function get_callbackInitialDelay()
cpp
int get_callbackInitialDelay()
m
-(int) callbackInitialDelay
pas
LongInt get_callbackInitialDelay(): LongInt
vb
function get_callbackInitialDelay() As Integer
cs
int get_callbackInitialDelay()
dnp
int get_callbackInitialDelay()
java
int get_callbackInitialDelay()
uwp
async Task<int> get_callbackInitialDelay()
py
get_callbackInitialDelay()
php
function get_callbackInitialDelay()
es
async get_callbackInitialDelay()
cmd
YNetwork target get_callbackInitialDelay

Returns :

an integer corresponding to the initial waiting time before first callback notifications, in seconds

On failure, throws an exception or returns Y_CALLBACKINITIALDELAY_INVALID.

network→get_callbackMaxDelay()
network→callbackMaxDelay()
network.get_callbackMaxDelay()network→get_callbackMaxDelay()[network callbackMaxDelay]network.get_callbackMaxDelay()network.get_callbackMaxDelay()network.get_callbackMaxDelay()network.get_callbackMaxDelay()network.get_callbackMaxDelay()network.get_callbackMaxDelay()network.get_callbackMaxDelay()network→get_callbackMaxDelay()network.get_callbackMaxDelay()YNetwork get_callbackMaxDelay

Returns the waiting time between two HTTP callbacks when there is nothing new.

js
function get_callbackMaxDelay()
cpp
int get_callbackMaxDelay()
m
-(int) callbackMaxDelay
pas
LongInt get_callbackMaxDelay(): LongInt
vb
function get_callbackMaxDelay() As Integer
cs
int get_callbackMaxDelay()
dnp
int get_callbackMaxDelay()
java
int get_callbackMaxDelay()
uwp
async Task<int> get_callbackMaxDelay()
py
get_callbackMaxDelay()
php
function get_callbackMaxDelay()
es
async get_callbackMaxDelay()
cmd
YNetwork target get_callbackMaxDelay

Returns :

an integer corresponding to the waiting time between two HTTP callbacks when there is nothing new

On failure, throws an exception or returns Y_CALLBACKMAXDELAY_INVALID.

network→get_callbackMethod()
network→callbackMethod()
network.get_callbackMethod()network→get_callbackMethod()[network callbackMethod]network.get_callbackMethod()network.get_callbackMethod()network.get_callbackMethod()network.get_callbackMethod()network.get_callbackMethod()network.get_callbackMethod()network.get_callbackMethod()network→get_callbackMethod()network.get_callbackMethod()YNetwork get_callbackMethod

Returns the HTTP method used to notify callbacks for significant state changes.

js
function get_callbackMethod()
cpp
Y_CALLBACKMETHOD_enum get_callbackMethod()
m
-(Y_CALLBACKMETHOD_enum) callbackMethod
pas
Integer get_callbackMethod(): Integer
vb
function get_callbackMethod() As Integer
cs
int get_callbackMethod()
dnp
int get_callbackMethod()
java
int get_callbackMethod()
uwp
async Task<int> get_callbackMethod()
py
get_callbackMethod()
php
function get_callbackMethod()
es
async get_callbackMethod()
cmd
YNetwork target get_callbackMethod

Returns :

a value among Y_CALLBACKMETHOD_POST, Y_CALLBACKMETHOD_GET and Y_CALLBACKMETHOD_PUT corresponding to the HTTP method used to notify callbacks for significant state changes

On failure, throws an exception or returns Y_CALLBACKMETHOD_INVALID.

network→get_callbackMinDelay()
network→callbackMinDelay()
network.get_callbackMinDelay()network→get_callbackMinDelay()[network callbackMinDelay]network.get_callbackMinDelay()network.get_callbackMinDelay()network.get_callbackMinDelay()network.get_callbackMinDelay()network.get_callbackMinDelay()network.get_callbackMinDelay()network.get_callbackMinDelay()network→get_callbackMinDelay()network.get_callbackMinDelay()YNetwork get_callbackMinDelay

Returns the minimum waiting time between two HTTP callbacks, in seconds.

js
function get_callbackMinDelay()
cpp
int get_callbackMinDelay()
m
-(int) callbackMinDelay
pas
LongInt get_callbackMinDelay(): LongInt
vb
function get_callbackMinDelay() As Integer
cs
int get_callbackMinDelay()
dnp
int get_callbackMinDelay()
java
int get_callbackMinDelay()
uwp
async Task<int> get_callbackMinDelay()
py
get_callbackMinDelay()
php
function get_callbackMinDelay()
es
async get_callbackMinDelay()
cmd
YNetwork target get_callbackMinDelay

Returns :

an integer corresponding to the minimum waiting time between two HTTP callbacks, in seconds

On failure, throws an exception or returns Y_CALLBACKMINDELAY_INVALID.

network→get_callbackSchedule()
network→callbackSchedule()
network.get_callbackSchedule()network→get_callbackSchedule()[network callbackSchedule]network.get_callbackSchedule()network.get_callbackSchedule()network.get_callbackSchedule()network.get_callbackSchedule()network.get_callbackSchedule()network.get_callbackSchedule()network.get_callbackSchedule()network→get_callbackSchedule()network.get_callbackSchedule()YNetwork get_callbackSchedule

Returns the HTTP callback schedule strategy, as a text string.

js
function get_callbackSchedule()
cpp
string get_callbackSchedule()
m
-(NSString*) callbackSchedule
pas
string get_callbackSchedule(): string
vb
function get_callbackSchedule() As String
cs
string get_callbackSchedule()
dnp
string get_callbackSchedule()
java
String get_callbackSchedule()
uwp
async Task<string> get_callbackSchedule()
py
get_callbackSchedule()
php
function get_callbackSchedule()
es
async get_callbackSchedule()
cmd
YNetwork target get_callbackSchedule

Returns :

a string corresponding to the HTTP callback schedule strategy, as a text string

On failure, throws an exception or returns Y_CALLBACKSCHEDULE_INVALID.

network→get_callbackUrl()
network→callbackUrl()
network.get_callbackUrl()network→get_callbackUrl()[network callbackUrl]network.get_callbackUrl()network.get_callbackUrl()network.get_callbackUrl()network.get_callbackUrl()network.get_callbackUrl()network.get_callbackUrl()network.get_callbackUrl()network→get_callbackUrl()network.get_callbackUrl()YNetwork get_callbackUrl

Returns the callback URL to notify of significant state changes.

js
function get_callbackUrl()
cpp
string get_callbackUrl()
m
-(NSString*) callbackUrl
pas
string get_callbackUrl(): string
vb
function get_callbackUrl() As String
cs
string get_callbackUrl()
dnp
string get_callbackUrl()
java
String get_callbackUrl()
uwp
async Task<string> get_callbackUrl()
py
get_callbackUrl()
php
function get_callbackUrl()
es
async get_callbackUrl()
cmd
YNetwork target get_callbackUrl

Returns :

a string corresponding to the callback URL to notify of significant state changes

On failure, throws an exception or returns Y_CALLBACKURL_INVALID.

network→get_defaultPage()
network→defaultPage()
network.get_defaultPage()network→get_defaultPage()[network defaultPage]network.get_defaultPage()network.get_defaultPage()network.get_defaultPage()network.get_defaultPage()network.get_defaultPage()network.get_defaultPage()network.get_defaultPage()network→get_defaultPage()network.get_defaultPage()YNetwork get_defaultPage

Returns the HTML page to serve for the URL "/"" of the hub.

js
function get_defaultPage()
cpp
string get_defaultPage()
m
-(NSString*) defaultPage
pas
string get_defaultPage(): string
vb
function get_defaultPage() As String
cs
string get_defaultPage()
dnp
string get_defaultPage()
java
String get_defaultPage()
uwp
async Task<string> get_defaultPage()
py
get_defaultPage()
php
function get_defaultPage()
es
async get_defaultPage()
cmd
YNetwork target get_defaultPage

Returns :

a string corresponding to the HTML page to serve for the URL "/"" of the hub

On failure, throws an exception or returns Y_DEFAULTPAGE_INVALID.

network→get_discoverable()
network→discoverable()
network.get_discoverable()network→get_discoverable()[network discoverable]network.get_discoverable()network.get_discoverable()network.get_discoverable()network.get_discoverable()network.get_discoverable()network.get_discoverable()network.get_discoverable()network→get_discoverable()network.get_discoverable()YNetwork get_discoverable

Returns the activation state of the multicast announce protocols to allow easy discovery of the module in the network neighborhood (uPnP/Bonjour protocol).

js
function get_discoverable()
cpp
Y_DISCOVERABLE_enum get_discoverable()
m
-(Y_DISCOVERABLE_enum) discoverable
pas
Integer get_discoverable(): Integer
vb
function get_discoverable() As Integer
cs
int get_discoverable()
dnp
int get_discoverable()
java
int get_discoverable()
uwp
async Task<int> get_discoverable()
py
get_discoverable()
php
function get_discoverable()
es
async get_discoverable()
cmd
YNetwork target get_discoverable

Returns :

either Y_DISCOVERABLE_FALSE or Y_DISCOVERABLE_TRUE, according to the activation state of the multicast announce protocols to allow easy discovery of the module in the network neighborhood (uPnP/Bonjour protocol)

On failure, throws an exception or returns Y_DISCOVERABLE_INVALID.

network→get_errorMessage()
network→errorMessage()
network.get_errorMessage()network→get_errorMessage()[network errorMessage]network.get_errorMessage()network.get_errorMessage()network.get_errorMessage()network.get_errorMessage()network.get_errorMessage()network→get_errorMessage()network.get_errorMessage()

Returns the error message of the latest error with the network interface.

js
function get_errorMessage()
cpp
string get_errorMessage()
m
-(NSString*) errorMessage
pas
string get_errorMessage(): string
vb
function get_errorMessage() As String
cs
string get_errorMessage()
java
String get_errorMessage()
py
get_errorMessage()
php
function get_errorMessage()
es
get_errorMessage()

This method is mostly useful when using the Yoctopuce library with exceptions disabled.

Returns :

a string corresponding to the latest error message that occured while using the network interface object

network→get_errorType()
network→errorType()
network.get_errorType()network→get_errorType()[network errorType]network.get_errorType()network.get_errorType()network.get_errorType()network.get_errorType()network.get_errorType()network→get_errorType()network.get_errorType()

Returns the numerical error code of the latest error with the network interface.

js
function get_errorType()
cpp
YRETCODE get_errorType()
m
-(YRETCODE) errorType
pas
YRETCODE get_errorType(): YRETCODE
vb
function get_errorType() As YRETCODE
cs
YRETCODE get_errorType()
java
int get_errorType()
py
get_errorType()
php
function get_errorType()
es
get_errorType()

This method is mostly useful when using the Yoctopuce library with exceptions disabled.

Returns :

a number corresponding to the code of the latest error that occurred while using the network interface object

network→get_friendlyName()
network→friendlyName()
network.get_friendlyName()network→get_friendlyName()[network friendlyName]network.get_friendlyName()network.get_friendlyName()network.get_friendlyName()network.get_friendlyName()network→get_friendlyName()network.get_friendlyName()

Returns a global identifier of the network interface in the format MODULE_NAME.FUNCTION_NAME.

js
function get_friendlyName()
cpp
string get_friendlyName()
m
-(NSString*) friendlyName
cs
string get_friendlyName()
dnp
string get_friendlyName()
java
String get_friendlyName()
py
get_friendlyName()
php
function get_friendlyName()
es
async get_friendlyName()

The returned string uses the logical names of the module and of the network interface if they are defined, otherwise the serial number of the module and the hardware identifier of the network interface (for example: MyCustomName.relay1)

Returns :

a string that uniquely identifies the network interface using logical names (ex: MyCustomName.relay1)

On failure, throws an exception or returns Y_FRIENDLYNAME_INVALID.

network→get_functionDescriptor()
network→functionDescriptor()
network.get_functionDescriptor()network→get_functionDescriptor()[network functionDescriptor]network.get_functionDescriptor()network.get_functionDescriptor()network.get_functionDescriptor()network.get_functionDescriptor()network.get_functionDescriptor()network→get_functionDescriptor()network.get_functionDescriptor()

Returns a unique identifier of type YFUN_DESCR corresponding to the function.

js
function get_functionDescriptor()
cpp
YFUN_DESCR get_functionDescriptor()
m
-(YFUN_DESCR) functionDescriptor
pas
YFUN_DESCR get_functionDescriptor(): YFUN_DESCR
vb
function get_functionDescriptor() As YFUN_DESCR
cs
YFUN_DESCR get_functionDescriptor()
java
String get_functionDescriptor()
py
get_functionDescriptor()
php
function get_functionDescriptor()
es
async get_functionDescriptor()

This identifier can be used to test if two instances of YFunction reference the same physical function on the same physical device.

Returns :

an identifier of type YFUN_DESCR.

If the function has never been contacted, the returned value is Y_FUNCTIONDESCRIPTOR_INVALID.

network→get_functionId()
network→functionId()
network.get_functionId()network→get_functionId()[network functionId]network.get_functionId()network.get_functionId()network.get_functionId()network.get_functionId()network.get_functionId()network→get_functionId()network.get_functionId()

Returns the hardware identifier of the network interface, without reference to the module.

js
function get_functionId()
cpp
string get_functionId()
m
-(NSString*) functionId
vb
function get_functionId() As String
cs
string get_functionId()
dnp
string get_functionId()
java
String get_functionId()
py
get_functionId()
php
function get_functionId()
es
async get_functionId()

For example relay1

Returns :

a string that identifies the network interface (ex: relay1)

On failure, throws an exception or returns Y_FUNCTIONID_INVALID.

network→get_hardwareId()
network→hardwareId()
network.get_hardwareId()network→get_hardwareId()[network hardwareId]network.get_hardwareId()network.get_hardwareId()network.get_hardwareId()network.get_hardwareId()network.get_hardwareId()network→get_hardwareId()network.get_hardwareId()

Returns the unique hardware identifier of the network interface in the form SERIAL.FUNCTIONID.

js
function get_hardwareId()
cpp
string get_hardwareId()
m
-(NSString*) hardwareId
vb
function get_hardwareId() As String
cs
string get_hardwareId()
dnp
string get_hardwareId()
java
String get_hardwareId()
py
get_hardwareId()
php
function get_hardwareId()
es
async get_hardwareId()

The unique hardware identifier is composed of the device serial number and of the hardware identifier of the network interface (for example RELAYLO1-123456.relay1).

Returns :

a string that uniquely identifies the network interface (ex: RELAYLO1-123456.relay1)

On failure, throws an exception or returns Y_HARDWAREID_INVALID.

network→get_httpPort()
network→httpPort()
network.get_httpPort()network→get_httpPort()[network httpPort]network.get_httpPort()network.get_httpPort()network.get_httpPort()network.get_httpPort()network.get_httpPort()network.get_httpPort()network.get_httpPort()network→get_httpPort()network.get_httpPort()YNetwork get_httpPort

Returns the TCP port used to serve the hub web UI.

js
function get_httpPort()
cpp
int get_httpPort()
m
-(int) httpPort
pas
LongInt get_httpPort(): LongInt
vb
function get_httpPort() As Integer
cs
int get_httpPort()
dnp
int get_httpPort()
java
int get_httpPort()
uwp
async Task<int> get_httpPort()
py
get_httpPort()
php
function get_httpPort()
es
async get_httpPort()
cmd
YNetwork target get_httpPort

Returns :

an integer corresponding to the TCP port used to serve the hub web UI

On failure, throws an exception or returns Y_HTTPPORT_INVALID.

network→get_ipAddress()
network→ipAddress()
network.get_ipAddress()network→get_ipAddress()[network ipAddress]network.get_ipAddress()network.get_ipAddress()network.get_ipAddress()network.get_ipAddress()network.get_ipAddress()network.get_ipAddress()network.get_ipAddress()network→get_ipAddress()network.get_ipAddress()YNetwork get_ipAddress

Returns the IP address currently in use by the device.

js
function get_ipAddress()
cpp
string get_ipAddress()
m
-(NSString*) ipAddress
pas
string get_ipAddress(): string
vb
function get_ipAddress() As String
cs
string get_ipAddress()
dnp
string get_ipAddress()
java
String get_ipAddress()
uwp
async Task<string> get_ipAddress()
py
get_ipAddress()
php
function get_ipAddress()
es
async get_ipAddress()
cmd
YNetwork target get_ipAddress

The address may have been configured statically, or provided by a DHCP server.

Returns :

a string corresponding to the IP address currently in use by the device

On failure, throws an exception or returns Y_IPADDRESS_INVALID.

network→get_ipConfig()
network→ipConfig()
network.get_ipConfig()network→get_ipConfig()[network ipConfig]network.get_ipConfig()network.get_ipConfig()network.get_ipConfig()network.get_ipConfig()network.get_ipConfig()network.get_ipConfig()network.get_ipConfig()network→get_ipConfig()network.get_ipConfig()YNetwork get_ipConfig

Returns the IP configuration of the network interface.

js
function get_ipConfig()
cpp
string get_ipConfig()
m
-(NSString*) ipConfig
pas
string get_ipConfig(): string
vb
function get_ipConfig() As String
cs
string get_ipConfig()
dnp
string get_ipConfig()
java
String get_ipConfig()
uwp
async Task<string> get_ipConfig()
py
get_ipConfig()
php
function get_ipConfig()
es
async get_ipConfig()
cmd
YNetwork target get_ipConfig

If the network interface is setup to use a static IP address, the string starts with "STATIC:" and is followed by three parameters, separated by "/". The first is the device IP address, followed by the subnet mask length, and finally the router IP address (default gateway). For instance: "STATIC:192.168.1.14/16/192.168.1.1"

If the network interface is configured to receive its IP from a DHCP server, the string start with "DHCP:" and is followed by three parameters separated by "/". The first is the fallback IP address, then the fallback subnet mask length and finally the fallback router IP address. These three parameters are used when no DHCP reply is received.

Returns :

a string corresponding to the IP configuration of the network interface

On failure, throws an exception or returns Y_IPCONFIG_INVALID.

network→get_logicalName()
network→logicalName()
network.get_logicalName()network→get_logicalName()[network logicalName]network.get_logicalName()network.get_logicalName()network.get_logicalName()network.get_logicalName()network.get_logicalName()network.get_logicalName()network.get_logicalName()network→get_logicalName()network.get_logicalName()YNetwork get_logicalName

Returns the logical name of the network interface.

js
function get_logicalName()
cpp
string get_logicalName()
m
-(NSString*) logicalName
pas
string get_logicalName(): string
vb
function get_logicalName() As String
cs
string get_logicalName()
dnp
string get_logicalName()
java
String get_logicalName()
uwp
async Task<string> get_logicalName()
py
get_logicalName()
php
function get_logicalName()
es
async get_logicalName()
cmd
YNetwork target get_logicalName

Returns :

a string corresponding to the logical name of the network interface.

On failure, throws an exception or returns Y_LOGICALNAME_INVALID.

network→get_macAddress()
network→macAddress()
network.get_macAddress()network→get_macAddress()[network macAddress]network.get_macAddress()network.get_macAddress()network.get_macAddress()network.get_macAddress()network.get_macAddress()network.get_macAddress()network.get_macAddress()network→get_macAddress()network.get_macAddress()YNetwork get_macAddress

Returns the MAC address of the network interface.

js
function get_macAddress()
cpp
string get_macAddress()
m
-(NSString*) macAddress
pas
string get_macAddress(): string
vb
function get_macAddress() As String
cs
string get_macAddress()
dnp
string get_macAddress()
java
String get_macAddress()
uwp
async Task<string> get_macAddress()
py
get_macAddress()
php
function get_macAddress()
es
async get_macAddress()
cmd
YNetwork target get_macAddress

The MAC address is also available on a sticker on the module, in both numeric and barcode forms.

Returns :

a string corresponding to the MAC address of the network interface

On failure, throws an exception or returns Y_MACADDRESS_INVALID.

network→get_module()
network→module()
network.get_module()network→get_module()[network module]network.get_module()network.get_module()network.get_module()network.get_module()network.get_module()network.get_module()network→get_module()network.get_module()

Gets the YModule object for the device on which the function is located.

js
function get_module()
cpp
YModule * get_module()
m
-(YModule*) module
pas
TYModule get_module(): TYModule
vb
function get_module() As YModule
cs
YModule get_module()
dnp
YModuleProxy get_module()
java
YModule get_module()
py
get_module()
php
function get_module()
es
async get_module()

If the function cannot be located on any module, the returned instance of YModule is not shown as on-line.

Returns :

an instance of YModule

network→get_module_async()
network→module_async()
network.get_module_async()

Gets the YModule object for the device on which the function is located (asynchronous version).

js
function get_module_async(callback, context)

If the function cannot be located on any module, the returned YModule object does not show as on-line.

This asynchronous version exists only in JavaScript. It uses a callback instead of a return value in order to avoid blocking Firefox JavaScript VM that does not implement context switching during blocking I/O calls. See the documentation section on asynchronous JavasSript calls for more details.

Parameters :

callbackcallback function that is invoked when the result is known. The callback function receives three arguments: the caller-specific context object, the receiving function object and the requested YModule object
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing : the result is provided to the callback.

network→get_ntpServer()
network→ntpServer()
network.get_ntpServer()network→get_ntpServer()[network ntpServer]network.get_ntpServer()network.get_ntpServer()network.get_ntpServer()network.get_ntpServer()network.get_ntpServer()network.get_ntpServer()network.get_ntpServer()network→get_ntpServer()network.get_ntpServer()YNetwork get_ntpServer

Returns the IP address of the NTP server to be used by the device.

js
function get_ntpServer()
cpp
string get_ntpServer()
m
-(NSString*) ntpServer
pas
string get_ntpServer(): string
vb
function get_ntpServer() As String
cs
string get_ntpServer()
dnp
string get_ntpServer()
java
String get_ntpServer()
uwp
async Task<string> get_ntpServer()
py
get_ntpServer()
php
function get_ntpServer()
es
async get_ntpServer()
cmd
YNetwork target get_ntpServer

Returns :

a string corresponding to the IP address of the NTP server to be used by the device

On failure, throws an exception or returns Y_NTPSERVER_INVALID.

network→get_poeCurrent()
network→poeCurrent()
network.get_poeCurrent()network→get_poeCurrent()[network poeCurrent]network.get_poeCurrent()network.get_poeCurrent()network.get_poeCurrent()network.get_poeCurrent()network.get_poeCurrent()network.get_poeCurrent()network.get_poeCurrent()network→get_poeCurrent()network.get_poeCurrent()YNetwork get_poeCurrent

Returns the current consumed by the module from Power-over-Ethernet (PoE), in milliamps.

js
function get_poeCurrent()
cpp
int get_poeCurrent()
m
-(int) poeCurrent
pas
LongInt get_poeCurrent(): LongInt
vb
function get_poeCurrent() As Integer
cs
int get_poeCurrent()
dnp
int get_poeCurrent()
java
int get_poeCurrent()
uwp
async Task<int> get_poeCurrent()
py
get_poeCurrent()
php
function get_poeCurrent()
es
async get_poeCurrent()
cmd
YNetwork target get_poeCurrent

The current consumption is measured after converting PoE source to 5 Volt, and should never exceed 1800 mA.

Returns :

an integer corresponding to the current consumed by the module from Power-over-Ethernet (PoE), in milliamps

On failure, throws an exception or returns Y_POECURRENT_INVALID.

network→get_primaryDNS()
network→primaryDNS()
network.get_primaryDNS()network→get_primaryDNS()[network primaryDNS]network.get_primaryDNS()network.get_primaryDNS()network.get_primaryDNS()network.get_primaryDNS()network.get_primaryDNS()network.get_primaryDNS()network.get_primaryDNS()network→get_primaryDNS()network.get_primaryDNS()YNetwork get_primaryDNS

Returns the IP address of the primary name server to be used by the module.

js
function get_primaryDNS()
cpp
string get_primaryDNS()
m
-(NSString*) primaryDNS
pas
string get_primaryDNS(): string
vb
function get_primaryDNS() As String
cs
string get_primaryDNS()
dnp
string get_primaryDNS()
java
String get_primaryDNS()
uwp
async Task<string> get_primaryDNS()
py
get_primaryDNS()
php
function get_primaryDNS()
es
async get_primaryDNS()
cmd
YNetwork target get_primaryDNS

Returns :

a string corresponding to the IP address of the primary name server to be used by the module

On failure, throws an exception or returns Y_PRIMARYDNS_INVALID.

network→get_readiness()
network→readiness()
network.get_readiness()network→get_readiness()[network readiness]network.get_readiness()network.get_readiness()network.get_readiness()network.get_readiness()network.get_readiness()network.get_readiness()network.get_readiness()network→get_readiness()network.get_readiness()YNetwork get_readiness

Returns the current established working mode of the network interface.

js
function get_readiness()
cpp
Y_READINESS_enum get_readiness()
m
-(Y_READINESS_enum) readiness
pas
Integer get_readiness(): Integer
vb
function get_readiness() As Integer
cs
int get_readiness()
dnp
int get_readiness()
java
int get_readiness()
uwp
async Task<int> get_readiness()
py
get_readiness()
php
function get_readiness()
es
async get_readiness()
cmd
YNetwork target get_readiness

Level zero (DOWN_0) means that no hardware link has been detected. Either there is no signal on the network cable, or the selected wireless access point cannot be detected. Level 1 (LIVE_1) is reached when the network is detected, but is not yet connected. For a wireless network, this shows that the requested SSID is present. Level 2 (LINK_2) is reached when the hardware connection is established. For a wired network connection, level 2 means that the cable is attached at both ends. For a connection to a wireless access point, it shows that the security parameters are properly configured. For an ad-hoc wireless connection, it means that there is at least one other device connected on the ad-hoc network. Level 3 (DHCP_3) is reached when an IP address has been obtained using DHCP. Level 4 (DNS_4) is reached when the DNS server is reachable on the network. Level 5 (WWW_5) is reached when global connectivity is demonstrated by properly loading the current time from an NTP server.

Returns :

a value among Y_READINESS_DOWN, Y_READINESS_EXISTS, Y_READINESS_LINKED, Y_READINESS_LAN_OK and Y_READINESS_WWW_OK corresponding to the current established working mode of the network interface

On failure, throws an exception or returns Y_READINESS_INVALID.

network→get_router()
network→router()
network.get_router()network→get_router()[network router]network.get_router()network.get_router()network.get_router()network.get_router()network.get_router()network.get_router()network.get_router()network→get_router()network.get_router()YNetwork get_router

Returns the IP address of the router on the device subnet (default gateway).

js
function get_router()
cpp
string get_router()
m
-(NSString*) router
pas
string get_router(): string
vb
function get_router() As String
cs
string get_router()
dnp
string get_router()
java
String get_router()
uwp
async Task<string> get_router()
py
get_router()
php
function get_router()
es
async get_router()
cmd
YNetwork target get_router

Returns :

a string corresponding to the IP address of the router on the device subnet (default gateway)

On failure, throws an exception or returns Y_ROUTER_INVALID.

network→get_secondaryDNS()
network→secondaryDNS()
network.get_secondaryDNS()network→get_secondaryDNS()[network secondaryDNS]network.get_secondaryDNS()network.get_secondaryDNS()network.get_secondaryDNS()network.get_secondaryDNS()network.get_secondaryDNS()network.get_secondaryDNS()network.get_secondaryDNS()network→get_secondaryDNS()network.get_secondaryDNS()YNetwork get_secondaryDNS

Returns the IP address of the secondary name server to be used by the module.

js
function get_secondaryDNS()
cpp
string get_secondaryDNS()
m
-(NSString*) secondaryDNS
pas
string get_secondaryDNS(): string
vb
function get_secondaryDNS() As String
cs
string get_secondaryDNS()
dnp
string get_secondaryDNS()
java
String get_secondaryDNS()
uwp
async Task<string> get_secondaryDNS()
py
get_secondaryDNS()
php
function get_secondaryDNS()
es
async get_secondaryDNS()
cmd
YNetwork target get_secondaryDNS

Returns :

a string corresponding to the IP address of the secondary name server to be used by the module

On failure, throws an exception or returns Y_SECONDARYDNS_INVALID.

network→get_serialNumber()
network→serialNumber()
network.get_serialNumber()network→get_serialNumber()[network serialNumber]network.get_serialNumber()network.get_serialNumber()network.get_serialNumber()network.get_serialNumber()network.get_serialNumber()network.get_serialNumber()network.get_serialNumber()network→get_serialNumber()network.get_serialNumber()YNetwork get_serialNumber

Returns the serial number of the module, as set by the factory.

js
function get_serialNumber()
cpp
string get_serialNumber()
m
-(NSString*) serialNumber
pas
string get_serialNumber(): string
vb
function get_serialNumber() As String
cs
string get_serialNumber()
dnp
string get_serialNumber()
java
String get_serialNumber()
uwp
async Task<string> get_serialNumber()
py
get_serialNumber()
php
function get_serialNumber()
es
async get_serialNumber()
cmd
YNetwork target get_serialNumber

Returns :

a string corresponding to the serial number of the module, as set by the factory.

On failure, throws an exception or returns YModule.SERIALNUMBER_INVALID.

network→get_subnetMask()
network→subnetMask()
network.get_subnetMask()network→get_subnetMask()[network subnetMask]network.get_subnetMask()network.get_subnetMask()network.get_subnetMask()network.get_subnetMask()network.get_subnetMask()network.get_subnetMask()network.get_subnetMask()network→get_subnetMask()network.get_subnetMask()YNetwork get_subnetMask

Returns the subnet mask currently used by the device.

js
function get_subnetMask()
cpp
string get_subnetMask()
m
-(NSString*) subnetMask
pas
string get_subnetMask(): string
vb
function get_subnetMask() As String
cs
string get_subnetMask()
dnp
string get_subnetMask()
java
String get_subnetMask()
uwp
async Task<string> get_subnetMask()
py
get_subnetMask()
php
function get_subnetMask()
es
async get_subnetMask()
cmd
YNetwork target get_subnetMask

Returns :

a string corresponding to the subnet mask currently used by the device

On failure, throws an exception or returns Y_SUBNETMASK_INVALID.

network→get_userData()
network→userData()
network.get_userData()network→get_userData()[network userData]network.get_userData()network.get_userData()network.get_userData()network.get_userData()network.get_userData()network→get_userData()network.get_userData()

Returns the value of the userData attribute, as previously stored using method set_userData.

js
function get_userData()
cpp
void * get_userData()
m
-(id) userData
pas
Tobject get_userData(): Tobject
vb
function get_userData() As Object
cs
object get_userData()
java
Object get_userData()
py
get_userData()
php
function get_userData()
es
async get_userData()

This attribute is never touched directly by the API, and is at disposal of the caller to store a context.

Returns :

the object stored previously by the caller.

network→get_userPassword()
network→userPassword()
network.get_userPassword()network→get_userPassword()[network userPassword]network.get_userPassword()network.get_userPassword()network.get_userPassword()network.get_userPassword()network.get_userPassword()network.get_userPassword()network.get_userPassword()network→get_userPassword()network.get_userPassword()YNetwork get_userPassword

Returns a hash string if a password has been set for "user" user, or an empty string otherwise.

js
function get_userPassword()
cpp
string get_userPassword()
m
-(NSString*) userPassword
pas
string get_userPassword(): string
vb
function get_userPassword() As String
cs
string get_userPassword()
dnp
string get_userPassword()
java
String get_userPassword()
uwp
async Task<string> get_userPassword()
py
get_userPassword()
php
function get_userPassword()
es
async get_userPassword()
cmd
YNetwork target get_userPassword

Returns :

a string corresponding to a hash string if a password has been set for "user" user, or an empty string otherwise

On failure, throws an exception or returns Y_USERPASSWORD_INVALID.

network→get_wwwWatchdogDelay()
network→wwwWatchdogDelay()
network.get_wwwWatchdogDelay()network→get_wwwWatchdogDelay()[network wwwWatchdogDelay]network.get_wwwWatchdogDelay()network.get_wwwWatchdogDelay()network.get_wwwWatchdogDelay()network.get_wwwWatchdogDelay()network.get_wwwWatchdogDelay()network.get_wwwWatchdogDelay()network.get_wwwWatchdogDelay()network→get_wwwWatchdogDelay()network.get_wwwWatchdogDelay()YNetwork get_wwwWatchdogDelay

Returns the allowed downtime of the WWW link (in seconds) before triggering an automated reboot to try to recover Internet connectivity.

js
function get_wwwWatchdogDelay()
cpp
int get_wwwWatchdogDelay()
m
-(int) wwwWatchdogDelay
pas
LongInt get_wwwWatchdogDelay(): LongInt
vb
function get_wwwWatchdogDelay() As Integer
cs
int get_wwwWatchdogDelay()
dnp
int get_wwwWatchdogDelay()
java
int get_wwwWatchdogDelay()
uwp
async Task<int> get_wwwWatchdogDelay()
py
get_wwwWatchdogDelay()
php
function get_wwwWatchdogDelay()
es
async get_wwwWatchdogDelay()
cmd
YNetwork target get_wwwWatchdogDelay

A zero value disables automated reboot in case of Internet connectivity loss.

Returns :

an integer corresponding to the allowed downtime of the WWW link (in seconds) before triggering an automated reboot to try to recover Internet connectivity

On failure, throws an exception or returns Y_WWWWATCHDOGDELAY_INVALID.

network→isOnline()network.isOnline()network→isOnline()[network isOnline]network.isOnline()network.isOnline()network.isOnline()network.isOnline()network.isOnline()network.isOnline()network→isOnline()network.isOnline()

Checks if the network interface is currently reachable, without raising any error.

js
function isOnline()
cpp
bool isOnline()
m
-(BOOL) isOnline
pas
boolean isOnline(): boolean
vb
function isOnline() As Boolean
cs
bool isOnline()
dnp
bool isOnline()
java
boolean isOnline()
py
isOnline()
php
function isOnline()
es
async isOnline()

If there is a cached value for the network interface in cache, that has not yet expired, the device is considered reachable. No exception is raised if there is an error while trying to contact the device hosting the network interface.

Returns :

true if the network interface can be reached, and false otherwise

network→isOnline_async()network.isOnline_async()

Checks if the network interface is currently reachable, without raising any error (asynchronous version).

js
function isOnline_async(callback, context)

If there is a cached value for the network interface in cache, that has not yet expired, the device is considered reachable. No exception is raised if there is an error while trying to contact the device hosting the requested function.

This asynchronous version exists only in Javascript. It uses a callback instead of a return value in order to avoid blocking the Javascript virtual machine.

Parameters :

callbackcallback function that is invoked when the result is known. The callback function receives three arguments: the caller-specific context object, the receiving function object and the boolean result
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing : the result is provided to the callback.

network→isReadOnly()network→isReadOnly()[network isReadOnly]network.isReadOnly()network.isReadOnly()network.isReadOnly()network.isReadOnly()network.isReadOnly()network.isReadOnly()network.isReadOnly()network→isReadOnly()network.isReadOnly()YNetwork isReadOnly

Test if the function is readOnly.

cpp
bool isReadOnly()
m
-(bool) isReadOnly
pas
boolean isReadOnly(): boolean
vb
function isReadOnly() As Boolean
cs
bool isReadOnly()
dnp
bool isReadOnly()
java
boolean isReadOnly()
uwp
async Task<bool> isReadOnly()
py
isReadOnly()
php
function isReadOnly()
es
async isReadOnly()
cmd
YNetwork target isReadOnly

Return true if the function is write protected or that the function is not available.

Returns :

true if the function is readOnly or not online.

network→load()network.load()network→load()[network load: ]network.load()network.load()network.load()network.load()network.load()network→load()network.load()

Preloads the network interface cache with a specified validity duration.

js
function load(msValidity)
cpp
YRETCODE load(int msValidity)
m
-(YRETCODE) load: (u64) msValidity
pas
YRETCODE load(msValidity: u64): YRETCODE
vb
function load(ByVal msValidity As Long) As YRETCODE
cs
YRETCODE load(ulong msValidity)
java
int load(long msValidity)
py
load(msValidity)
php
function load($msValidity)
es
async load(msValidity)

By default, whenever accessing a device, all function attributes are kept in cache for the standard duration (5 ms). This method can be used to temporarily mark the cache as valid for a longer period, in order to reduce network traffic for instance.

Parameters :

msValidityan integer corresponding to the validity attributed to the loaded function parameters, in milliseconds

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

network→loadAttribute()network.loadAttribute()network→loadAttribute()[network loadAttribute: ]network.loadAttribute()network.loadAttribute()network.loadAttribute()network.loadAttribute()network.loadAttribute()network.loadAttribute()network.loadAttribute()network→loadAttribute()network.loadAttribute()

Returns the current value of a single function attribute, as a text string, as quickly as possible but without using the cached value.

js
function loadAttribute(attrName)
cpp
string loadAttribute(string attrName)
m
-(NSString*) loadAttribute: (NSString*) attrName
pas
string loadAttribute(attrName: string): string
vb
function loadAttribute() As String
cs
string loadAttribute(string attrName)
dnp
string loadAttribute(string attrName)
java
String loadAttribute(String attrName)
uwp
async Task<string> loadAttribute(string attrName)
py
loadAttribute(attrName)
php
function loadAttribute($attrName)
es
async loadAttribute(attrName)

Parameters :

attrNamethe name of the requested attribute

Returns :

a string with the value of the the attribute

On failure, throws an exception or returns an empty string.

network→load_async()network.load_async()

Preloads the network interface cache with a specified validity duration (asynchronous version).

js
function load_async(msValidity, callback, context)

By default, whenever accessing a device, all function attributes are kept in cache for the standard duration (5 ms). This method can be used to temporarily mark the cache as valid for a longer period, in order to reduce network traffic for instance.

This asynchronous version exists only in JavaScript. It uses a callback instead of a return value in order to avoid blocking the JavaScript virtual machine.

Parameters :

msValidityan integer corresponding to the validity of the loaded function parameters, in milliseconds
callbackcallback function that is invoked when the result is known. The callback function receives three arguments: the caller-specific context object, the receiving function object and the error code (or YAPI_SUCCESS)
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing : the result is provided to the callback.

network→muteValueCallbacks()network.muteValueCallbacks()network→muteValueCallbacks()[network muteValueCallbacks]network.muteValueCallbacks()network.muteValueCallbacks()network.muteValueCallbacks()network.muteValueCallbacks()network.muteValueCallbacks()network.muteValueCallbacks()network.muteValueCallbacks()network→muteValueCallbacks()network.muteValueCallbacks()YNetwork muteValueCallbacks

Disables the propagation of every new advertised value to the parent hub.

js
function muteValueCallbacks()
cpp
int muteValueCallbacks()
m
-(int) muteValueCallbacks
pas
LongInt muteValueCallbacks(): LongInt
vb
function muteValueCallbacks() As Integer
cs
int muteValueCallbacks()
dnp
int muteValueCallbacks()
java
int muteValueCallbacks()
uwp
async Task<int> muteValueCallbacks()
py
muteValueCallbacks()
php
function muteValueCallbacks()
es
async muteValueCallbacks()
cmd
YNetwork target muteValueCallbacks

You can use this function to save bandwidth and CPU on computers with limited resources, or to prevent unwanted invocations of the HTTP callback. Remember to call the saveToFlash() method of the module if the modification must be kept.

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

network→nextNetwork()network.nextNetwork()network→nextNetwork()[network nextNetwork]network.nextNetwork()network.nextNetwork()network.nextNetwork()network.nextNetwork()network.nextNetwork()network.nextNetwork()network→nextNetwork()network.nextNetwork()

Continues the enumeration of network interfaces started using yFirstNetwork().

js
function nextNetwork()
cpp
YNetwork * nextNetwork()
m
-(YNetwork*) nextNetwork
pas
TYNetwork nextNetwork(): TYNetwork
vb
function nextNetwork() As YNetwork
cs
YNetwork nextNetwork()
java
YNetwork nextNetwork()
uwp
YNetwork nextNetwork()
py
nextNetwork()
php
function nextNetwork()
es
nextNetwork()

Caution: You can't make any assumption about the returned network interfaces order. If you want to find a specific a network interface, use Network.findNetwork() and a hardwareID or a logical name.

Returns :

a pointer to a YNetwork object, corresponding to a network interface currently online, or a null pointer if there are no more network interfaces to enumerate.

network→ping()network.ping()network→ping()[network ping: ]network.ping()network.ping()network.ping()network.ping()network.ping()network.ping()network.ping()network→ping()network.ping()YNetwork ping

Pings host to test the network connectivity.

js
function ping(host)
cpp
string ping(string host)
m
-(NSString*) ping: (NSString*) host
pas
string ping(host: string): string
vb
function ping() As String
cs
string ping(string host)
dnp
string ping(string host)
java
String ping(String host)
uwp
async Task<string> ping(string host)
py
ping(host)
php
function ping($host)
es
async ping(host)
cmd
YNetwork target ping host

Sends four ICMP ECHO_REQUEST requests from the module to the target host. This method returns a string with the result of the 4 ICMP ECHO_REQUEST requests.

Parameters :

hostthe hostname or the IP address of the target

Returns :

a string with the result of the ping.

network→registerValueCallback()network.registerValueCallback()network→registerValueCallback()[network registerValueCallback: ]network.registerValueCallback()network.registerValueCallback()network.registerValueCallback()network.registerValueCallback()network.registerValueCallback()network.registerValueCallback()network→registerValueCallback()network.registerValueCallback()

Registers the callback function that is invoked on every change of advertised value.

js
function registerValueCallback(callback)
cpp
int registerValueCallback(YNetworkValueCallback callback)
m
-(int) registerValueCallback: (YNetworkValueCallback) callback
pas
LongInt registerValueCallback(callback: TYNetworkValueCallback): LongInt
vb
function registerValueCallback() As Integer
cs
int registerValueCallback(ValueCallback callback)
java
int registerValueCallback(UpdateCallback callback)
uwp
async Task<int> registerValueCallback(ValueCallback callback)
py
registerValueCallback(callback)
php
function registerValueCallback($callback)
es
async registerValueCallback(callback)

The callback is invoked only during the execution of ySleep or yHandleEvents. This provides control over the time when the callback is triggered. For good responsiveness, remember to call one of these two functions periodically. To unregister a callback, pass a null pointer as argument.

Parameters :

callbackthe callback function to call, or a null pointer. The callback function should take two arguments: the function object of which the value has changed, and the character string describing the new advertised value.

network→set_adminPassword()
network→setAdminPassword()
network.set_adminPassword()network→set_adminPassword()[network setAdminPassword: ]network.set_adminPassword()network.set_adminPassword()network.set_adminPassword()network.set_adminPassword()network.set_adminPassword()network.set_adminPassword()network.set_adminPassword()network→set_adminPassword()network.set_adminPassword()YNetwork set_adminPassword

Changes the password for the "admin" user.

js
function set_adminPassword(newval)
cpp
int set_adminPassword(string newval)
m
-(int) setAdminPassword: (NSString*) newval
pas
integer set_adminPassword(newval: string): integer
vb
function set_adminPassword(ByVal newval As String) As Integer
cs
int set_adminPassword(string newval)
dnp
int set_adminPassword(string newval)
java
int set_adminPassword(String newval)
uwp
async Task<int> set_adminPassword(string newval)
py
set_adminPassword(newval)
php
function set_adminPassword($newval)
es
async set_adminPassword(newval)
cmd
YNetwork target set_adminPassword newval

This password becomes instantly required to perform any change of the module state. If the specified value is an empty string, a password is not required anymore. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string corresponding to the password for the "admin" user

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_callbackCredentials()
network→setCallbackCredentials()
network.set_callbackCredentials()network→set_callbackCredentials()[network setCallbackCredentials: ]network.set_callbackCredentials()network.set_callbackCredentials()network.set_callbackCredentials()network.set_callbackCredentials()network.set_callbackCredentials()network.set_callbackCredentials()network.set_callbackCredentials()network→set_callbackCredentials()network.set_callbackCredentials()YNetwork set_callbackCredentials

Changes the credentials required to connect to the callback address.

js
function set_callbackCredentials(newval)
cpp
int set_callbackCredentials(string newval)
m
-(int) setCallbackCredentials: (NSString*) newval
pas
integer set_callbackCredentials(newval: string): integer
vb
function set_callbackCredentials(ByVal newval As String) As Integer
cs
int set_callbackCredentials(string newval)
dnp
int set_callbackCredentials(string newval)
java
int set_callbackCredentials(String newval)
uwp
async Task<int> set_callbackCredentials(string newval)
py
set_callbackCredentials(newval)
php
function set_callbackCredentials($newval)
es
async set_callbackCredentials(newval)
cmd
YNetwork target set_callbackCredentials newval

The credentials must be provided as returned by function get_callbackCredentials, in the form username:hash. The method used to compute the hash varies according to the the authentication scheme implemented by the callback, For Basic authentication, the hash is the MD5 of the string username:password. For Digest authentication, the hash is the MD5 of the string username:realm:password. For a simpler way to configure callback credentials, use function callbackLogin instead. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string corresponding to the credentials required to connect to the callback address

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_callbackEncoding()
network→setCallbackEncoding()
network.set_callbackEncoding()network→set_callbackEncoding()[network setCallbackEncoding: ]network.set_callbackEncoding()network.set_callbackEncoding()network.set_callbackEncoding()network.set_callbackEncoding()network.set_callbackEncoding()network.set_callbackEncoding()network.set_callbackEncoding()network→set_callbackEncoding()network.set_callbackEncoding()YNetwork set_callbackEncoding

Changes the encoding standard to use for representing notification values.

js
function set_callbackEncoding(newval)
cpp
int set_callbackEncoding(Y_CALLBACKENCODING_enum newval)
m
-(int) setCallbackEncoding: (Y_CALLBACKENCODING_enum) newval
pas
integer set_callbackEncoding(newval: Integer): integer
vb
function set_callbackEncoding(ByVal newval As Integer) As Integer
cs
int set_callbackEncoding(int newval)
dnp
int set_callbackEncoding(int newval)
java
int set_callbackEncoding(int newval)
uwp
async Task<int> set_callbackEncoding(int newval)
py
set_callbackEncoding(newval)
php
function set_callbackEncoding($newval)
es
async set_callbackEncoding(newval)
cmd
YNetwork target set_callbackEncoding newval

Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala value among Y_CALLBACKENCODING_FORM, Y_CALLBACKENCODING_JSON, Y_CALLBACKENCODING_JSON_ARRAY, Y_CALLBACKENCODING_CSV, Y_CALLBACKENCODING_YOCTO_API, Y_CALLBACKENCODING_JSON_NUM, Y_CALLBACKENCODING_EMONCMS, Y_CALLBACKENCODING_AZURE, Y_CALLBACKENCODING_INFLUXDB, Y_CALLBACKENCODING_MQTT, Y_CALLBACKENCODING_YOCTO_API_JZON and Y_CALLBACKENCODING_PRTG corresponding to the encoding standard to use for representing notification values

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_callbackInitialDelay()
network→setCallbackInitialDelay()
network.set_callbackInitialDelay()network→set_callbackInitialDelay()[network setCallbackInitialDelay: ]network.set_callbackInitialDelay()network.set_callbackInitialDelay()network.set_callbackInitialDelay()network.set_callbackInitialDelay()network.set_callbackInitialDelay()network.set_callbackInitialDelay()network.set_callbackInitialDelay()network→set_callbackInitialDelay()network.set_callbackInitialDelay()YNetwork set_callbackInitialDelay

Changes the initial waiting time before first callback notifications, in seconds.

js
function set_callbackInitialDelay(newval)
cpp
int set_callbackInitialDelay(int newval)
m
-(int) setCallbackInitialDelay: (int) newval
pas
integer set_callbackInitialDelay(newval: LongInt): integer
vb
function set_callbackInitialDelay(ByVal newval As Integer) As Integer
cs
int set_callbackInitialDelay(int newval)
dnp
int set_callbackInitialDelay(int newval)
java
int set_callbackInitialDelay(int newval)
uwp
async Task<int> set_callbackInitialDelay(int newval)
py
set_callbackInitialDelay(newval)
php
function set_callbackInitialDelay($newval)
es
async set_callbackInitialDelay(newval)
cmd
YNetwork target set_callbackInitialDelay newval

Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvalan integer corresponding to the initial waiting time before first callback notifications, in seconds

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_callbackMaxDelay()
network→setCallbackMaxDelay()
network.set_callbackMaxDelay()network→set_callbackMaxDelay()[network setCallbackMaxDelay: ]network.set_callbackMaxDelay()network.set_callbackMaxDelay()network.set_callbackMaxDelay()network.set_callbackMaxDelay()network.set_callbackMaxDelay()network.set_callbackMaxDelay()network.set_callbackMaxDelay()network→set_callbackMaxDelay()network.set_callbackMaxDelay()YNetwork set_callbackMaxDelay

Changes the waiting time between two HTTP callbacks when there is nothing new.

js
function set_callbackMaxDelay(newval)
cpp
int set_callbackMaxDelay(int newval)
m
-(int) setCallbackMaxDelay: (int) newval
pas
integer set_callbackMaxDelay(newval: LongInt): integer
vb
function set_callbackMaxDelay(ByVal newval As Integer) As Integer
cs
int set_callbackMaxDelay(int newval)
dnp
int set_callbackMaxDelay(int newval)
java
int set_callbackMaxDelay(int newval)
uwp
async Task<int> set_callbackMaxDelay(int newval)
py
set_callbackMaxDelay(newval)
php
function set_callbackMaxDelay($newval)
es
async set_callbackMaxDelay(newval)
cmd
YNetwork target set_callbackMaxDelay newval

Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvalan integer corresponding to the waiting time between two HTTP callbacks when there is nothing new

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_callbackMethod()
network→setCallbackMethod()
network.set_callbackMethod()network→set_callbackMethod()[network setCallbackMethod: ]network.set_callbackMethod()network.set_callbackMethod()network.set_callbackMethod()network.set_callbackMethod()network.set_callbackMethod()network.set_callbackMethod()network.set_callbackMethod()network→set_callbackMethod()network.set_callbackMethod()YNetwork set_callbackMethod

Changes the HTTP method used to notify callbacks for significant state changes.

js
function set_callbackMethod(newval)
cpp
int set_callbackMethod(Y_CALLBACKMETHOD_enum newval)
m
-(int) setCallbackMethod: (Y_CALLBACKMETHOD_enum) newval
pas
integer set_callbackMethod(newval: Integer): integer
vb
function set_callbackMethod(ByVal newval As Integer) As Integer
cs
int set_callbackMethod(int newval)
dnp
int set_callbackMethod(int newval)
java
int set_callbackMethod(int newval)
uwp
async Task<int> set_callbackMethod(int newval)
py
set_callbackMethod(newval)
php
function set_callbackMethod($newval)
es
async set_callbackMethod(newval)
cmd
YNetwork target set_callbackMethod newval

Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala value among Y_CALLBACKMETHOD_POST, Y_CALLBACKMETHOD_GET and Y_CALLBACKMETHOD_PUT corresponding to the HTTP method used to notify callbacks for significant state changes

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_callbackMinDelay()
network→setCallbackMinDelay()
network.set_callbackMinDelay()network→set_callbackMinDelay()[network setCallbackMinDelay: ]network.set_callbackMinDelay()network.set_callbackMinDelay()network.set_callbackMinDelay()network.set_callbackMinDelay()network.set_callbackMinDelay()network.set_callbackMinDelay()network.set_callbackMinDelay()network→set_callbackMinDelay()network.set_callbackMinDelay()YNetwork set_callbackMinDelay

Changes the minimum waiting time between two HTTP callbacks, in seconds.

js
function set_callbackMinDelay(newval)
cpp
int set_callbackMinDelay(int newval)
m
-(int) setCallbackMinDelay: (int) newval
pas
integer set_callbackMinDelay(newval: LongInt): integer
vb
function set_callbackMinDelay(ByVal newval As Integer) As Integer
cs
int set_callbackMinDelay(int newval)
dnp
int set_callbackMinDelay(int newval)
java
int set_callbackMinDelay(int newval)
uwp
async Task<int> set_callbackMinDelay(int newval)
py
set_callbackMinDelay(newval)
php
function set_callbackMinDelay($newval)
es
async set_callbackMinDelay(newval)
cmd
YNetwork target set_callbackMinDelay newval

Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvalan integer corresponding to the minimum waiting time between two HTTP callbacks, in seconds

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_callbackSchedule()
network→setCallbackSchedule()
network.set_callbackSchedule()network→set_callbackSchedule()[network setCallbackSchedule: ]network.set_callbackSchedule()network.set_callbackSchedule()network.set_callbackSchedule()network.set_callbackSchedule()network.set_callbackSchedule()network.set_callbackSchedule()network.set_callbackSchedule()network→set_callbackSchedule()network.set_callbackSchedule()YNetwork set_callbackSchedule

Changes the HTTP callback schedule strategy, as a text string.

js
function set_callbackSchedule(newval)
cpp
int set_callbackSchedule(string newval)
m
-(int) setCallbackSchedule: (NSString*) newval
pas
integer set_callbackSchedule(newval: string): integer
vb
function set_callbackSchedule(ByVal newval As String) As Integer
cs
int set_callbackSchedule(string newval)
dnp
int set_callbackSchedule(string newval)
java
int set_callbackSchedule(String newval)
uwp
async Task<int> set_callbackSchedule(string newval)
py
set_callbackSchedule(newval)
php
function set_callbackSchedule($newval)
es
async set_callbackSchedule(newval)
cmd
YNetwork target set_callbackSchedule newval

Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string corresponding to the HTTP callback schedule strategy, as a text string

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_callbackUrl()
network→setCallbackUrl()
network.set_callbackUrl()network→set_callbackUrl()[network setCallbackUrl: ]network.set_callbackUrl()network.set_callbackUrl()network.set_callbackUrl()network.set_callbackUrl()network.set_callbackUrl()network.set_callbackUrl()network.set_callbackUrl()network→set_callbackUrl()network.set_callbackUrl()YNetwork set_callbackUrl

Changes the callback URL to notify significant state changes.

js
function set_callbackUrl(newval)
cpp
int set_callbackUrl(string newval)
m
-(int) setCallbackUrl: (NSString*) newval
pas
integer set_callbackUrl(newval: string): integer
vb
function set_callbackUrl(ByVal newval As String) As Integer
cs
int set_callbackUrl(string newval)
dnp
int set_callbackUrl(string newval)
java
int set_callbackUrl(String newval)
uwp
async Task<int> set_callbackUrl(string newval)
py
set_callbackUrl(newval)
php
function set_callbackUrl($newval)
es
async set_callbackUrl(newval)
cmd
YNetwork target set_callbackUrl newval

Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string corresponding to the callback URL to notify significant state changes

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_defaultPage()
network→setDefaultPage()
network.set_defaultPage()network→set_defaultPage()[network setDefaultPage: ]network.set_defaultPage()network.set_defaultPage()network.set_defaultPage()network.set_defaultPage()network.set_defaultPage()network.set_defaultPage()network.set_defaultPage()network→set_defaultPage()network.set_defaultPage()YNetwork set_defaultPage

Changes the default HTML page returned by the hub.

js
function set_defaultPage(newval)
cpp
int set_defaultPage(string newval)
m
-(int) setDefaultPage: (NSString*) newval
pas
integer set_defaultPage(newval: string): integer
vb
function set_defaultPage(ByVal newval As String) As Integer
cs
int set_defaultPage(string newval)
dnp
int set_defaultPage(string newval)
java
int set_defaultPage(String newval)
uwp
async Task<int> set_defaultPage(string newval)
py
set_defaultPage(newval)
php
function set_defaultPage($newval)
es
async set_defaultPage(newval)
cmd
YNetwork target set_defaultPage newval

If not value are set the hub return "index.html" which is the web interface of the hub. It is possible to change this page for file that has been uploaded on the hub. The maximum filename size is 15 characters. When you change this parameter, remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string corresponding to the default HTML page returned by the hub

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_discoverable()
network→setDiscoverable()
network.set_discoverable()network→set_discoverable()[network setDiscoverable: ]network.set_discoverable()network.set_discoverable()network.set_discoverable()network.set_discoverable()network.set_discoverable()network.set_discoverable()network.set_discoverable()network→set_discoverable()network.set_discoverable()YNetwork set_discoverable

Changes the activation state of the multicast announce protocols to allow easy discovery of the module in the network neighborhood (uPnP/Bonjour protocol).

js
function set_discoverable(newval)
cpp
int set_discoverable(Y_DISCOVERABLE_enum newval)
m
-(int) setDiscoverable: (Y_DISCOVERABLE_enum) newval
pas
integer set_discoverable(newval: Integer): integer
vb
function set_discoverable(ByVal newval As Integer) As Integer
cs
int set_discoverable(int newval)
dnp
int set_discoverable(int newval)
java
int set_discoverable(int newval)
uwp
async Task<int> set_discoverable(int newval)
py
set_discoverable(newval)
php
function set_discoverable($newval)
es
async set_discoverable(newval)
cmd
YNetwork target set_discoverable newval

Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvaleither Y_DISCOVERABLE_FALSE or Y_DISCOVERABLE_TRUE, according to the activation state of the multicast announce protocols to allow easy discovery of the module in the network neighborhood (uPnP/Bonjour protocol)

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_httpPort()
network→setHttpPort()
network.set_httpPort()network→set_httpPort()[network setHttpPort: ]network.set_httpPort()network.set_httpPort()network.set_httpPort()network.set_httpPort()network.set_httpPort()network.set_httpPort()network.set_httpPort()network→set_httpPort()network.set_httpPort()YNetwork set_httpPort

Changes the the TCP port used to serve the hub web UI.

js
function set_httpPort(newval)
cpp
int set_httpPort(int newval)
m
-(int) setHttpPort: (int) newval
pas
integer set_httpPort(newval: LongInt): integer
vb
function set_httpPort(ByVal newval As Integer) As Integer
cs
int set_httpPort(int newval)
dnp
int set_httpPort(int newval)
java
int set_httpPort(int newval)
uwp
async Task<int> set_httpPort(int newval)
py
set_httpPort(newval)
php
function set_httpPort($newval)
es
async set_httpPort(newval)
cmd
YNetwork target set_httpPort newval

The default value is port 80, which is the default for all Web servers. Regardless of the value set here, the hub will always reply on port 4444, which is used by default by Yoctopuce API library. When you change this parameter, remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvalan integer corresponding to the the TCP port used to serve the hub web UI

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_logicalName()
network→setLogicalName()
network.set_logicalName()network→set_logicalName()[network setLogicalName: ]network.set_logicalName()network.set_logicalName()network.set_logicalName()network.set_logicalName()network.set_logicalName()network.set_logicalName()network.set_logicalName()network→set_logicalName()network.set_logicalName()YNetwork set_logicalName

Changes the logical name of the network interface.

js
function set_logicalName(newval)
cpp
int set_logicalName(string newval)
m
-(int) setLogicalName: (NSString*) newval
pas
integer set_logicalName(newval: string): integer
vb
function set_logicalName(ByVal newval As String) As Integer
cs
int set_logicalName(string newval)
dnp
int set_logicalName(string newval)
java
int set_logicalName(String newval)
uwp
async Task<int> set_logicalName(string newval)
py
set_logicalName(newval)
php
function set_logicalName($newval)
es
async set_logicalName(newval)
cmd
YNetwork target set_logicalName newval

You can use yCheckLogicalName() prior to this call to make sure that your parameter is valid. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string corresponding to the logical name of the network interface.

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_ntpServer()
network→setNtpServer()
network.set_ntpServer()network→set_ntpServer()[network setNtpServer: ]network.set_ntpServer()network.set_ntpServer()network.set_ntpServer()network.set_ntpServer()network.set_ntpServer()network.set_ntpServer()network.set_ntpServer()network→set_ntpServer()network.set_ntpServer()YNetwork set_ntpServer

Changes the IP address of the NTP server to be used by the module.

js
function set_ntpServer(newval)
cpp
int set_ntpServer(string newval)
m
-(int) setNtpServer: (NSString*) newval
pas
integer set_ntpServer(newval: string): integer
vb
function set_ntpServer(ByVal newval As String) As Integer
cs
int set_ntpServer(string newval)
dnp
int set_ntpServer(string newval)
java
int set_ntpServer(String newval)
uwp
async Task<int> set_ntpServer(string newval)
py
set_ntpServer(newval)
php
function set_ntpServer($newval)
es
async set_ntpServer(newval)
cmd
YNetwork target set_ntpServer newval

Use an empty string to restore the factory set address. Remember to call the saveToFlash() method and then to reboot the module to apply this setting.

Parameters :

newvala string corresponding to the IP address of the NTP server to be used by the module

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_periodicCallbackSchedule()
network→setPeriodicCallbackSchedule()
network.set_periodicCallbackSchedule()network→set_periodicCallbackSchedule()[network setPeriodicCallbackSchedule: ]network.set_periodicCallbackSchedule()network.set_periodicCallbackSchedule()network.set_periodicCallbackSchedule()network.set_periodicCallbackSchedule()network.set_periodicCallbackSchedule()network.set_periodicCallbackSchedule()network.set_periodicCallbackSchedule()network→set_periodicCallbackSchedule()network.set_periodicCallbackSchedule()YNetwork set_periodicCallbackSchedule

Setup periodic HTTP callbacks (simplified function).

js
function set_periodicCallbackSchedule(interval, offset)
cpp
int set_periodicCallbackSchedule(string interval, int offset)
m
-(int) setPeriodicCallbackSchedule: (NSString*) interval
  : (int) offset
pas
LongInt set_periodicCallbackSchedule(interval: string,
  offset: LongInt): LongInt
vb
function set_periodicCallbackSchedule() As Integer
cs
int set_periodicCallbackSchedule(string interval, int offset)
dnp
int set_periodicCallbackSchedule(string interval, int offset)
java
int set_periodicCallbackSchedule(String interval, int offset)
uwp
async Task<int> set_periodicCallbackSchedule(string interval,
  int offset)
py
set_periodicCallbackSchedule(interval, offset)
php
function set_periodicCallbackSchedule($interval, $offset)
es
async set_periodicCallbackSchedule(interval, offset)
cmd
YNetwork target set_periodicCallbackSchedule interval offset

Parameters :

intervala string representing the callback periodicity, expressed in seconds, minutes or hours, eg. "60s", "5m", "1h", "48h".
offsetan integer representing the time offset relative to the period when the callback should occur. For instance, if the periodicity is 24h, an offset of 7 will make the callback occur each day at 7AM.

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_primaryDNS()
network→setPrimaryDNS()
network.set_primaryDNS()network→set_primaryDNS()[network setPrimaryDNS: ]network.set_primaryDNS()network.set_primaryDNS()network.set_primaryDNS()network.set_primaryDNS()network.set_primaryDNS()network.set_primaryDNS()network.set_primaryDNS()network→set_primaryDNS()network.set_primaryDNS()YNetwork set_primaryDNS

Changes the IP address of the primary name server to be used by the module.

js
function set_primaryDNS(newval)
cpp
int set_primaryDNS(string newval)
m
-(int) setPrimaryDNS: (NSString*) newval
pas
integer set_primaryDNS(newval: string): integer
vb
function set_primaryDNS(ByVal newval As String) As Integer
cs
int set_primaryDNS(string newval)
dnp
int set_primaryDNS(string newval)
java
int set_primaryDNS(String newval)
uwp
async Task<int> set_primaryDNS(string newval)
py
set_primaryDNS(newval)
php
function set_primaryDNS($newval)
es
async set_primaryDNS(newval)
cmd
YNetwork target set_primaryDNS newval

When using DHCP, if a value is specified, it overrides the value received from the DHCP server. Remember to call the saveToFlash() method and then to reboot the module to apply this setting.

Parameters :

newvala string corresponding to the IP address of the primary name server to be used by the module

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_secondaryDNS()
network→setSecondaryDNS()
network.set_secondaryDNS()network→set_secondaryDNS()[network setSecondaryDNS: ]network.set_secondaryDNS()network.set_secondaryDNS()network.set_secondaryDNS()network.set_secondaryDNS()network.set_secondaryDNS()network.set_secondaryDNS()network.set_secondaryDNS()network→set_secondaryDNS()network.set_secondaryDNS()YNetwork set_secondaryDNS

Changes the IP address of the secondary name server to be used by the module.

js
function set_secondaryDNS(newval)
cpp
int set_secondaryDNS(string newval)
m
-(int) setSecondaryDNS: (NSString*) newval
pas
integer set_secondaryDNS(newval: string): integer
vb
function set_secondaryDNS(ByVal newval As String) As Integer
cs
int set_secondaryDNS(string newval)
dnp
int set_secondaryDNS(string newval)
java
int set_secondaryDNS(String newval)
uwp
async Task<int> set_secondaryDNS(string newval)
py
set_secondaryDNS(newval)
php
function set_secondaryDNS($newval)
es
async set_secondaryDNS(newval)
cmd
YNetwork target set_secondaryDNS newval

When using DHCP, if a value is specified, it overrides the value received from the DHCP server. Remember to call the saveToFlash() method and then to reboot the module to apply this setting.

Parameters :

newvala string corresponding to the IP address of the secondary name server to be used by the module

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_userData()
network→setUserData()
network.set_userData()network→set_userData()[network setUserData: ]network.set_userData()network.set_userData()network.set_userData()network.set_userData()network.set_userData()network→set_userData()network.set_userData()

Stores a user context provided as argument in the userData attribute of the function.

js
function set_userData(data)
cpp
void set_userData(void * data)
m
-(void) setUserData: (id) data
pas
set_userData(data: Tobject)
vb
procedure set_userData(ByVal data As Object)
cs
void set_userData(object data)
java
void set_userData(Object data)
py
set_userData(data)
php
function set_userData($data)
es
async set_userData(data)

This attribute is never touched by the API, and is at disposal of the caller to store a context.

Parameters :

dataany kind of object to be stored

network→set_userPassword()
network→setUserPassword()
network.set_userPassword()network→set_userPassword()[network setUserPassword: ]network.set_userPassword()network.set_userPassword()network.set_userPassword()network.set_userPassword()network.set_userPassword()network.set_userPassword()network.set_userPassword()network→set_userPassword()network.set_userPassword()YNetwork set_userPassword

Changes the password for the "user" user.

js
function set_userPassword(newval)
cpp
int set_userPassword(string newval)
m
-(int) setUserPassword: (NSString*) newval
pas
integer set_userPassword(newval: string): integer
vb
function set_userPassword(ByVal newval As String) As Integer
cs
int set_userPassword(string newval)
dnp
int set_userPassword(string newval)
java
int set_userPassword(String newval)
uwp
async Task<int> set_userPassword(string newval)
py
set_userPassword(newval)
php
function set_userPassword($newval)
es
async set_userPassword(newval)
cmd
YNetwork target set_userPassword newval

This password becomes instantly required to perform any use of the module. If the specified value is an empty string, a password is not required anymore. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvala string corresponding to the password for the "user" user

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→set_wwwWatchdogDelay()
network→setWwwWatchdogDelay()
network.set_wwwWatchdogDelay()network→set_wwwWatchdogDelay()[network setWwwWatchdogDelay: ]network.set_wwwWatchdogDelay()network.set_wwwWatchdogDelay()network.set_wwwWatchdogDelay()network.set_wwwWatchdogDelay()network.set_wwwWatchdogDelay()network.set_wwwWatchdogDelay()network.set_wwwWatchdogDelay()network→set_wwwWatchdogDelay()network.set_wwwWatchdogDelay()YNetwork set_wwwWatchdogDelay

Changes the allowed downtime of the WWW link (in seconds) before triggering an automated reboot to try to recover Internet connectivity.

js
function set_wwwWatchdogDelay(newval)
cpp
int set_wwwWatchdogDelay(int newval)
m
-(int) setWwwWatchdogDelay: (int) newval
pas
integer set_wwwWatchdogDelay(newval: LongInt): integer
vb
function set_wwwWatchdogDelay(ByVal newval As Integer) As Integer
cs
int set_wwwWatchdogDelay(int newval)
dnp
int set_wwwWatchdogDelay(int newval)
java
int set_wwwWatchdogDelay(int newval)
uwp
async Task<int> set_wwwWatchdogDelay(int newval)
py
set_wwwWatchdogDelay(newval)
php
function set_wwwWatchdogDelay($newval)
es
async set_wwwWatchdogDelay(newval)
cmd
YNetwork target set_wwwWatchdogDelay newval

A zero value disables automated reboot in case of Internet connectivity loss. The smallest valid non-zero timeout is 90 seconds. Remember to call the saveToFlash() method of the module if the modification must be kept.

Parameters :

newvalan integer corresponding to the allowed downtime of the WWW link (in seconds) before triggering an automated reboot to try to recover Internet connectivity

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

network→triggerCallback()network.triggerCallback()network→triggerCallback()[network triggerCallback]network.triggerCallback()network.triggerCallback()network.triggerCallback()network.triggerCallback()network.triggerCallback()network.triggerCallback()network.triggerCallback()network→triggerCallback()network.triggerCallback()YNetwork triggerCallback

Trigger an HTTP callback quickly.

js
function triggerCallback()
cpp
int triggerCallback()
m
-(int) triggerCallback
pas
LongInt triggerCallback(): LongInt
vb
function triggerCallback() As Integer
cs
int triggerCallback()
dnp
int triggerCallback()
java
int triggerCallback()
uwp
async Task<int> triggerCallback()
py
triggerCallback()
php
function triggerCallback()
es
async triggerCallback()
cmd
YNetwork target triggerCallback

This function can even be called within an HTTP callback, in which case the next callback will be triggered 5 seconds after the end of the current callback, regardless if the minimum time between callbacks configured in the device.

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

network→unmuteValueCallbacks()network.unmuteValueCallbacks()network→unmuteValueCallbacks()[network unmuteValueCallbacks]network.unmuteValueCallbacks()network.unmuteValueCallbacks()network.unmuteValueCallbacks()network.unmuteValueCallbacks()network.unmuteValueCallbacks()network.unmuteValueCallbacks()network.unmuteValueCallbacks()network→unmuteValueCallbacks()network.unmuteValueCallbacks()YNetwork unmuteValueCallbacks

Re-enables the propagation of every new advertised value to the parent hub.

js
function unmuteValueCallbacks()
cpp
int unmuteValueCallbacks()
m
-(int) unmuteValueCallbacks
pas
LongInt unmuteValueCallbacks(): LongInt
vb
function unmuteValueCallbacks() As Integer
cs
int unmuteValueCallbacks()
dnp
int unmuteValueCallbacks()
java
int unmuteValueCallbacks()
uwp
async Task<int> unmuteValueCallbacks()
py
unmuteValueCallbacks()
php
function unmuteValueCallbacks()
es
async unmuteValueCallbacks()
cmd
YNetwork target unmuteValueCallbacks

This function reverts the effect of a previous call to muteValueCallbacks(). Remember to call the saveToFlash() method of the module if the modification must be kept.

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

network→useDHCP()network.useDHCP()network→useDHCP()[network useDHCP: ]network.useDHCP()network.useDHCP()network.useDHCP()network.useDHCP()network.useDHCP()network.useDHCP()network.useDHCP()network→useDHCP()network.useDHCP()YNetwork useDHCP

Changes the configuration of the network interface to enable the use of an IP address received from a DHCP server.

js
function useDHCP(fallbackIpAddr, fallbackSubnetMaskLen, fallbackRouter)
cpp
int useDHCP(string fallbackIpAddr,
  int fallbackSubnetMaskLen,
  string fallbackRouter)
m
-(int) useDHCP: (NSString*) fallbackIpAddr
  : (int) fallbackSubnetMaskLen
  : (NSString*) fallbackRouter
pas
LongInt useDHCP(fallbackIpAddr: string,
  fallbackSubnetMaskLen: LongInt,
  fallbackRouter: string): LongInt
vb
function useDHCP() As Integer
cs
int useDHCP(string fallbackIpAddr,
  int fallbackSubnetMaskLen,
  string fallbackRouter)
dnp
int useDHCP(string fallbackIpAddr,
  int fallbackSubnetMaskLen,
  string fallbackRouter)
java
int useDHCP(String fallbackIpAddr,
  int fallbackSubnetMaskLen,
  String fallbackRouter)
uwp
async Task<int> useDHCP(string fallbackIpAddr,
  int fallbackSubnetMaskLen,
  string fallbackRouter)
py
useDHCP(fallbackIpAddr, fallbackSubnetMaskLen, fallbackRouter)
php
function useDHCP($fallbackIpAddr, $fallbackSubnetMaskLen, $fallbackRouter)
es
async useDHCP(fallbackIpAddr, fallbackSubnetMaskLen, fallbackRouter)
cmd
YNetwork target useDHCP fallbackIpAddr fallbackSubnetMaskLen fallbackRouter

Until an address is received from a DHCP server, the module uses the IP parameters specified to this function. Remember to call the saveToFlash() method and then to reboot the module to apply this setting.

Parameters :

fallbackIpAddrfallback IP address, to be used when no DHCP reply is received
fallbackSubnetMaskLenfallback subnet mask length when no DHCP reply is received, as an integer (e.g. 24 means 255.255.255.0)
fallbackRouterfallback router IP address, to be used when no DHCP reply is received

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

network→useDHCPauto()network.useDHCPauto()network→useDHCPauto()[network useDHCPauto]network.useDHCPauto()network.useDHCPauto()network.useDHCPauto()network.useDHCPauto()network.useDHCPauto()network.useDHCPauto()network.useDHCPauto()network→useDHCPauto()network.useDHCPauto()YNetwork useDHCPauto

Changes the configuration of the network interface to enable the use of an IP address received from a DHCP server.

js
function useDHCPauto()
cpp
int useDHCPauto()
m
-(int) useDHCPauto
pas
LongInt useDHCPauto(): LongInt
vb
function useDHCPauto() As Integer
cs
int useDHCPauto()
dnp
int useDHCPauto()
java
int useDHCPauto()
uwp
async Task<int> useDHCPauto()
py
useDHCPauto()
php
function useDHCPauto()
es
async useDHCPauto()
cmd
YNetwork target useDHCPauto

Until an address is received from a DHCP server, the module uses an IP of the network 169.254.0.0/16 (APIPA). Remember to call the saveToFlash() method and then to reboot the module to apply this setting.

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

network→useStaticIP()network.useStaticIP()network→useStaticIP()[network useStaticIP: ]network.useStaticIP()network.useStaticIP()network.useStaticIP()network.useStaticIP()network.useStaticIP()network.useStaticIP()network.useStaticIP()network→useStaticIP()network.useStaticIP()YNetwork useStaticIP

Changes the configuration of the network interface to use a static IP address.

js
function useStaticIP(ipAddress, subnetMaskLen, router)
cpp
int useStaticIP(string ipAddress, int subnetMaskLen, string router)
m
-(int) useStaticIP: (NSString*) ipAddress
  : (int) subnetMaskLen
  : (NSString*) router
pas
LongInt useStaticIP(ipAddress: string,
  subnetMaskLen: LongInt,
  router: string): LongInt
vb
function useStaticIP() As Integer
cs
int useStaticIP(string ipAddress,
  int subnetMaskLen,
  string router)
dnp
int useStaticIP(string ipAddress,
  int subnetMaskLen,
  string router)
java
int useStaticIP(String ipAddress,
  int subnetMaskLen,
  String router)
uwp
async Task<int> useStaticIP(string ipAddress,
  int subnetMaskLen,
  string router)
py
useStaticIP(ipAddress, subnetMaskLen, router)
php
function useStaticIP($ipAddress, $subnetMaskLen, $router)
es
async useStaticIP(ipAddress, subnetMaskLen, router)
cmd
YNetwork target useStaticIP ipAddress subnetMaskLen router

Remember to call the saveToFlash() method and then to reboot the module to apply this setting.

Parameters :

ipAddressdevice IP address
subnetMaskLensubnet mask length, as an integer (e.g. 24 means 255.255.255.0)
routerrouter IP address (default gateway)

Returns :

YAPI_SUCCESS when the call succeeds.

On failure, throws an exception or returns a negative error code.

network→wait_async()network.wait_async()network.wait_async()

Waits for all pending asynchronous commands on the module to complete, and invoke the user-provided callback function.

js
function wait_async(callback, context)
es
wait_async(callback, context)

The callback function can therefore freely issue synchronous or asynchronous commands, without risking to block the JavaScript VM.

Parameters :

callbackcallback function that is invoked when all pending commands on the module are completed. The callback function receives two arguments: the caller-specific context object and the receiving function object.
contextcaller-specific object that is passed as-is to the callback function

Returns :

nothing.

8.4. Class YFiles

Filesystem control interface, available for instance in the Yocto-Buzzer, the Yocto-Color-V2, the YoctoHub-Ethernet or the YoctoHub-Wireless-g

The YFiles class is used to access the filesystem embedded on some Yoctopuce devices. This filesystem makes it possible for instance to design a custom web UI (for networked devices) or to add fonts (on display devices).

In order to use the functions described here, you should include:

js
<script type='text/javascript' src='yocto_files.js'></script>
cpp
#include "yocto_files.h"
m
#import "yocto_files.h"
pas
uses yocto_files;
vb
yocto_files.vb
cs
yocto_files.cs
dnp
import YoctoProxyAPI.YFilesProxy
java
import com.yoctopuce.YoctoAPI.YFiles;
uwp
import com.yoctopuce.YoctoAPI.YFiles;
py
from yocto_files import *
php
require_once('yocto_files.php');
es
in HTML: <script src="../../lib/yocto_files.js"></script>
in node.js: require('yoctolib-es2017/yocto_files.js');
vi
YFiles.vi
Global functions
YFiles.FindFiles(func)

Retrieves a filesystem for a given identifier.

YFiles.FindFilesInContext(yctx, func)

Retrieves a filesystem for a given identifier in a YAPI context.

YFiles.FirstFiles()

Starts the enumeration of filesystems currently accessible.

YFiles.FirstFilesInContext(yctx)

Starts the enumeration of filesystems currently accessible.

YFiles.GetSimilarFunctions()

Enumerates all functions of type Files available on the devices currently reachable by the library, and returns their unique hardware ID.

YFiles properties
files→AdvertisedValue [read-only]

Short string representing the current state of the function.

files→FilesCount [read-only]

Number of files currently loaded in the filesystem.

files→FriendlyName [read-only]

Global identifier of the function in the format MODULE_NAME.FUNCTION_NAME.

files→FunctionId [read-only]

Hardware identifier of the filesystem, without reference to the module.

files→HardwareId [read-only]

Unique hardware identifier of the function in the form SERIAL.FUNCTIONID.

files→IsOnline [read-only]

Checks if the function is currently reachable.

files→LogicalName [writable]

Logical name of the function.

files→SerialNumber [read-only]

Serial number of the module, as set by the factory.

YFiles methods
files→clearCache()

Invalidates the cache.

files→describe()

Returns a short text that describes unambiguously the instance of the filesystem in the form TYPE(NAME)=SERIAL.FUNCTIONID.

files→download(pathname)

Downloads the requested file and returns a binary buffer with its content.

files→download_async(pathname, callback, context)

Downloads the requested file and returns a binary buffer with its content.

files→fileExist(filename)

Test if a file exist on the filesystem of the module.

files→format_fs()

Reinitialize the filesystem to its clean, unfragmented, empty state.

files→get_advertisedValue()

Returns the current value of the filesystem (no more than 6 characters).

files→get_errorMessage()

Returns the error message of the latest error with the filesystem.

files→get_errorType()

Returns the numerical error code of the latest error with the filesystem.

files→get_filesCount()

Returns the number of files currently loaded in the filesystem.

files→get_freeSpace()

Returns the free space for uploading new files to the filesystem, in bytes.

files→get_friendlyName()

Returns a global identifier of the filesystem in the format MODULE_NAME.FUNCTION_NAME.

files→get_functionDescriptor()

Returns a unique identifier of type YFUN_DESCR corresponding to the function.

files→get_functionId()

Returns the hardware identifier of the filesystem, without reference to the module.

files→get_hardwareId()

Returns the unique hardware identifier of the filesystem in the form SERIAL.FUNCTIONID.

files→get_list(pattern)

Returns a list of YFileRecord objects that describe files currently loaded in the filesystem.

files→get_logicalName()

Returns the logical name of the filesystem.

files→get_module()

Gets the YModule object for the device on which the function is located.

files→get_module_async(callback, context)

Gets the YModule object for the device on which the function is located (asynchronous version).

files→get_serialNumber()

Returns the serial number of the module, as set by the factory.

files→get_userData()

Returns the value of the userData attribute, as previously stored using method set_userData.

files→isOnline()

Checks if the filesystem is currently reachable, without raising any error.

files→isOnline_async(callback, context)

Checks if the filesystem is currently reachable, without raising any error (asynchronous version).

files→isReadOnly()

Test if the function is readOnly.

files→load(msValidity)

Preloads the filesystem cache with a specified validity duration.

files→loadAttribute(attrName)

Returns the current value of a single function attribute, as a text string, as quickly as possible but without using the cached value.

files→load_async(msValidity, callback, context)

Preloads the filesystem cache with a specified validity duration (asynchronous version).

files→muteValueCallbacks()

Disables the propagation of every new advertised value to the parent hub.

files→nextFiles()

Continues the enumeration of filesystems started using yFirstFiles().

files→registerValueCallback(callback)

Registers the callback function that is invoked on every change of advertised value.

files→remove(pathname)

Deletes a file, given by its full path name, from the filesystem.

files→set_logicalName(newval)

Changes the logical name of the filesystem.

files→set_userData(data)

Stores a user context provided as argument in the userData attribute of the function.

files→unmuteValueCallbacks()

Re-enables the propagation of every new advertised value to the parent hub.

files→upload(pathname, content)

Uploads a file to the filesystem, to the specified full path name.

files→wait_async(callback, context)

Waits for all pending asynchronous commands on the module to complete, and invoke the user-provided callback function.

YFiles.FindFiles()
YFiles.FindFiles()
yFindFiles()yFindFiles()[YFiles FindFiles: ]yFindFiles()yFindFiles()YFiles.FindFiles()YFiles.FindFiles()YFiles.FindFiles()YFiles.FindFiles()YFiles.FindFiles()yFindFiles()YFiles.FindFiles()

Retrieves a filesystem for a given identifier.

js
function yFindFiles(func)
cpp
YFiles* yFindFiles(string func)
m
+(YFiles*) FindFiles: (NSString*) func
pas
TYFiles yFindFiles(func: string): TYFiles
vb
function yFindFiles(ByVal func As String) As YFiles
cs
static YFiles FindFiles(string func)
dnp
static YFilesProxy FindFiles(string func)
java
static YFiles FindFiles(String func)
uwp
static YFiles FindFiles(string func)
py
FindFiles(func)
php
function yFindFiles($func)
es
static FindFiles(func)

The identifier can be specified using several formats:

This function does not require that the filesystem is online at the time it is invoked. The returned object is nevertheless valid. Use the method YFiles.isOnline() to test if the filesystem is indeed online at a given time. In case of ambiguity when looking for a filesystem by logical name, no error is notified: the first instance found is returned. The search is performed first by hardware name, then by logical name.

If a call to this object's is_online() method returns FALSE although you are certain that the matching device is plugged, make sure that you did call registerHub() at application initialization time.

Parameters :

funca string that uniquely characterizes the filesystem, for instance YBUZZER2.files.

Returns :

a YFiles object allowing you to drive the filesystem.

YFiles.FindFilesInContext()
YFiles.FindFilesInContext()
YFiles.FindFilesInContext()YFiles.FindFilesInContext()YFiles.FindFilesInContext()

Retrieves a filesystem for a given identifier in a YAPI context.

java
static YFiles FindFilesInContext(YAPIContext yctx, String func)
uwp
static YFiles FindFilesInContext(YAPIContext yctx, string func)
es
static FindFilesInContext(yctx, func)

The identifier can be specified using several formats:

This function does not require that the filesystem is online at the time it is invoked. The returned object is nevertheless valid. Use the method YFiles.isOnline() to test if the filesystem is indeed online at a given time. In case of ambiguity when looking for a filesystem by logical name, no error is notified: the first instance found is returned. The search is performed first by hardware name, then by logical name.

Parameters :

yctxa YAPI context
funca string that uniquely characterizes the filesystem, for instance YBUZZER2.files.

Returns :

a YFiles object allowing you to drive the filesystem.

YFiles.FirstFiles()
YFiles.FirstFiles()
yFirstFiles()yFirstFiles()[YFiles FirstFiles]yFirstFiles()yFirstFiles()YFiles.FirstFiles()YFiles.FirstFiles()YFiles.FirstFiles()YFiles.FirstFiles()yFirstFiles()YFiles.FirstFiles()

Starts the enumeration of filesystems currently accessible.

js
function yFirstFiles()
cpp
YFiles * yFirstFiles()
m
+(YFiles*) FirstFiles
pas
TYFiles yFirstFiles(): TYFiles
vb
function yFirstFiles() As YFiles
cs
static YFiles FirstFiles()
java
static YFiles FirstFiles()
uwp
static YFiles FirstFiles()
py
FirstFiles()
php
function yFirstFiles()
es
static FirstFiles()

Use the method YFiles.nextFiles() to iterate on next filesystems.

Returns :

a pointer to a YFiles object, corresponding to the first filesystem currently online, or a null pointer if there are none.

YFiles.FirstFilesInContext()
YFiles.FirstFilesInContext()
YFiles.FirstFilesInContext()YFiles.FirstFilesInContext()YFiles.FirstFilesInContext()

Starts the enumeration of filesystems currently accessible.

java
static YFiles FirstFilesInContext(YAPIContext yctx)
uwp
static YFiles FirstFilesInContext(YAPIContext yctx)
es
static FirstFilesInContext(yctx)

Use the method YFiles.nextFiles() to iterate on next filesystems.

Parameters :

yctxa YAPI context.

Returns :

a pointer to a YFiles object, corresponding to the first filesystem currently online, or a null pointer if there are none.

YFiles.GetSimilarFunctions()
YFiles.GetSimilarFunctions()
YFiles.GetSimilarFunctions()

Enumerates all functions of type Files available on the devices currently reachable by the library, and returns their unique hardware ID.

dnp
static new string[] GetSimilarFunctions()

Each of these IDs can be provided as argument to the method YFiles.FindFiles to obtain an object that can control the corresponding device.

Returns :

an array of strings, each string containing the unique hardwareId of a device function currently connected.

files→AdvertisedValuefiles.AdvertisedValue

Short string representing the current state of the function.

dnp
string AdvertisedValue

files→FilesCountfiles.FilesCount

Number of files currently loaded in the filesystem.

dnp
int FilesCount

files→FriendlyNamefiles.FriendlyName

Global identifier of the function in the format MODULE_NAME.FUNCTION_NAME.

dnp
string FriendlyName

The returned string uses the logical names of the module and of the function if they are defined, otherwise the serial number of the module and the hardware identifier of the function (for example: MyCustomName.relay1)

files→FunctionIdfiles.FunctionId

Hardware identifier of the filesystem, without reference to the module.

dnp
string FunctionId

For example relay1

files→HardwareIdfiles.HardwareId

Unique hardware identifier of the function in the form SERIAL.FUNCTIONID.

dnp
string HardwareId

The unique hardware identifier is composed of the device serial number and of the hardware identifier of the function (for example RELAYLO1-123456.relay1).

files→IsOnlinefiles.IsOnline

Checks if the function is currently reachable.

dnp
bool IsOnline

If there is a cached value for the function in cache, that has not yet expired, the device is considered reachable. No exception is raised if there is an error while trying to contact the device hosting the function.

files→LogicalNamefiles.LogicalName

Logical name of the function.

dnp
string LogicalName

Writable. You can use yCheckLogicalName() prior to this call to make sure that your parameter is valid. Remember to call the saveToFlash() method of the module if the modification must be kept.

files→SerialNumberfiles.SerialNumber

Serial number of the module, as set by the factory.

dnp
string SerialNumber

files→clearCache()files.clearCache()files→clearCache()[files clearCache]files.clearCache()files.clearCache()files.clearCache()files.clearCache()files.clearCache()files→clearCache()files.clearCache()

Invalidates the cache.

js
function clearCache()
cpp
void clearCache()
m
-(void) clearCache
pas
clearCache()
vb
procedure clearCache()
cs
void clearCache()
java
void clearCache()
py
clearCache()
php
function clearCache()
es
async clearCache()

Invalidates the cache of the filesystem attributes. Forces the next call to get_xxx() or loadxxx() to use values that come from the device.

files→describe()files.describe()files→describe()[files describe]files.describe()files.describe()files.describe()files.describe()files.describe()files→describe()files.describe()

Returns a short text that describes unambiguously the instance of the filesystem in the form TYPE(NAME)=SERIAL.FUNCTIONID.

js
function describe()
cpp
string describe()
m
-(NSString*) describe
pas
string describe(): string
vb
function describe() As String
cs
string describe()
java
String describe()
py
describe()
php
function describe()
es
async describe()

More precisely, TYPE is the type of the function, NAME it the name used for the first access to the function, SERIAL is the serial number of the module if the module is connected or "unresolved", and FUNCTIONID is the hardware identifier of the function if the module is connected. For example, this method returns Relay(MyCustomName.relay1)=RELAYLO1-123456.relay1 if the module is already connected or Relay(BadCustomeName.relay1)=unresolved if the module has not yet been connected. This method does not trigger any USB or TCP transaction and can therefore be used in a debugger.

Returns :

a string that describes the filesystem (ex: Relay(MyCustomName.relay1)=RELAYLO1-123456.relay1)

files→download()files.download()files→download()[files download: ]files.download()files.download()files.download()files.download()files.download()files.download()files.download()files→download()files.download()YFiles download

Downloads the requested file and returns a binary buffer with its content.

js
function download(pathname)
cpp
string download(string pathname)
m
-(NSMutableData*) download: (NSString*) pathname
pas
TByteArray download(pathname: string): TByteArray
vb
function download() As Byte
cs
byte[] download(string pathname)
dnp
byte[] download(string pathname)
java
byte[] download(String pathname)
uwp
async Task<byte[]> download(string pathname)
py
download(pathname)
php
function download($pathname)
es
async download(pathname)
cmd
YFiles target download pathname

Parameters :

pathnamepath and name of the file to download

Returns :

a binary buffer with the file content

On failure, throws an exception or returns an empty content.

files→download_async()files.download_async()

Downloads the requested file and returns a binary buffer with its content.

js
function download_async(pathname, callback, context)

This is the asynchronous version that uses a callback to pass the result when the download is completed.

Parameters :

pathnamepath and name of the new file to load
callbackcallback function that is invoked when the w The callback function receives three arguments: - the user-specific context object - the YFiles object whose download_async was invoked - a binary buffer with the file content
contextuser-specific object that is passed as-is to the callback function

Returns :

nothing.

files→fileExist()files.fileExist()files→fileExist()[files fileExist: ]files.fileExist()files.fileExist()files.fileExist()files.fileExist()files.fileExist()files.fileExist()files.fileExist()files→fileExist()files.fileExist()YFiles fileExist

Test if a file exist on the filesystem of the module.

js
function fileExist(filename)
cpp
bool fileExist(string filename)
m
-(bool) fileExist: (NSString*) filename
pas
boolean fileExist(filename: string): boolean
vb
function fileExist() As Boolean
cs
bool fileExist(string filename)
dnp
bool fileExist(string filename)
java
boolean fileExist(String filename)
uwp
async Task<bool> fileExist(string filename)
py
fileExist(filename)
php
function fileExist($filename)
es
async fileExist(filename)
cmd
YFiles target fileExist filename

Parameters :

filenamethe file name to test.

Returns :

a true if the file exist, false otherwise.

On failure, throws an exception.

files→format_fs()files.format_fs()files→format_fs()[files format_fs]files.format_fs()files.format_fs()files.format_fs()files.format_fs()files.format_fs()files.format_fs()files.format_fs()files→format_fs()files.format_fs()YFiles format_fs

Reinitialize the filesystem to its clean, unfragmented, empty state.

js
function format_fs()
cpp
int format_fs()
m
-(int) format_fs
pas
LongInt format_fs(): LongInt
vb
function format_fs() As Integer
cs
int format_fs()
dnp
int format_fs()
java
int format_fs()
uwp
async Task<int> format_fs()
py
format_fs()
php
function format_fs()
es
async format_fs()
cmd
YFiles target format_fs

All files previously uploaded are permanently lost.

Returns :

YAPI_SUCCESS if the call succeeds.

On failure, throws an exception or returns a negative error code.

files→get_advertisedValue()
files→advertisedValue()
files.get_advertisedValue()files→get_advertisedValue()[files advertisedValue]files.get_advertisedValue()files.get_advertisedValue()files.get_advertisedValue()files.get_advertisedValue()files.get_advertisedValue()files.get_advertisedValue()files.get_advertisedValue()files→get_advertisedValue()files.get_advertisedValue()YFiles get_advertisedValue

Returns the current value of the filesystem (no more than 6 characters).

js
function get_advertisedValue()
cpp
string get_advertisedValue()
m
-(NSString*) advertisedValue
pas
string get_advertisedValue(): string
vb
function get_advertisedValue() As String
cs
string get_advertisedValue()
dnp
string get_advertisedValue()
java
String get_advertisedValue()
uwp
async Task<string> get_advertisedValue()
py
get_advertisedValue()
php
function get_advertisedValue()
es
async get_advertisedValue()
cmd
YFiles target get_advertisedValue

Returns :

a string corresponding to the current value of the filesystem (no more than 6 characters).

On failure, throws an exception or returns Y_ADVERTISEDVALUE_INVALID.

files→get_errorMessage()
files→errorMessage()
files.get_errorMessage()files→get_errorMessage()[files errorMessage]files.get_errorMessage()files.get_errorMessage()files.get_errorMessage()files.get_errorMessage()files.get_errorMessage()files→get_errorMessage()files.get_errorMessage()

Returns the error message of the latest error with the filesystem.

js
function get_errorMessage()
cpp
string get_errorMessage()
m
-(NSString*) errorMessage
pas
string get_errorMessage(): string
vb
function get_errorMessage() As String
cs
string get_errorMessage()
java
String get_errorMessage()
py
get_errorMessage()
php
function get_errorMessage()
es
get_errorMessage()

This method is mostly useful when using the Yoctopuce library with exceptions disabled.

Returns :

a string corresponding to the latest error message that occured while using the filesystem object

files→get_errorType()
files→errorType()
files.get_errorType()files→get_errorType()[files errorType]files.get_errorType()files.get_errorType()files.get_errorType()files.get_errorType()files.get_errorType()files→get_errorType()files.get_errorType()

Returns the numerical error code of the latest error with the filesystem.

js
function get_errorType()
cpp
YRETCODE get_errorType()
m
-(YRETCODE) errorType
pas
YRETCODE get_errorType(): YRETCODE
vb
function get_errorType() As YRETCODE
cs
YRETCODE get_errorType()
java
int get_errorType()
py
get_errorType()
php
function get_errorType()
es
get_errorType()

This method is mostly useful when using the Yoctopuce library with exceptions disabled.

Returns :

a number corresponding to the code of the latest error that occurred while using the filesystem object

files→get_filesCount()
files→filesCount()
files.get_filesCount()files→get_filesCount()[files filesCount]files.get_filesCount()files.get_filesCount()files.get_filesCount()files.get_filesCount()files.get_filesCount()files.get_filesCount()files.get_filesCount()files→get_filesCount()files.get_filesCount()YFiles get_filesCount

Returns the number of files currently loaded in the filesystem.

js
function get_filesCount()
cpp
int get_filesCount()
m
-(int) filesCount
pas
LongInt get_filesCount(): LongInt
vb
function get_filesCount() As Integer
cs
int get_filesCount()
dnp
int get_filesCount()
java
int get_filesCount()
uwp
async Task<int> get_filesCount()
py
get_filesCount()
php
function get_filesCount()
es
async get_filesCount()
cmd
YFiles target get_filesCount

Returns :

an integer corresponding to the number of files currently loaded in the filesystem

On failure, throws an exception or returns Y_FILESCOUNT_INVALID.

files→get_freeSpace()
files→freeSpace()
files.get_freeSpace()files→get_freeSpace()[files freeSpace]files.get_freeSpace()files.get_freeSpace()files.get_freeSpace()files.get_freeSpace()files.get_freeSpace()files.get_freeSpace()files.get_freeSpace()files→get_freeSpace()files.get_freeSpace()YFiles get_freeSpace

Returns the free space for uploading new files to the filesystem, in bytes.

js
function get_freeSpace()
cpp
int get_freeSpace()
m
-(int) freeSpace
pas
LongInt get_freeSpace(): LongInt
vb
function get_freeSpace() As Integer
cs
int get_freeSpace()
dnp
int get_freeSpace()
java
int get_freeSpace()
uwp
async Task<int> get_freeSpace()
py
get_freeSpace()
php
function get_freeSpace()
es
async get_freeSpace()
cmd
YFiles target get_freeSpace

Returns :

an integer corresponding to the free space for uploading new files to the filesystem, in bytes

On failure, throws an exception or returns Y_FREESPACE_INVALID.

files→get_friendlyName()
files→friendlyName()
files.get_friendlyName()files→get_friendlyName()[files friendlyName]files.get_friendlyName()files.get_friendlyName()files.get_friendlyName()files.get_friendlyName()files→get_friendlyName()files.get_friendlyName()

Returns a global identifier of the filesystem in the format MODULE_NAME.FUNCTION_NAME.

js
function get_friendlyName()
cpp
string get_friendlyName()
m
-(NSString*) friendlyName
cs
string get_friendlyName()
dnp
string get_friendlyName()
java
String get_friendlyName()
py
get_friendlyName()
php
function get_friendlyName()
es
async get_friendlyName()

The returned string uses the logical names of the module and of the filesystem if they are defined, otherwise the serial number of the module and the hardware identifier of the filesystem (for example: MyCustomName.relay1)

Returns :

a string that uniquely identifies the filesystem using logical names (ex: MyCustomName.relay1)

On failure, throws an exception or returns Y_FRIENDLYNAME_INVALID.

files→get_functionDescriptor()
files→functionDescriptor()
files.get_functionDescriptor()files→get_functionDescriptor()[files functionDescriptor]files.get_functionDescriptor()files.get_functionDescriptor()files.get_functionDescriptor()files.get_functionDescriptor()files.get_functionDescriptor()files→get_functionDescriptor()files.get_functionDescriptor()

Returns a unique identifier of type YFUN_DESCR corresponding to the function.

js
function get_functionDescriptor()
cpp
YFUN_DESCR get_functionDescriptor()
m
-(YFUN_DESCR) functionDescriptor
pas
YFUN_DESCR get_functionDescriptor(): YFUN_DESCR
vb
function get_functionDescriptor() As YFUN_DESCR
cs
YFUN_DESCR get_functionDescriptor()
java
String get_functionDescriptor()
py
get_functionDescriptor()
php
function get_functionDescriptor()
es
async get_functionDescriptor()

This identifier can be used to test if two instances of YFunction reference the same physical function on the same physical device.

Returns :

an identifier of type YFUN_DESCR.

If the function has never been contacted, the returned value is Y_FUNCTIONDESCRIPTOR_INVALID.

files→get_functionId()
files→functionId()
files.get_functionId()files→get_functionId()[files functionId]files.get_functionId()files.get_functionId()files.get_functionId()files.get_functionId()files.get_functionId()files→get_functionId()files.get_functionId()

Returns the hardware identifier of the filesystem, without reference to the module.

js
function get_functionId()
cpp
string get_functionId()
m
-(NSString*) functionId
vb
function get_functionId() As String
cs
string get_functionId()
dnp
string get_functionId()
java
String get_functionId()
py
get_functionId()
php
function get_functionId()
es
async get_functionId()

For example relay1

Returns :

a string that identifies the filesystem (ex: relay1)

On failure, throws an exception or returns Y_FUNCTIONID_INVALID.

files→get_hardwareId()
files→hardwareId()
files.get_hardwareId()files→get_hardwareId()[files hardwareId]files.get_hardwareId()files.get_hardwareId()files.get_hardwareId()files.get_hardwareId()files.get_hardwareId()files→get_hardwareId()files.get_hardwareId()

Returns the unique hardware identifier of the filesystem in the form SERIAL.FUNCTIONID.

js
function get_hardwareId()
cpp
string get_hardwareId()
m
-(NSString*) hardwareId
vb
function get_hardwareId() As String
cs
string get_hardwareId()
dnp
string get_hardwareId()
java
String get_hardwareId()
py
get_hardwareId()
php
function get_hardwareId()
es
async get_hardwareId()

The unique hardware identifier is composed of the device serial number and of the hardware identifier of the filesystem (for example RELAYLO1-123456.relay1).

Returns :

a string that uniquely identifies the filesystem (ex: RELAYLO1-123456.relay1)

On failure, throws an exception or returns Y_HARDWAREID_INVALID.

files→get_list()
files→list()
files.get_list()files→get_list()[files list: ]files.get_list()files.get_list()files.get_list()files.get_list()files.get_list()files.get_list()files.get_list()files→get_list()files.get_list()YFiles get_list

Returns a list of YFileRecord objects that describe files currently loaded in the filesystem.

js
function get_list(pattern)
cpp
vector<YFileRecord> get_list(string pattern)
m
-(NSMutableArray*) list: (NSString*) pattern
pas
TYFileRecordArray get_list(pattern: string): TYFileRecordArray
vb
function get_list() As List
cs
List<YFileRecord> get_list(string pattern)
dnp
YFileRecordProxy[] get_list(string pattern)
java
ArrayList<YFileRecord> get_list(String pattern)
uwp
async Task<List<YFileRecord>> get_list(string pattern)
py
get_list(pattern)
php
function get_list($pa
